Motorschutzplatte/ Skid plate
BMW F 850 GS Adventure
2019-2020
6520
810
00 12
alu
BMW F 750 GS
2018-2020
6512
810
00 12
INHALT
CONTENT
1x 700010224 Motorschutzplatte
1x 700010225 Halter hinten
1x 700010227 Halter vorne
1x 700010228 Schraubensatz:
4x Zylinderschraube ISK M6x16
2x Zylinderschraube ISK M6x35
2x Zylinderschraube ISK M8x45
2x Zylinderschraube ISK M6x50
1x Zylinderschraube ISK M8x16
6x Linsenschraube M8x20
4x Selbstsichernde Mutter M6
10x U-Scheibe Ø8,4
4x Karosseriescheibe Ø6,4xØ18
2x AludistanzØ15xØ9x30
2x AludistanzØ18xØ9x25
2x AludistanzØ13xØ7x16
2x Schutzstreifen
1x Logo H&B
BMW F 850 GS
2018-2020
810
alu
6513
00 12
alu
1x 700010224 Skid plate
1x 700010225 Adapter rear
1x 700010227 Adapter front
1x 700010228 Screw kit:
4x allen screw M6x16
2x allen screw M6x35
2x allen screw M8x45
2x allen screw M6x50
1x allen screw M8x16
6x filister head screw M8x20
4x self lock nut M6
10x washer Ø8,4
4x body washer Ø6,4xØ18
2x alu spacer Ø15xØ9x30
2x alu spacer Ø18xØ9x25
2x alu spacer Ø13xØ7x16
2x plastic protective strips
1x emblem H&B
1
