Telescope Features
Image A
EclipseView 82
Image B
17
8
FIGURE 1A
14
7
9 10
13
15
16
6
12
13
1. Mount Feet
Image C
5
2. Dobsonian Mount
11
3. Azimuth Tension Nut
7
4. Optical Tube Assembly (OTA)
5. Solar Filter Assembly (See Image D) -
4
*Required for viewing the Sun
6. Secondary Mirror Collimation Adjustments (not visible)
7. SunFinder with Mounting Bracket (See Image C)
8. Finder Bracket Mounting Thumbscrews
(See image A)
9. Focuser
2
10. Focuser Drawtube
Image D
3
11. Focuser Knob
12. Eyepiece
5
13. Eyepiece Holder Thumbscrews
14. Vertical Lock Knob (See Image A)
1
1
15. Red-dot Viewfinder Power Switch (See Image B)
16. Red-dot Viewfinder Adjustment Knobs (See Image B)
17. Red-dot Finder (See Image B)
7
6
Always use the EclipseView Solar Filter when viewing at or near the Sun or irreversible eye damage may occur.
