- Page 1 REFRIGERATOR SRL550DW SRL551DP OWNER’S INSTRUCTIONS Register your product at www.samsung.com/global/register DA68-00998M REV(0.3)
-
Page 2: Table Of Contents
FEATURES These operating instructions cover various models. The characteristics of your appliance may differ Environmentally friendly refrigerator/freezer using slightly from those described in this manual. R600a refrigerant and cyclopentane blowing agent. • This product protects the environment by using R600a Either R600a or R134a are the refrigerants used. -
Page 3: Warnings / Safety Precautions
WARNINGS / SAFETY PRECAUTIONS To avoid any risk of personal injury, material damage or incorrect use of the appliance, be sure to observe the following safety precautions. (After reading these owner’s instructions, please keep them in a safe place for reference.) Remember to hand them over to any subsequent owner. Indicates that a danger of death or Indicates that a risk of personal serious injury exists. - Page 4 Do not touch any containers or food in the Warning freezer with wet hands. • It may cause frostbite. • Keep ventilation openings in the appliance Remove any foreign matter from the power plug enclosure or mounting structure clear of pins.
-
Page 5: Installing The Refrigerator/Freezer
INSTALLING THE REFRIGERATOR/FREEZER Allow an adequate space and install the refrigerator/freezer on a firm, level floor. • If the appliance is not level, there may be unusual noises and poor cooling. • Wait for at least one hour before plugging the appliance in. Clean the refrigerator/freezer. -
Page 6: Preparing The Refrigerator /Freezer
PREPARING THE REFRIGERATOR /FREEZER To prepare your appliance for use and check that it is running correctly, take the following steps. Install all shelves and compartments removed during transport in the correct positions. You are advised to clean the appliance and accessories before switching the appliance on for the first time to remove any dust that accumulated during packing and shipping. -
Page 7: Using The Control Features
USING THE CONTROL FEATURES REFRIGERATOR TEMPERATURE BUTTON FREEZER TEMPERATURE BUTTON Sets the freezer temperature. Sets the refrigerator temperature. Press the button repeatedly to change the Press the button repeatedly to change the temperature in sequence between temperature in sequence between 7°C and 1°C. -14°C and -25°C. -
Page 8: Controlling The Freezer And Refrigerator
CONTROLLING THE FREEZER AND REFRIGERATOR TEMPERATURES Freezer Refrigerator • • The freezer can be set to a temperature between The refrigerator can be set to a temperature -14°C and -25°C. between 7°C and 1°C. • • Press the FREEZER TEMP. button repeatedly Press the REFRIGERATOR TEMP. -
Page 9: Storing Food In The Refrigerator Or Freezer
STORING FOOD IN THE REFRIGERATOR OR FREEZER When storing food in the appliance, A. Refrigerator follow the recommendations below. • Allow warm food and beverages to cool down before storing them in the appliance. • Ensure that food is well-wrapped or covered before it is stored. - Page 10 B. Freezer Upper freezer drawer • Store packed frozen foods, like ice cream and bacon. Middle/lower freezer drawer • Store fresh meat and fish or dried foods Upper freezer drawer divided into suitably sized portions. Middle/lower freezer drawer Wrapping food Note Pack the food in suitably sized portions for your household.
-
Page 11: Making Ice
MAKING ICE ICE CUBE MAKER Pull out the ice-cube maker. Pour water in up to the water level mark (arrow). (Not to use hot water) Put the ice-cube maker back in position. Close the freezer door. Danger of explosion • The coldest parts of the refrigerator are the rear panel and the lowest shelf. This is the best Warning place to store delicate foodstuffs. -
Page 12: Using The Water Dispenser (Optional)
USING THE WATER DISPENSER (OPTIONAL) You can easily obtain chilled water with the water dispenser without opening the refrigerator door. In addition, you can save electricity by reducing the number of times the door is opened by more than 30%. Overview Press lever Locking device... - Page 13 INSTALLING A REGULAR BOTTLE Press the fixing lever, lift the exclusive water tank upwards, then remove it. Remove the water supply device from the exclusive water tank, then set the inner groove of the water supply device in a regular spring water bottle and fix it in position by turning it.
-
Page 14: Removing And Cleaning Accessories
REMOVING AND CLEANING ACCESSORIES Before cleaning the appliance, you must always switch it off and unplug it from the wall socket. Do not use a steam cleaner. Hot steam could damage the surface of the appliance or the electrical components, with a risk of electric shock. Ice cube maker •... -
Page 15: Cleaning The Water Dispenser
CLEANING THE WATER DISPENSER Dispenser Tray Using the dispenser tray handle, pull the dispenser tray right out. Empty the water in the dispenser tray, then clean it using warm water and detergent. Dispenser tray Connection path Wipe over the connection path and surrounding area with a clean damp cloth. -
Page 16: Replacing Interior Lights
REPLACING INTERIOR LIGHTS INDOOR LAMP IN THE REFRIGERATOR Always unplug the appliance when replacing the refrigerator light. Otherwise, there is the danger of electric shock. Unscrew the cover with a philips-head screwdriver. - Fluorescent light • Remove the interior light by pulling it downward, then replace it with a new one. -
Page 17: Problems And Solutions
PROBLEMS AND SOLUTIONS The appliance is not operating at all or the temperature is too high • Check that the power plug is correctly connected. • Is the temperature control on the front panel correctly set? • Does sun shine on the appliance or are there heat sources nearby? •... -
Page 18: Usage Precautions
USAGE PRECAUTIONS Store food with a high water content at the Store hot food in the appliance only after it front of a refrigerator shelf. has cooled. • If you store cold food, you save on electricity and improve refrigeration. Tips Power Saving Tips •... -
Page 19: View Of Your Refrigerator / Freezer
VIEW OF YOUR REFRIGERATOR / FREEZER REFRIGERATOR LIGHT REFRIGERATOR MULTI-PURPOSE GUARD REFRIGERATOR SHELVES BOTTLE GUARD FRESH SALAD DRAWER WATER DISPENSER TWIST ICE MAKER AND ICE (OPTIONAL) STORAGE BIN FREEZER FREEZER DRAWER FREEZER LIGHT... - Page 20 MEMO...
- Page 21 MEMO...
- Page 22 Business users should contact their supplier and check the terms and conditions of the purchase contract. This product should not be mixed with other commercial wastes for disposal. If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
