- Page 1 DIAMOND CORE DRILL SPN-202Uw INSTRUCTION MANUAL ◎ Thank you for purchasing our products. ◎ Before using, please read Instruction manual carefully, and use the machine safely by following the instructions. ◎ After reading, please keep it where anyone can utilize.
- Page 2 ＭＥＡＮＩＮＧ ＯＦ ＳＩＧＮＡＬ ＷＡＲＤＳ ＷＡＲＮＩＮＧ ＆ ＣＡＵＴＩＯＮ The instruction manual includes two signal words ； WARNING & CAUTION which are meant as follows. WARNING: It is assumed that if the user uses the machine wrongly, it would be the risks that the user could be died or injured.
-
Page 3: Table Of Contents
CONTENTS 1.WARNING AND CAUTION 【1】 Safety Notice for Electric Tools ･･････････････・・・・・・・・・・・・・・・・・・・・・・・・ 【2】 Notes for Usage of Core Drill ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 2.DESCRIPTION ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3.SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4.STANDARD ACCESSORIES ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5.APPLICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6.GENERAL DRAWING AND SPECIFICATIONS IN OPERATION ・・・・・・・・・・・・・ 7.OPERATIONAL INSTRUCTIONS 【1】 Anchoring Core Dill ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・... -
Page 4: Warning And Caution
1. WARNING AND CAUTION ◎ To avoid the risk of fire, electric shock and personally injury, follow all the instruction mentioned in "Safety Notice for Electric Tools" and "Notes for Usage of Core Drill". ◎ Before using, please read "WARNING & CAUTION", and follow the instructions for your safety. ◎... - Page 5 WARNING 10. Use CONSEC recommended accessories and options. ◎ In case that you use the accessories and the options which are not listed in the manual or CONSEC's catalogue, it might cause the accidents or personal injury. Please do not use the accessories and the options which CONSEC does not recommend.
-
Page 6: 2】Notes For Usage Of Core Drill
【2】Notes for Usage of Core Drill (In case of combination with CONSEC's original Drill Carriage Assy. and Pole Base.) WARNING 1. Check for the embedded conduit etc. ◎ In case that you contact to the electric wire or conduit in that there are electric current, you may receive the electric shocks. - Page 7 CAUTION 1. Do not overload with Core Drill. ◎ Use the machine according to the machine capacity of specifications in order to use safely and efficiently. 2. When drilling, please supply the water for sure. ◎ Overheating of Core Bit reduces not only drilling performance but also its life. So make sure to keep supplying water during drilling operation.
-
Page 8: Description
2. DESCRIPTION Motor Clamp Adjust Bolt (Hex. Socket Set Screw) Cord 5m Plug Water Cock Switch (Built-in Circuit Breaker) Carbon Cap Name Plate Clamp Adjust Bolt （Hex. Socket Set Screw） Lock Dial Feeding Handle Grip Unified Screw (1-1/4”-7UNC) (The Outside of Main Shaft) G 1/2 (The inside of Main Shaft) －6－... -
Page 9: Specifications
3. SPECIFICATIONS Model SPN-202Uw Motor Single phase series commutator motor Power Supply Single-phase A.C. 120V 50/60Hz Rated Current Max. Output 2400W No Load Speed 700min Max. Bit Dia. 205mm(8") Outside Unified screw (1-1/4”-7 UNC) Core Bit Installing Screw Inside G 1/2 Drill Head Weight (Excluding cord) 11.0kg... -
Page 10: General Drawing And Specifications In Operation
6. GENERAL DRAWING AND SPECIFICATIONS IN OPERATION Core drill installed on to □49 Pole Base SB-491-1000. ◎ Drill Head □49 Pole Base Feeding Handle Core Bit Bolt Square Washer Hex. Nut Water Collector Leveling Bolt Water Collector Fitting －8－... -
Page 11: Operational Instructions
7. OPERATIONAL INSTRUCTIONS 【1】 Anchoring Core Drill ◎ Core drill can be anchored by means of Anchor Bolt, Vacuum Pad or Support Jack. Follow the below procedures for bolt anchor method. 【2】 Anchoring Core Drill by Anchor Bolt 1. Installation of anchor bolt 1) Drill anchor bolt hole, using a hammer drill. - Page 12 7．Core drilling WARNING When drilling a through-hole, take proper measures to provide for protection on the other side where core bit penetrates. 1) Turn switch off and plug in. WARNING To prevent accidental starting, make certain that motor switch is in OFF position before plugging your machine.
-
Page 13: Maintenance And Servicing
(6mm), replace with new ones. ○ Keep the Carbon Brush clean for free sliding in brush holder. CAUTION Use HAKKEN genuine Carbon Brushes for replacement. －11－... - Page 14 3) Hold Clutch Adjusting Pin by your hand, hang the Spanner 36mm on the Main Shaft. Using Torque Wrench, fasten the clutch. Tightening Tightening Model Torque Direction Hex. Bar Wrench SPN-202Uw 87N・m Left Clutch Adjusting Pin Torque Wrench CAUTION Right Tightening more than specified value might cause the damage to clutch adjusting pin and Drill Motor.
-
Page 15: For Repairing
◎ For repairing your machine, contact CONSEC's authorized representative. 10. WARRANTY We will guarantee the HAKKEN Core Drill SPN-202U for 6 months from the date of delivery. During this period we will rectify material and production defects free of charge. We are not responsible for any other damage direct nor indirect other than this. - Page 16 －14－...
- Page 17 －15－...
- Page 18 －16－...
- Page 19 －17－...
- Page 20 Main office : 4-6-8 Shoko Center Nishi-ku Hiroshima 733-0833 Japan International Department : 1-7-5-1, Sakaimachi, Naka-ku, Hiroshima, 730-0853 Japan Phone : 81-82-297-3231 Fax : 81-82-297-3230 E2280-1 －18－...
