- Page 1 DIAMOND CORE DRILL SPN-202Ui INSTRUCTION MANUAL ◎ Thank you for purchasing our products. ◎ Before using, please read Instruction manual carefully, and use the machine safely by following the instructions. ◎ After reading, please keep it where anyone can utilize.
- Page 2 Read the operating instructions before use. Only for EU countries Disposal of electric tools together with household waste is not permissible! In observance of European Directive on waste electrical and electronic equipment and its implementation in accordance with national law, electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility.
-
Page 3: Table Of Contents
CONTENTS 1.WARNING AND CAUTION 【1】 Safety Notice for Electric Tools ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 【2】 Notes for Usage of Core Drill ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 【3】 For Mounting Drill Carriage Assy. and Pole Base ・・・・・・・・・・・・・・・・・・・・ 2.DESCRIPTION ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 3.SPECIFICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 4.STANDARD ACCESSORIES ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 5.APPLICATIONS ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 6.GENERAL DRAWING AND SPECIFICATIONS IN OPERATION ・・・・・・・・・・・・・... -
Page 4: Warning And Caution
1. WARNING AND CAUTION ◎ To avoid the risk of fire, electric shock and personally injury, follow all the instruction mentioned in "Safety Notice for Electric Tools" and "Notes for Usage of Core Drill". ◎ Before using, please read "WARNING & CAUTION", and follow the instructions for your safety. ◎... - Page 5 WARNING 11. Use CONSEC recommended accessories and options. ◎ In case that you use the accessories and the options which are not listed in the manual or CONSEC's catalogue, it might cause the accidents or personal injury. Please do not use the accessories and the options which CONSEC does not recommend.
-
Page 6: 2】Notes For Usage Of Core Drill
【2】Notes for Usage of Core Drill (In case of combination with CONSEC's original Drill Carriage Assy. and Pole Base.) WARNING 1. Check for the embedded conduit etc. ◎ In case that you contact to the electric wire or conduit in that there are electric current, you may receive the electric shocks. - Page 7 WARNING 15. Do not use the Core Bit which exceeds the maximum diameter of Core Bit. 16. Connection for water supply must be ensured. ◎ Water might be splashed to the electric tool or person in working area. 17. In case that Pole Base is fixed, ensure to fix it at stable place. 18.
-
Page 8: 3】 For Mounting Drill Carriage Assy. And Pole Base
Core Drill. Use Drill Motor in one of the following ways. ◎ To combine with a genuine “HAKKEN” brand Drill Carriage Assy. and Pole Base. ◎ To combine with the CE marked Drill Carriage Assy. and Pole Base. -
Page 9: Description
2. DESCRIPTION Motor PRCD Water Cock (Cord 2.4m) Hose Band 00 (Standard Accessories) Plug Hose 12×250 (Standard Accessories) Switch (Built-in Circuit Breaker) Carbon Cap Name Plate Clamp Adjust Bolt （Hex. Socket Set Screw） Lock Dial Feeding Handle Grip Unified screw (1-1/4”-7 UNC) G 1/2 (The inside of Main Shaft) (The outside of Main Shaft ) －7－... -
Page 10: Specifications
3. SPECIFICATIONS Model SPN-202Ui Motor Single phase series commutator Motor Power Supply Single-phase A.C. 230V 50Hz Rated Current 8.7A Max. Output 2400W No Load Speed 710min Max. Bit Dia. 204mm 8” Core Bit Installing Screw Outside Unified screw (1-1/4”-7UNC) inside... -
Page 11: General Drawing And Specifications In Operation
6. GENERAL DRAWING AND SPECIFICATIONS IN OPERATION ◎ Drill Head installed on to □49 Pole Base. Drill Head Drill Motor □49 Drill Carriage Assy Feeding Handle □49 Pole Base Bolt Square Washer Hex. Nut Leveling Bolt Core Bit Water Collector Water Collector Fitting －9－... -
Page 12: Operational Instructions
7. OPERATIONAL INSTRUCTIONS (Explanation referring to general drawing during operation.) 【1】 Anchoring Core Drill ◎ Core Drill can be anchored by means of Anchor Bolt, Vacuum Pad or Support Jack. Follow the below procedures for bolt anchor method. 【2】 Anchoring Core Drill by Anchor Bolt 1.Installation of anchor bolt 1) Drill anchor bolt hole, using a hammer drill. - Page 13 7.Core Drilling WARNING When drilling a through-hole, take proper measures to provide for protection on the other side where Core Bit penetrates. 1) Turn switch off and plug in. WARNING To prevent accidental starting, make certain that motor switch is in OFF position before plugging your machine.
-
Page 14: 1】 Maintenance
8. MAINTENANCE AND INSPECTION 【1】 Maintenance 1) Clean the surface of the machine after using. Regarding the outer frame of the Drill Head, the part of the gear case is made of aluminum, and the part of the motor is made of the sturdy synthetic resin. If gasoline, thinner, petroleum or kerosene are adhered to the outer frame of the Drill Head, the surface of the Drill Head will be damaged. - Page 15 Shaft. Using Torque Wrench, fasten the clutch. Tightening Tightening Model Torque Direction Hex. Bar Wrench Clutch Adjusting Pin SPN-202Ui 87N･m Left Torque Wrench CAUTION Right Tightening more than specified value might cause the damage to clutch adjusting pin and Drill Motor.
- Page 16 4) After completion of 1) - 3), pull out Clutch Adjusting Pin. Hang Single-ended Wrench 36mm on the Main Shaft and then stick the main shaft by a handle of the wrench touching the pole. Make sure that the main shaft is locked. Turn the motor switch on for just a moment and make sure that the clutch is slipping without motor locking.
-
Page 17: For Repairing
11. WARRANTY We will guarantee the HAKKEN Core Drill SPN-202Ui for 6 months from the date of delivery. During this period we will rectify material and production defects free of charge. We are not responsible for any other damage direct nor indirect other than this. This warranty does not cover normal wear and tear, overloading, non-compliance with the operating instructions and intervention by unauthorized persons or the use of parts from other companies. -
Page 18: Ce Declaration Of Conformity
Product Name : Diamond Core Drill Model : SPN-202Ui Council Directive : 2006/95/EC , 2004/108/EC , 2006/42/EC Relative Standard : EN292-1 , EN292-2 , EN55014-1 , EN55014-2 , EN61000-3-2,... - Page 19 MEMO －17－...
- Page 20 Main office : 4-6-8 Shoko Center Nishi-ku Hiroshima 733-0833 Japan International Department : 1-7-5-1, Sakaimachi, Naka-ku, Hiroshima, 730-0853 Japan Phone : 81-82-297-3231 Fax : 81-82-297-3230 E1940-1 －18－...
