UNVENTED (VENT-FREE) GAS LOG HEATER
OWNER'S OPERATION AND INSTALLATION MANUAL
REMOTE-READy LOG SET AND BURNER SySTEM MODELS
MF42INR, MF42IPR, MF48INR, MF48IPR, VFGT30NR, VFGT30PR,
VARIABLE-REMOTE LOG SET AND BURNER SySTEM MODELS
MF42INV, MF42IPV, MF48INV, MF48IPV, VFGT30NV, VFGT30PV, VFGT36NV
MF42 MODELS MAY BE USED WITH LMF42-SC LOGS ONLY
MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
— Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
PFS
®
US
VFGT36NR AND VFGT36PR
AND VFGT36PV
For more information, visit www.fmiproducts.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for FMI MF42INF
Summary of Contents for FMI MF42INF
- Page 1 UNVENTED (VENT-FREE) GAS LOG HEATER OWNER’S OPERATION AND INSTALLATION MANUAL ® REMOTE-READy LOG SET AND BURNER SySTEM MODELS MF42INR, MF42IPR, MF48INR, MF48IPR, VFGT30NR, VFGT30PR, VFGT36NR AND VFGT36PR VARIABLE-REMOTE LOG SET AND BURNER SySTEM MODELS MF42INV, MF42IPV, MF48INV, MF48IPV, VFGT30NV, VFGT30PV, VFGT36NV AND VFGT36PV MF42 MODELS MAY BE USED WITH LMF42-SC LOGS ONLY MF48 MODELS MAY BE USED WITH LMF48-SC LOGS ONLY...
-
