Windsor QSC20 Operating Instructions Manual

Windsor saber compact walk behind scrubber
Hide thumbs Also See for QSC20:
Table of Contents

Advertisement

Quick Links

Download this manual
WALK BEHIND SCRUBBER
MODELS:
QSC20
QSCX20
QSC20T
QSCX20T
Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen
E
980067
11/15/03
Instrucciones de funcionamiento (SPA)
Read these instructions before using the machine
Lire ce manuel avant d'utiliser la machine
Lea las instrucciones antes de utilizar la máquina
Operating Instructions (ENG)
Manuel d'utilisation (FRE)
Bedienungsanleitung (GER)
IPX4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSC20 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Windsor QSC20

Summary of Contents for Windsor QSC20

  • Page 1 WALK BEHIND SCRUBBER Operating Instructions (ENG) Manuel d’utilisation (FRE) Bedienungsanleitung (GER) Instrucciones de funcionamiento (SPA) MODELS: QSC20 QSCX20 QSC20T QSCX20T IPX4 Read these instructions before using the machine Lire ce manuel avant d’utiliser la machine Bitte lesen Sie diese Anleitungen, bevor Sie die Maschine in Gebrauch nehmen Lea las instrucciones antes de utilizar la máquina...
  • Page 2 Copyright 1995 Windsor Industries, Printed in USA YOUR DEALER Name: __________________________________________________________________________________________________ Address: _______________________________________________________________________________________________ For the name and address of your dealer contact: Windsor Industries Phone Number: _________________________________________________________________________________________ OVERVIEW The Saber Compact is a battery powered, hard floor scrubber intended for commercial use.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Machine Data Log/Overview......2 GROUP PARTS LIST Table of Contents...........3 Control Handle Group – Non-Traction...5-1 HOW TO USE THIS MANUAL Control Tower Group - Traction.....5-3 Decal Group...........5-5 Electrical Panel Group – Non-Traction..5-7 How to use this Manual.........1-1 Electrical Panel Group –...

  • Page 4: How To Use This Manual

    They are Parts may be ordered from authorized Windsor listed in this general order: dealers. When placing an order for parts, the machine model and machine serial number are Batteries important.

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS When using an battery powered appliance, basic precaution must always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE. WARNING: To reduce the risk of fire, electric shock, or injury: Use only indoors. Do not use outdoors or expose to rain. Use only as described in this manual.

  • Page 6: Hazard Intensity Level

    WHEN SERVICING MACHINE: Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use Windsor approved replacement parts. WARNING Batteries emit hydrogen gas. Explosion or fire can result. Keep sparks and open flame away. Keep solution tank in raised position when charging.

  • Page 7: Safety Label Location

    SAFETY LABEL LOCATION NOTE: These drawings indicate the location of safety labels on the machine. If at any time the labels become illegible, promptly replace them. SAFETY DECAL 81494 CAUTION Explosive Gas is Given Off By Batteries During Charge. 1. Keep Battery Compartment Cover Open.

  • Page 8: Technical Specifications

    TECHNICAL SPECIFICATIONS ITEM DIMENSION/CAPACITY Nominal power – non-traction model 1100 W Nominal power – traction model 1200 W Rated Voltage 24VDC Rated Amperage – non-traction model 45 Amps Rated Amperage – traction model 50 Amps Batteries 2 x 12 Volt 105-130-195 AH @ 20hr rate Scrub Brush Motor .75 hp (0.56 kW)
  • Page 9 TECHNICAL SPECIFICATIONS ITEM MEASURE Height 43 in. ( 109.2 cm) Length 54 in. (137.1 cm) Width without squeegee 22 in. (55.9 cm) Width of squeegee 31 in. ( 78.7 cm) Width of scrub path 20 in. (51 cm) Length Width Height SPECIAL NOTES: The overall root-mean-square acceleration at...

  • Page 10: How The Machine Works

    HOW THE MACHINE WORKS The function of the recovery system is to vacuum The Saber Compact is a battery powered, hard the soiled water back into the recovery tank. The floor scrubber intended for commercial use. The recovery system consists of the squeegee, appliance applies a cleaning solution onto a hard vacuum motor, screen, recovery tank and floor, scrubs the floor with a brush, and then...

  • Page 11: Components

    COMPONENTS 1. Control Panel 2. Control Handle 3. Recovery Tank 4. Recovery Tank Drain Hose 5. Scrub Head 6. Scrub Brush Access Cover 7. Solution Tank 8. Solution Tank Cover 9. Solution Tank Drain Hose 10. Solution Strainer 11. Solution Tank Support Arm 12.
  • Page 12 CONTROLS – NON-TRACTION 1. Brush Switch 2. Brush Lift Lever 3. Vacuum Switch 4. Squeegee Lift Lever 5. Solution Control Lever 6. Battery Charge Level Indicator 7. Hour Meter (Optional) 8. Circuit Breakers SABER (QSC) 980067 11/13/02...
  • Page 13 CONTROLS – NON-TRACTION 1. BRUSH SWITCH 6. BATTERY CHARGE LEVEL INDICATOR Controls the scrub brush motor. Indicates the charge level of the batteries. To turn scrub brush on, press the top of the The meter display is divided into 10 vertical bars.
  • Page 14 CONTROLS - TRACTION 1. Solution Control Knob 2. Brush Switch 3. Brush Lift Lever 4. Vacuum Switch 5. Squeegee Lift Lever 6. Key Switch 7. Propel Buttons (Normally Forward) 8. Reverse Propel Button 9. Speed Control Knob 10. Battery Charge Level Indicator 11.
  • Page 15 CONTROLS – NON-TRACTION 5. SQUEEGEE LIFT LEVER 1. SOLUTION CONTROL KNOB Controls solution flow to scrub deck. Raises and lowers the squeegee. To increase flow, rotate knob clockwise. To lower the squeegee, lift and pull the lever to the left and then lower. To decrease flow, rotate knob To raise the squeegee, lift the lever and push counterclockwise.

  • Page 16: Controls

    CONTROLS – NON-TRACTION 9. SPEED CONTROL KNOB 12. HOUR METER (OPTIONAL) Controls the speed of the machine. Records the number of hours the machine’s brush has been in operation. This information To increase speed, rotate knob clockwise. is useful in determining when to service the machine.

  • Page 17: Machine Operation

    MACHINE OPERATION Measure the chemical into the solution tank. PRE-RUN MACHINE INSPECTION Liquid chemicals should be added to the Do a pre-run inspection to find possible problems solution tank after filling with water. Dry that could cause poor performance or lost time chemicals should be thoroughly mixed before from breakdown.
  • Page 18 MACHINE OPERATION TO STOP SCRUBBING TO BEGIN SCRUBBING 1. Release the directional control button(s), if CAUTION your machine is traction model. When operating the machine around people, pay close attention for unexpected movement. 2. Turn the scrub brush off. Use extra caution around children. 3.

  • Page 19: Emptying & Cleaning Tanks

    MACHINE OPERATION EMPTYING AND CLEANING TANKS RECOVERY TANK 1. Unhook the large drain hose from the retainer. 1. Park the machine next to a floor drain. Drain Unscrew the T-handle on the plug enough to hoses are on the rear of the machine. loosen it, then lower the hose in the direction of the drain.

  • Page 20: Maintenance

    MAINTENANCE BATTERIES CAUTION The batteries provide the power to operate the When servicing machine, avoid contact with machine. The batteries require regular battery acid. maintenance to keep them operating at peak efficiency. WARNING Batteries emit hydrogen gas. Explosion or fire The machine batteries will hold their charge for can result.

  • Page 21: Checking Battery Specific Gravity

    MAINTENANCE CHECKING BATTERY SPECIFIC GRAVITY Check the hydrometer readings against this chart. Use a hydrometer to check the battery specific SPECIFIC GRAVITY BATTERY CONDITION gravity. @ 80° F (27°C) 1.265 100% CHARGED 1.225 75% CHARGED 1.190 50% CHARGED Battery Check 1.155 25% CHARGED 1.120...

  • Page 22: Changing Batteries

    MAINTENANCE TO CHARGE THE BATTERIES 7. Plug the charger connector into the battery connector. Connect the charger AC plug to a CAUTION wall outlet. The charger gauge should indicate When servicing machine, avoid contact with that the batteries are charging. battery acid.

  • Page 23: Scrub Brushes

    MAINTENANCE SCRUB BRUSHES Blue Pads (Scrubbing) are used for heavy-duty scrubbing and light stripping. The blue pads remove NOTE: All original equipment brushes are equipped less finish than brown stripping pads, yet will remove with “Perform Alert©”. This feature will tell the black marks, stains and dirt.

  • Page 24: Squeegee Blades

    MAINTENANCE SQUEEGEE BLADES DELUXE SQUEEGEE BLADES The front squeegee blade allows solution to pass The front squeegee blade allows solution to pass through channels in the blade into the squeegee through channels in the blade into the squeegee assembly while maintaining vacuum to provide lift. assembly while maintaining vacuum to provide lift.

  • Page 25: Greasing Axles

    MAINTENANCE TO ADJUST SQUEEGEE PITCH TO REPLACE OR ROTATE REAR SQUEEGEE BLADE 1. Choose a smooth, level surface. Turn “ON” the key switch and vacuum switch. Lower the 1. With the squeegee in the up position, turn key squeegee and drive forward at least 2 feet switch “OFF”.

  • Page 26: Service Schedule

    MAINTENANCE SERVICE SCHEDULE MAINTENANCE DAILY WEEKLY MONTHLY Check batteries after charging; add water if necessary Check pad wear to prevent buildup of chemicals Check linkages and connectors for wear and damage Check hoses for wear, blockages, or damage Clean squeegee; check for adjustment; inspect for wear Check handles, switches, knobs, domes, and gaskets for damage...

  • Page 27: Machine Troubleshooting

    MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Poor or no water pick-up Debris caught on squeegee Remove debris Worn squeegee blades Replace squeegee blades Vacuum hose clogged Clear obstruction from hose Vacuum hose disconnected Reconnect vacuum hose from squeegee or recovery tank Vacuum hose damaged Replace vacuum hose Vacuum motor inlet screen...
  • Page 28 MACHINE TROUBLESHOOTING PROBLEM CAUSE SOLUTION Little or no solution flow to the Solution tank empty Fill solution tank floor Solution flow turned off or Turn on or increase flow set too low setting Solution strainer plugged Clean solution strainer Solution hoses obstructed Clear obstruction from hose Solution solenoid valve...
  • Page 29 THIS PAGE LEFT BLANK INTENTIONALLY 4-10 SABER (QSC) 980067 11/13/02...

This manual is also suitable for:

Qscx20Qsc20tQscx20t
