Chapter 1
1. 2. 2.

The Side and Back Panel

The following parts (view from left to right) are located on the rear panel.
Item
Reset Button
USB 3.0 Ports
Internet Port
Ethernet Ports (1/2/3/4)
Power On/Off Button
Power Port
1. 3.

Position Your Router

• Place your router in a well-ventilated place far from any heater or heating vent.
• Avoid direct irradiation of any strong light (such as sunlight).
• Keep at least 2 inches (5 cm) of clear space around your router.
Generally, your router should be placed on a horizontal surface. It also can be mounted
on the wall as shown below.
Press and hold this button for more than 10 seconds to reset the router to its
factory default settings.
For connecting your USB storage device or USB printer to the router.
For connecting to a DSL/Cable modem, or an Ethernet jack.
For connecting your PC or other wired devices to the router.
Press this button to power on or off the router.
For connecting the router to a power socket via the provided power adapter.
Get to Know About Your Router
Description
5
