MULTI PICTURE button
ON/OFF button: Toggle switches between ON and OFF.
See page 17.
MODE button: Selects picture number and a mode from PIP,
PBP 1, PBP 2, PBP 3.
CHANGE button: Selects a pair of pictures. You can swap
images between the selected two pictures.
PICTURE ASPECT button: Selects active picture frame
aspect.
ROTATE button: Selects a multi picture to rotate 90°.
ALL ROTATE button: All multi pictures rotate 90°.
When MULTI PICTURE is OFF, the displayed single
picture rotates 90°.
NOTE: Enable to change each multi picture size by pressing
SET/POINT ZOOM button during multi picture mode.
You cannot select input other than the setting of the
HDMI/DVI SELECT.
STILL button
ON/OFF button: Activates/deactivates still picture mode.
STILL CAPTURE button: Captures still picture.
NOTE: This function is released when selecting MULTI
PICTURE MODE, TEXT TICKER, SCREEN SAVER, POINT
ZOOM, IMAGE FLIP except for NONE, SUPER in INPUT
CHANGE, INPUT CONFIGURATION.
When STILL is active, ROTATE is not available.
REMOTE ID button
Activates REMOTE ID function. See page 33.
MTS button*
1
button*
1
Activates closed captioning.
2
2
NOTE: VIDEO*
, S-VIDEO*
*1: This button's action depends on which option board you use.
Refer to the option board's manual for further information.
*2: This function depends on which option board you use.
*3: This function depends on INPUT CONFIGURATION setting.
NOTE:
The buttons with no explanation do not function.
inputs only.
Operating Range for the Remote
Control
Points the top of the remote control toward the LCD monitor's
remote sensor during button operation.
Uses the remote control within a distance of about 7 m (23 ft.)
from remote control sensor or at a horizontal and vertical
angle of within 30° within a distance of about 3.5 m (10 ft.).
Caution: Important, the remote control
system may not function
when direct sunlight or strong
illumination strikes the remote
control sensor or when there is
an object in the path.
Handling the remote control
•
Do not subject to strong shock.
•
Do not allow water or other liquid to splash the remote
control. If the remote control gets wet, wipe it dry
immediately.
•
Avoid exposure to heat and steam.
•
Other than to install the batteries, do not open the remote
control.
English-11
