- Page 1 SKU# NB19839, NB19840 MONTAUK OVAL 52-IN DEEP HYBRID POOL WITH 7-IN TOP RAIL INSTRUCTION MANUAL Questions, problems, missing parts? Before returning to your retailer, call our Consumer Hotline at 1-800-759-0977, Monday – Friday. 8am – 5pm (CST) V1: 042021...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INSTRUCTIONS ....................4 GENERAL WATER SAFETY ........................5 ADDITIONAL POOL AND WATER SAFETY GUIDELINES ..............6 MONTAUK OVAL STYLE POOL - PARTS LIST ..................7 SELECTING A SUITABLE SITE ........................9 POOL SETUP .............................. 10 LEVELING THE AREA ..........................11 POOL WALL AND SIDE FRAME SUPPORT ASSEMBLY ................ -
Page 3: Thank You
THANK YOU! Thank you for purchasing this product. We work around the clock and around the globe to ensure that our products maintain the highest possible quality. However, in the rare case of issues during assembly or use of this product, please contact our Consumer Hotline at 800-759-0977 for immediate assistance before contacting your retailer. -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Please examine equipment before use. If there are any damaged or missing parts at the time of purchase, do not assemble or operate until parts are replaced. To lessen the risk of serious injury or death, follow these rules. The following instructions contain important safety information, please read these important safety instructions and abide by them when installing and using this pool. -
Page 5: General Water Safety
GENERAL WATER SAFETY • Always supervise children around water. • Ensure a pool fence is correctly installed and functioning if it is required by your local municipality or state code. • Follow all local and National Pool Safety Codes. • Learn CPR and keep in practice. •... -
Page 6: Additional Pool And Water Safety Guidelines
ADDITIONAL POOL AND WATER SAFETY GUIDELINES • Name only one safety supervisor when people are in the pool. • Reinforce supervision when there are several users in the swimming pool. Have personal flotation aids available (for people who cannot swim). •... -
Page 7: Montauk Oval Style Pool - Parts List
MONTAUK OVAL STYLE POOL - PARTS LIST (Not to scale) Check all parts and ensure they are present and undamaged before assembly. Images and objects may differ. Report missing or damaged parts immediately to have them replaced. For damaged or replacement parts, contact Blue Wave Customer Service at (800)759-0977. - Page 8 MONTAUK OVAL STYLE POOL - PARTS LIST continued BW No. Parts Description MFG No. 24-ft x 12-ft x 52-in 30-ft x 15-ft x 52-in NBP6089 STEEL BELT 22001010 NBP6090 PVC SLEEVE 22001011 NBP6091 SIDE BOTTOM METAL PIECE A 22001012 NBP6092...
-
Page 9: Selecting A Suitable Site
SELECTING A SUITABLE SITE Carefully select the site for your new pool. This is the most important decision to ensure the safety and success of your pool’s construction. An incorrect site could cause problems in the future that may result in injury, death, or financial loss. Carefully read the check list below when selecting your site. Acceptable: Tools and Materials Required: •... -
Page 10: Pool Setup
POOL SETUP POOL SITE PREPARATION Remember ground preparation is the most important step in the installation of the pool. Do not install the pool over underground power lines, sewer lines, or other structures. Do not install on cement, asphalt, or other hard surfaces. 1. -
Page 11: Leveling The Area
LEVELING THE AREA WARNING! Leveling is extremely important: take as much time as necessary to ensure the pool site is completely fi rm and leveled. • WARNING: The pool contains thousands of gallons of water. Should the pool collapse due to unleveled ground, it could cause signifi cant property damage and even result in injury or death. -
Page 12: Pool Wall And Side Frame Support Assembly
POOL WALL AND SIDE FRAME SUPPORT ASSEMBLY • Once you have the ground preparation completed you can proceed with the frame and wall assembly and installation step. Follow each step and complete it carefully before moving on to the next step. NOTE: Some diagrams may look different from your pool structure. -
Page 13: Pool Wall Rail And Rail Connector Setup
POOL WALL AND SIDE FRAME SUPPORT ASSEMBLY continued • Connect the steel belt to either end of the left and right side pool frames (see diagram 11 and 12). Make sure the steel belt is protected by the PVC sleeve which is provided in the package. This will protect the pool liner from damage. - Page 14 POOL WALL RAIL AND RAIL CONNECTOR SETUP continued 5. Place the bottom metal pieces between the joins of the rails with the triangular end pointing out from the pool wall (see diagram 17). 6. Place the inside bottom protector over the steel belt and screw into the horizontal side beam. NOTE: Ensure the PVC sleeve covers the steel belt to prevent damage or rust effecting the pool (see diagram 18).
- Page 15 POOL WALL RAIL AND RAIL CONNECTOR SETUP continued Stop at this point to make sure you have the wall cut outs where you want them. 9. On the opposite side of the pool wall, carefully lift and place the steel wall in between the side support frame and the inside bottom protector.
-
Page 16: Measuring The Level And Shape Of The Pool Wall
MEASURING THE LEVEL AND SHAPE OF THE POOL WALL • WARNING: A pool that is not level is very dangerous and may collapse at any time. • Check the pool wall level by placing a 2-in x 4-in board or similar across the diameter of the pool wall and placing a level on the top of the board. -
Page 17: Protective Sand Cushion
PROTECTIVE SAND CUSHION Making a Protective Sand Cushion at the Foot of the Inner Pool Wall (Diagram 26) (Diagram 27) ATTENTION: THIS IS A CRITICAL STEP THAT WILL PREVENT THE LINER FROM BEING FORCED OUT UNDER THE WALL, TEARING, AND RELEASING THOUSANDS OF GALLONS OF WATER INTO THE YARD. -
Page 18: Installing The Pool Liner
INSTALLING THE POOL LINER These instructions only apply to overlap liner installation. Follow the liner manufacturer’s instructions for other style liners. IMPORTANT: Only attempt to install the liner on a warm and sunny day, preferably above 72 °F (22° C). Unfold the liner and put it in the sun for 2 hours. This helps to soften the liner. If the temperature is below 60°... - Page 19 INSTALLING THE POOL LINER continued • Remove the clothes pins one at a time while applying the fix rail coping and the round top rails (see diagram 32). Slide the rail connectors into one end of the top rail, then connect another top rail and continue around the oval until all top rails are joined together.
-
Page 20: Installing The Top And Side Metal Plate
INSTALLING THE TOP AND SIDE METAL PLATE • Hook the top metal piece over the top of the rail between the rail connections and align with the bottom metal piece (see diagram 33). The first metal piece should be placed on top and in the middle of the pool wall joint. -
Page 21: Installing The Curved And Straight Side Top
INSTALLING THE CURVED AND STRAIGHT SIDE TOP LEDGE • Place the three side top ledges on top of the rails and align the holes over the side top metal piece. Using four bolts, washers, and spring washers, attach the side top ledge to the side top metal piece and hand tighten. -
Page 22: Installing The Curved And Straight Side Top Ledge
INSTALLING THE CURVED AND STRAIGHT SIDE TOP LEDGE • Continue this process until all of the top and side top ledges are attached to all of the top and side metal pieces (see diagram 34, 35 and 36). Check the alignment but do not tighten. (Diagram 35) (Diagram 36) 1, 2, 6 AND 7 TOP LEDGE AS SHOWN IN DIAGRAM 34... - Page 23 ASSEMBLY OF THE VERTICAL SUPPORTS continued • Fix the vertical support onto the top and bottom metal piece and hand screw into place. Continue this process around the pool until all of the vertical supports are attached. Check and adjust the alignment of the vertical supports to ensure that they are indeed vertical and straight.
-
Page 24: Checking All Connections And Joints
CHECKING ALL CONNECTIONS AND JOINTS • Once completed, check all connections and tighten loose screws and bolts, but do not over tighten. • Replace damaged components and repair all tears, rips, and holes with repair patch (see diagram 42). (Diagram 42) INSTALLING THE SKIMMER •... -
Page 25: Filling The Pool With Water
FILLING THE POOL WITH WATER • Before filling the pool with water, thoroughly check to see if there are any loose screws not tightened during the pool frame installation process. Also, check for holes or tears in the liner. • Fill the pool until the water is halfway up the skimmer opening or a minimum of 6-in (15-cm) from the top of the pool wall (see diagram 43). -
Page 26: Safety Warnings
SAFETY WARNINGS • Install all safety warning decals and signs included with the pool. • The fi lter pump must be turned off when there are swimmers in the pool! WARNING DECALS TOP LEDGE DECALS: Round pools require three (3) of these warning labels (see diagram 44). -
Page 27: Pool Maintenance
POOL MAINTENANCE 1. Keep the pool clean and maintain proper water chemistry by applying the correct pool chemicals. Unsanitary water is a serious health hazard. 2. Maintain pool pH level between 7.2 to 7.6. 3. Carefully follow the installation and other instructions in the filtration system manual. 4. -
Page 28: Montauk Pool Warranty
MONTAUK POOL WARRANTY Warranties for the skimmer, ladder, liner, and filter system are found in their respective installation manuals. Twenty-Five Year Prorated Limited Warranty IMPORTANT Carefully read and apply all safety warnings, cautions, and instructions detailed in the installation manual and the safety and warning package that came with the pool. - Page 29 Year 16-Year 30 80% of List Price WARRANTY VALIDATION AND PROCEDURE TO START A WARRANTY CLAIM: • The pool warranty must be registered with the local retailer or Blue Wave Products within 30 days of the ® date of purchase. The warranty registration form is located in your safety and warning package.
