AIR CONDITIONER
SPLIT-TYPE AIR CONDITIONER
INDOOR UNIT
Model Code:
AR18NSWXCWKNCV
AR24NSWXCWKNCV
Basic Code:
CONTENTS
1.Precautions
2. ProduP c t
ations
3. Alignment and Adjustments
4. Disassembly and Reassembly
5. Assy Control
6. Electrical Parts List
7. Wiring Diagram
8. Schematic Diagram
9. Operating Instructions
10. Troubleshooting
11. Block Diagram
12. Reference Sheet
OUTDOOR UNIT
AR18NSWXCWKXCV
AR24NSWXCWKXCV
