Telescope Features
EclipseView 1 14
FIGURE 1B
7
10
5
9
2
1
8
7
Always use the EclipseView Solar Filter when viewing at or near the Sun or irreversible eye damage may occur.
Image A
18
14
12
13
1. Mount Feet
2. Dobsonian Mount
11
3. Azimuth Tension Nut
4. Optical Tube Assembly (OTA)
5. Solar Filter Assembly (See Image D) -
4
*Required for viewing the Sun
6. Secondary Mirror Collimation Adjustments (See Image A)
SunFinder with Mounting Bracket (See Image C)
7.
17
8. Finder Bracket Mounting Thumbscrews (See Image A)
9. Focuser
10. Focuser Drawtube
11. Focuser Knob
3
12. Eyepiece
13. Eyepiece Holder Thumbscrews
14. Vertical Lock Knob
15. Red-dot Viewfinder Power Switch (See Image B)
16. Red-dot VIewfinder Adjustment Knobs (See Image B)
17. Primary Mirror Collimation Adjustment Knobs (not visible)
1
18. Dovetail Locking Knob (See Image A)
19. OTA Dovetail (See Image A)
20. Dovetail Receiver (See Image A)
21. Red-dot Viewfinder (See Image B)
Image B
19 20
8
16
6
Image D
21
15
Image C
7
5
