SCHEDULE LIST
List of schedules.
DATE & TIME
Sets the date, time, and daylight saving region. Date & time must be set in order for the
"SCHEDULE" function to operate. See page 32.
YEAR
Confi gures the year for the real-time clock.
MONTH
Confi gures the month for the real-time clock.
DAY
Confi gures the day for the real-time clock.
TIME
Confi gures the time for the real-time clock.
DAYLIGHT SAVING
Confi gures daylight savings on or off.
RESET
Resets the following settings within the SCHEDULE menu back to factory setting: OFF TIMER,
SCHEDULE SETTINGS.
MULTI PICTURE CONTROL*
KEEP MULTI PICTURE
Allows the monitor to remain in MULTI PICTURE and TEXT TICKER mode after powering off.
MODE
When Power is returned, MULTI PICTURE and TEXT TICKER appear without having to enter
the OSD.
MULTI PICTURE MODE
Selects picture number and display form.
NOTE: This function is released when selecting SUPER in INPUT CHANGE, SCREEN SAVER,
INPUT CONFIGURATION, IMAGE FLIP except for NONE.
When this function is "ON", STILL, POINT ZOOM are not available.
MULTI PICTURE
When "OFF" is selected one picture is displayed.
When "ON" is selected several pictures are displayed.
PICTURE NUMBER
Selects [2 PICTURES], [3 PICTURES], [4 PICTURES].
After selected PICTURE NUMBER, select display form PIP, PBP1, PBP2, or PBP3. Depending
on the setting at PICTURE NUMBER, display form selection is changed. See page 17.
ACTIVE PICTURE*
2
ACTIVE
When MULTI PICTURE is "OFF", [PICTURE 1] is Active Picture. When MULTI PICTURE is "ON",
sets Active Picture.
NOTE: This function depends on MULTI PICTURE setting.
ACTIVE FRAME
ON: Active picture is shown with frame.
INPUT SELECT
Selects Multi Picture input. Press the + button or - button to select input.
NOTE: This function is not available when MULTI PICTURE is "OFF".
Press SET button after selecting Active Picture input.
2
PICTURE SIZE*
Sets Active Picture size.
Press the SET/POINT ZOOM button to adjust picture size. Press + or CH+ to expand. Press - or
CH- to reduce.
NOTE: This function is not available when MULTI PICTURE is 4 PICTURES PBP.
Depends on the setting at MULTI PICTURE MODE, some picture cannot change it's size.
PICTURE POSITION*
2
Sets Active Picture location.
Pressing the + button moves Active Picture to the right, and pressing the - button moves it to
the left.
Pressing the
NOTE: This function is not available when MULTI PICTURE is 4 PICTURES PBP.
PICTURE ASPECT*
2
Selects Active Picture frame aspect, [FULL], [NORMAL] and [EXPAND].
To change aspect ratio of the screen image, see page 17.
NOTE: This function depends on MULTI PICTURE setting.
ROTATE
ROTATE ALL
When "ON" is selected, all pictures rotate.
When "OFF" is selected, sets each picture ROTATE settings.
NOTE: When TEXT TICKER, IMAGE FLIP except for NONE, STILL is ON or SCREEN SAVER
is active, this function is not available. If ASPECT "1:1" is selected, characters and lines may be
displayed in blurring, depending on the signal resolution.
When ROTATE is ON, POINT ZOOM and IMAGE FLIP except for NONE are not available.
Each picture ROTATE settings are released when MULTI PICTURE is set to "OFF".
When input signal is Interlace, the image may be disturbed.
If input signal is 3840 x 2160 60 Hz and [3 PICTURES], [4 PICTURES] is selected at PICTURE
NUMBER in MULTI PICTURE MODE, ROTATE is not available.
If ROTATE of MULTI PICTURE CONTROL is selected in the input signal with a high refresh rate,
the image may not be displayed smoothly. To reduce this condition, please set the input signal
with a low refresh rate.
*1: This function is released when selecting SUPER in INPUT CHANGE, SCREEN SAVER, INPUT CONFIGURATION, IMAGE FLIP except for NONE.
*2: When TEXT TICKER is active, this function is not available.
1
button moves Active Picture up, and pressing the
English-25
2 PICTURES/
X=95, Y=92
button moves it down.
-
-
-
-
-
OFF
-
OFF
OFF
PIP
ON
-
37
NORMAL
OFF
