- Page 1 HD Ready LCD TV with Freeview, DVD & iPod Docking User Guide Model No M22/20A-GB-TCDI-UK...
- Page 2 Important Guarantee Information. Congratulations on purchasing this television. We hope you have many years of trouble free enjoyment from your purchase. Your product is covered under the manufacturers guarantee for 12 months from date of purchase. The guarantee is ‘return to manufacturer’ and covers the costs of collection, parts &...
- Page 4 Important information regarding the digital TV switchover Television in the UK is going digital, bringing us all more choice and new services. Starting late 2007 and ending in 2012, television services in the UK will go completely digital, TV region by TV region. How the switchover affects your TV equipment.
- Page 5 Warnings Caution This television contains no user serviceable parts. Please refer to the manufacturer or authorised repair agent in the event of malfunction. Do not remove the back cover from the television. Warning To reduce the risk of fire, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any objects filled with liquids on or near the television.
- Page 6 Warnings Screen Burn A characteristic of LCD TV Panels is that displaying the same image for a long time may cause a permanent after - image to remain on the screen. This is called screen burn. Most pictures shown on your TV will be constantly moving and fill the screen. Examples of images that you need to watch out for are as follows (this is not an all-inclusive list): TV Channel Logos: e.g.
-
Page 7: Table Of Contents
Contents Chapter 1 Introducing the LCD TV Getting Started 3 - 4 Chapter 2 Installing the LCD TV Remote Control Buttons TV Buttons Inputs & Connections Source Menu Chapter 3 Using The Features Picture Menu 8 - 11 Sound Menu 12 - 13 Tuning Menu 14 - 15... - Page 8 What is included in the box Accessories Included with this TV are the following accessories: 1x - User Guide Book 1x - Remote control IPOD PROGRAM TEXT HOLD REVEAL INDEX GOTO SIZE SUBPAGE FAV- FAV+ NICAM D.TITLE D.MENU ZOOM SUBTITLE DVB-LANG -/-- DVB-INFO...
-
Page 9: Getting Started
Getting Started - Initial Set Up IMPORTANT - AFTER TUNING DO NOT PRESS ANY BUTTONS FOR 20 SECONDS SO THE CHANNEL INFORMATION CAN BE STORED. TUNING IN 1) Using the RF Cable supplied, connect the TV to the TV Aerial socket (Fig A) IMPORTANT: If your TV signal is inadequate to receive a good Digital signal, you will need to connect a 'Signal booster' between your TV and TV Aerial Socket. -
Page 10: Remote Control Buttons
Remote Control Buttons DVB-LANGUAGE / AUDIO Digital mode: Press to select the digital language Press to switch on LCD when on standby mode or DVD mode: Press to select DVD audio channels vice versa EPG / REPEAT Digital mode: Press to show the Electronic Program Press to mute the sound and press again to restore Guide menu DVD mode: Press to set repeat... -
Page 11: Tv Buttons
TV Buttons TOP PANEL BUTTONS Eject Play/Pause Select the input source Displays Menu/OSD Volume down and menu down Volume up and menu up Program/Channel down and menu down Program/Channel up and menu up Standby ON/OFF EJECT SOURCE MENU STANDBY PLAY/PAUSE... -
Page 12: Inputs & Connections
Inputs & Connections REAR CONNECTIONS HDMI input HDMI IN VGA IN VGA-PC Audio input SCART Scart input VIDEO IN Video input COMPONENT IN Component input VIDEO/COMPONENT Video/Component Audio input AUDIO PC AUDIO PC Audio input CI Port RF IN RF input COAX Digital Audio Out (DVD) 3.5mm Audio output to connecting... -
Page 13: Picture Menu
TV Menu Operation PICTURE SETTINGS MENU PLEASE NOTE – YOU CAN ONLY MAKE ADJUSTMENTS TO CONTRAST, BRIGHTNESS & COLOUR WHEN PICTURE MODE IS SET TO ‘PERSONAL’. Lets you adjust picture mode, contrast, brightness, colour, tint and sharpness to enhance the viewing experience. Selecting Picture Mode Presets Switch between different preset picture options Standard... - Page 14 TV Menu Operation PICTURE SETTINGS MENU Adjusting Brightness (Only available when Picture Mode is set to Personal) Increase or decrease the brightness of the picture 1) Press [MENU] to enter menu 2) Press [\/] to highlight Brightness 3) Press [>] to increase the brightness or [<] to decrease the brightness 4) Press [EXIT] to exit Adjusting Colour (Only available when Picture Mode is set to Personal) Increase the colour from black and white to vivid...
- Page 15 TV Menu Operation PICTURE SETTINGS MENU Adjusting Tint (Only available in VGA/PC Mode) Lets you increase or decrease the level of tint within the picture 1) Press [MENU] to enter menu 2) Press [\/] to highlight Tint 3) Press [>] to increase the tint or [<] to decrease the tint 4) Press [EXIT] to exit Adjusting Sharpness You can change the sharpness between the different preset options...
- Page 16 TV Menu Operation PICTURE SETTINGS MENU Adjusting Colour Temperature (Only available in VGA/PC Mode) There are 3 presets for colour temperature Normal Standard setting Warm Increased red within the picture Cold Increased blue within the picture 1) Press [MENU] to enter menu 2) Press [\/] to highlight Colour Temperature 3) Press [>] to navigate through the various options 4) Press [EXIT] to exit...
-
Page 17: Sound Menu
TV Menu Operation SOUND SETTINGS MENU Adjusting Volume Lets you adjust the volume of the television 1) Press [MENU] to enter menu 2) Press [>] to move to Sound Settings Menu 3) Press [\/] to highlight Volume 4) Press [>] to increase the volume or [<] to decrease the volume 5) Press [EXIT] to exit Selecting Sound Mode Switch between different preset sound options... - Page 18 TV Menu Operation SOUND SETTINGS MENU Adjusting Bass To adjust the amount of bass within the sound 1) Press [MENU] to enter menu 2) Press [>] to move to Sound Settings Menu 3) Press [\/] to highlight Bass 4) Press [>] to increase the bass or [<] to decrease the bass 5) Press [EXIT] to exit Adjusting Treble To adjust the amount of treble within the sound...
- Page 19 TV Menu Operation TUNING SETTINGS MENU (Only Freeview & Analogue TV modes) Adjusting Country If you are moving country you may wish to change the Country Settings 1) Press [MENU] to enter menu 2) Press [>] to move to Tuning Settings Menu 3) Press [\/] to highlight Country 4) Press [>] to alter the chosen country 5) Press [EXIT] to exit...
-
Page 20: Tuning Menu
TV Menu Operation TUNING SETTINGS MENU Program Edit / Changing Channel Position (Only Freeview & Analague TV modes) You can change the analogue channel position to suit your requirements. 1) Press [MENU] to enter menu 2) Press [>] to move to Tuning Settings Menu 3) Press [\/] to highlight Program Edit 4) Press [>] to enter the program edit menu 5a) Freeview mode –... -
Page 21: Timer Menu
TV Menu Operation TIMER SETTINGS MENU Lets you adjust the OSD timing and the sleep timer Sleep Timer Lets you set the sleep timer so the television automatically switches off after a certain amount of time. 1) Press [MENU] to enter menu 2) Press [>] to move to Timer Settings Menu 3) Press [\/] to highlight Sleep Timer 4) Press [>] to increase the time to the required amount... -
Page 22: General Menu
TV Menu Operation GENERAL SETTINGS MENU Lets you adjust the language, picture size, blue screen, add child lock, complete first time installation and reset the television. On Screen Menu Language Lets you change the on screen menu language. 1) Press [MENU] to enter menu 2) Press [>] to move to General Settings Menu 3) Press [\/] to highlight Language 4) Press [>] to change the language... - Page 23 TV Menu Operation GENERAL SETTINGS MENU 5) To change Pin Code enter menu. Enter the old pin code (Default is blank), then enter the new pin code and enter it again. Press [OK], the pin is now changed Change PIN Code Old PIN Code New PIN Code Enter PIN Code...
-
Page 24: Electronic Program Guide
Electronic Program Guide Electronic Program Guide (EPG) The Electronic Program Guide (EPG) is available in Digital TV mode. It is a 7 day TV guide and provides information about forthcoming programmes (where supported by the broadcasted channel). You can view the start and end time of all programs and on all channels for the next 7 days. It is very simple to operate. -
Page 25: Digital Text
Digital Teletext Digital TV Teletext With Digital TV (Freeview) there is also digital teletext available on some channels. Simply follow the on screen commands. Here is an example of the BBC digital teletext service. 1) To start digital teletext press the RED button (BBC channels) or the TEXT buttons (Other channels) 2) To select the information you require you can scroll using [\/] or [/\] and press [OK] alternatively you can key the page number for example [3][0][0] followed by [OK] You can then navigate using the colour buttons (Red, Green, Yellow, Blue), the [\/] [/\] buttons... -
Page 26: Analogue Tv Text
TV Mode Teletext Operation Teletext is a service offered by some broadcasters. Teletext Operation 1) Press [TEXT], after a few seconds teletext page 100 should appear. Here is an example of BBC1 2) You can now navigate to the page you require in a number of ways: a) Press the page you require using the number buttons i.e. -
Page 27: Ipod Operation
iPod Operation Connect iPod to TV-Dock 1) Insert your iPod to the TV-dock on the sound base. The TV would detect the insertion of iPod an automatically switch to iPod mode. You can also manually switch to iPod mode by pressing IPOD button or selecting “iPod”... - Page 28 iPod Operation Key Buttons VOL- Decrease the volume TEXT HOLD REVEAL INDEX VOL+ Increase the volume GOTO SIZE SUBPAGE BASS- Decrease the sub bass BASS+ Increase the sub bass FAV- FAV+ NICAM D.TITLE D.MENU ZOOM Play/pause DVB-LANG DVB-INFO SUBTITLE Next track SUBT.
- Page 29 iPod Operation Now Playing Interface Track Title Artist Album Name Shuffle Off Shuffle State Shuffle On Repeat Off Repeat State Repeat One Song Elapsed time Repeat All Track Time Volume Level Bass Level Scrubber bar Shuffle and Repeat Songs iPod iPod Main Menu Main Menu...
- Page 30 iPod Operation Watch Videos from iPod iPod Main Menu 1 Music 2 Videos 3 Shuffle Songs 4 Settings 5 Now Playing Pg Up/Down Enter Select IPOD MENU Operate Via Ipod Back For iPod nano 3Gen, iPod Classic, iPod 5Gen, you can select a video program and play in the iPod Menu OSD.
-
Page 31: Connecting To A Pc
Connecting to a PC - Windows XP IMPORTANT— Before connecting to a PC you must ensure that the settings of the PCs output are correct for the new LCD Monitor. You need to do the following with your old monitor connected 1) Switch on your PC 2) When finished booting up, right click your mouse anywhere on the screen, the below will appear... - Page 32 Connecting to a PC - Windows XP 5) Left click your mouse on Advance, this screen will appear, click on tab called ‘Monitor’ 6) Left click on the drop down for Screen refresh rate and select 60 Hertz. 7) Finally click on Apply, then click Yes and the settings will be saved. 8) Turn off your PC.
-
Page 33: Vga (Pc) Menu
PC Menu Operation (VGA) VGA MENU Auto Configuration of Screen Lets you automatically configure the television to be used as a computer monitor 1) Press [MENU] to enter menu 2) Press [>] to select PC settings 3) Press [\/] to select Auto Sync 4) Then press [>] for the TV to automatically configure itself 5) Press [EXIT] to exit Phase... - Page 34 PC Menu Operation (VGA) Horizontal Position Changes the horizontal position of the picture 1) Press [MENU] to enter menu 2) Press [>] to select PC settings 3) Press [\/] to select H-Position 4) Then press [>] or [<] to move the picture to left or right 5) Press [EXIT] to exit Vertical Position Changes the vertical position of the picture...
-
Page 35: Dvd Menu
DVD Menu Operation HOW TO PLAY DVD’S The DVD player has an automatic DVD feature which means when you insert a disc it will automatically switch source and start to play. If you disc does not play please refer to frequently asked questions section of the user guide. DVD SETTINGS MENU Adjusting Parental Control You may wish to block certain DVDs being played, for example if you have young children. - Page 36 DVD Menu Operation Adjusting Language Lets you adjust the Audio Language, Menu Language, Subtitle Language within DVD mode 1) Press [MENU] to enter menu 2) Press [>] to move to DVD Setting Menu 3) Press [\/] to highlight Language SETUP Parental Control Language Audio Setup...
- Page 37 DVD Menu Operation Adjusting Audio Set Up Lets you adjust the Audio Setup within DVD mode 1) Press [MENU] to enter menu 2) Press [>] to move to DVD Setting Menu 3) Press [\/] to highlight Audio Setup SETUP Parental Control Language Audio Setup Digital Setup...
- Page 38 DVD Menu Operation Adjusting Digital Set Up Lets you adjust the Audio Setup within DVD mode 1) Press [MENU] to enter menu 2) Press [>] to move to DVD Setting Menu 3) Press [\/] to highlight Digital Setup SETUP Parental Control Language Audio Setup Digital Setup...
-
Page 39: Wall Mounting
Wall Mounting IMPORTANT— BEFORE DRILLING ANY HOLES IN THE WALL ENSURE YOU ARE NOT DRILLING WHERE THERE COULD BE ANY ELECTRIC WIRES, WATER OR GAS PIPES THIS TV REQUIRES A VESA 100 WALL MOUNT, OR EQUIVALENT To provide improved sound this television has speakers built into the stand of the TV. -
Page 40: Using With Sky Digital
Using with Sky Digital You may wish to use your TV with Sky Digital. There are a number of connection options, the best being connecting via SCART cable. Connecting via SCART 1) Connect the SCART cable from the Sky Digital Box to SCART of the TV 2) Press [SOURCE] 3) Press [\/] or [/\] to select SCART 4) Press [OK]... - Page 41 Using with Sky Digital USING WITH SKY DIGITAL REMOTE CONTROLS (BSKYB) OR UNIVERSAL REMOTE CONTROL You may wish to use your Sky Digital or a universal remote control to operate some of the functions of this TV. For this you require a ‘code’ that needs to be programmed into your Sky Digital or universal remote control.
-
Page 42: Connecting A Games Console
CONNECTING A GAMES CONSOLE Connecting a games console can sometimes seem very difficult. We have simplified it to three options depending on the cables that you have. Option 1 – Connecting via Scart to AV adapter If you are supplied with a cable from the console which has YELLOW, RED & WHITE connectors you can connect via a SCART to AV adapter (Some console include this) TV source should be set to SCART. -
Page 43: Frequently Asked Questuions
Frequently Asked Questions Solution: Question: I have tuned in Digital TV but 1) Check you are in an area that can I am not receiving any or all of the receive Freeview. Visit channels and/or the channels I receive www.freeview.co.uk or call are breaking up 08701 111 270. -
Page 44: Technical Specification
Technical Specification Model Name " 9 " 2 LCD Panel Panel 16:10 × Analogue:BG, DK, I, L/L' TV System Digtial: DVB-T Analogue: PAL, SECAM, NTSC 3.58/4.43(Only video in) Colour/Video System Digital: MPEG-2 MP@ML Systems Analogue: VHF: E2-E12/UHF: E21-E69/CATV: S1-S20/HYPER: S21-S41 D/K: R1-R12, R21-R69/L: F2-F10, B-Q, F21-F6 Reception Range Digital: VHF/UHF... -
Page 45: Index
Index Analogue TV teletext Index Audio Set up Inputs and Connections Auto Configuration of Screen Manual Tuning Auto Tuning On Screen Display Timer Balance On Screen Menu Language Basic iPod Operation Parental Control Bass Phase Blue Screen Picture Format Brightness Picture Mode Preset Browse photos from iPod Position Reset... - Page 46 MMU/MAN/0021...
