WX2190 and WX2060 HELM LAYOUT
1
8
Figure 3-1
1. Multifunction Speed/Fuel Gauge
2. Steering Fluid Fill
3. Multifunction Gauge – Tachometer/Trim
4. Ignition Switch
5. Stereo
6. Auxiliary Plug – Headphone Jack/Music
USB Port
7. Starboard Switch Panel
8. Port Switch Panel
9. Steering Wheel Tilt
Table Of Contents
2
3
10
9
3-3
DEEP-V BOATS
4
5
6
11
12
7
13
18
17
10. Steering Wheel
11. Breaker Panel
12. 12-Volt Receptacle
13. Courtesy Light
14. Engine Remote Control
15. Kicker Engine Control (Optional)
16. Kicker Key Switch (Optional)
17. Speaker
18. Removable Access Plate
14
15
16
