- Page 1 Installation Instructions If you have questions, call 800-GE-CARES or visit our website at: www.GEAppliances.com Built-In Dishwashers PDW8000, PDW8060 Design Guide with Installation Instructions GE Appliances...
-
Page 2: Table Of Contents
Prepare Hot Water Line ..........8 Step 12, Pre-Test Check List ........13 Custom Panel Dimensions Step 13, Dishwasher Wet Test ........13 Custom Panels for PDW8000 ........9 Step 14, Secure Dishwasher to Cabinet or Countertop ........14 Step 15, Install Toekick ..........14... -
Page 3: Design Information
• Models with 3/4" thick custom door panel will fit flush with adjacent cabinetry. Traditional Built-In PDW8000 BB, Black - Accepts 1/4" or 3/4" custom Supplied or Custom Toekicks panels • A 2-piece toekick is supplied with all models. The PDW8000 WW White - Accepts 1/4"... -
Page 4: Installation Preparation
Installation Preparation MATERIALS YOU WILL NEED: Materials Required for All Installations Screw Type Clamps 90° Elbow (3/8”NPT external thread on one end, opposite 90° Elbow end sized to fit water supply) Note: Use new ferrule. Do not use old parts. Strain relief for electrical connection Thread seal tape Strain Relief... -
Page 5: Parts Supplied
Installation Preparation PARTS SUPPLIED: Remove the hardware accessory bag and other parts from inside or taped to the outside of the dishwasher. Check contents against illustrations to insure that all parts are included. 2-piece toekick 6 screws (see illustration) 2 leveling legs Junction Box Cover Junction box cover... -
Page 6: Drain Requirements
Installation Preparation DRAIN REQUIREMENTS Method 1 – Air Gap with Waste Tee or Disposer • Follow local codes and ordinances. An air gap must be used when the waste tee or disposer connection is less than 18” from the floor. •... -
Page 7: Prepare Electrical Wiring
Installation Preparation PREPARE ELECTRICAL WIRING FOR PERSONAL SAFETY: Remove Alternate house fuse or open circuit breaker Receptacle before beginning installation. Do not use Location an extension cord or adapter plug with 18" this appliance. 1-1/2" Dia. Hole (Max.) Receptacle Location 18"... -
Page 8: Prepare Hot Water Line
Installation Preparation PREPARE HOT WATER LINE The line may enter from either side, rear or floor within the shaded area shown. • The water line may pass through the same hole as the electrical cable and drain hose. Or, cut an additional 1-1/2"... -
Page 9: Custom Panel Dimensions
Custom Panel Dimensions 3/4" PANEL WITH ZPF675 TRIM KIT CUSTOM PANEL FOR MODELS PDW8000 The custom panel size varies depending on your installation. Panel kits must be ordered separately. Installation of any custom panel should be completed before Custom the dishwasher is installed. -
Page 10: Installation Instructions
Installation Instructions STEP 3 REMOVE ACCESS COVER BEFORE YOU BEGIN: CUSTOM PANEL INSTALLATION: If you intend to install custom door panels, (on some models) refer to trim kit installation instructions. Custom panels should be in place before installing the dishwasher. Insulation Board STEP 1 REMOVE PACKAGING Cut the shipping carton and use it as a pad beneath the... -
Page 11: Step 5 Install Power Cord
Installation Instructions STEP 5 INSTALL POWER CORD STEP 7 SLIDE DISHWASHER INTO OPENING SKIP THIS STEP IF DISHWASHER WILL BE DIRECT WIRED DO NOT PUSH AGAINST THE FRONT PANEL WITH • Maximum power cord length is 6 ft. KNEES, DAMAGE WILL OCCUR! •... -
Page 12: Step 9 Connect Drain Line
Installation Instructions STEP 9 CONNECT DRAIN LINE STEP 10 CONNECT ELECTRICAL FOLLOW ALL LOCAL CODES AND ORDINANCES. FOR DIRECT WIRE ONLY (If a power cord with plug is used, plug it into the wall • The dishwasher is supplied with a 72" long drain hose. outlet and continue with next step.) •... -
Page 13: Step 11, Position And Level Dishwasher
Installation Instructions STEP 11 POSITION AND LEVEL THE DISHWASHER • Check to be sure the dishwasher is adjusted to correct Door Rub Door Rub height and is centered in the cutout. On Right On Left • Open and close the door to insure proper operation of Hand Side Hand Side the door. -
Page 14: Step 14 Secure Dishwasher
Installation Instructions STEP 14 SECURE DISHWASHER STEP 15 INSTALL TOEKICK TO CABINET AND • Loosen depth adjustment screws inside the bracket. COUNTERTOP • Slide bracket out to proper depth. To maintain position and alignment, it is recommended Tighten screws. the dishwasher be secured to the countertop and •... -
Page 15: Step 16, Install Side Filler Strips
Installation Instructions STEP 16 ADJUST SIDE FILLER STRIPS • Open the door fully. • Loosen (but do not remove) screws holding the top and side trims. • Adjust trim to cover opening gap. Tighten screws. Adjust Side Trim to Meet Cabinetry Loosen Screws... - Page 16 Note: While performing installations described in this book, safety glasses or goggles should be worn. Note: Product improvement is a continuing endeavor at General Electric. Therefore, materials, appearance and specifications are subject to change without notice. 0616 400 350 Pub. No. 31-30545 Dwg.
