ASSEMBLY INSTRUCTIONS
ASSEMBLY RATING
The Assembly Rating is a 5-point
system that shows the degree of effort
needed in assembling a specific
product (with 1 being easy and 5 being
difficult). For most products, two
persons are recommended.
EASY
YNJ-15413C5-TV
DIFFICULT
Page 1
E-commerce-Enitial Lab
Tools Required for Assembly
Allen Wrench
Phillips Screwdriver
2 PERSON RECOMMENDED
( Included)
(Not Included)
(Not Included)
17.01.07
Advertisement
Related Manuals for Furniture of America YNJ-15413C5-TV
Summary of Contents for Furniture of America YNJ-15413C5-TV
- Page 1 E-commerce-Enitial Lab ASSEMBLY INSTRUCTIONS YNJ-15413C5-TV ASSEMBLY RATING Tools Required for Assembly The Assembly Rating is a 5-point system that shows the degree of effort Allen Wrench ( Included) needed in assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase.
- Page 3 Page 3...
- Page 4 PRE-ASSEMBLY INTRODUCTION Unless you are particularly adept at assembling flat-pack/knock-down furniture, we understand building ready-to-assemble furniture can be a frustrating experience for some. To help avoid confusion and to make the assembly process quicker and smoother, we have provided some helpful tips.
- Page 5 CAM LOCK FASTENER ASSEMBLY INSTRUCTIONS Note:Every cam lock bolt must have a cam lock connector in order to fasten the parts together. Secure the threaded end of the cam bolt by using a screwdriver Align the cam connector with its side opening (or arrow) pointing to the small Turn right (clockwise) to tighten.
- Page 6 TV STAND ASSEMBLY INSTRUCTIONS MODEL # YNJ-15413C5-TV Please keep for future reference PARTS LIST Before you begin, please read "Assembly and Care Advice","Pre- Assembly Introduction" and "Cam Lock Fastener Assembly Instructions" DIMENSIONS 70.87" (W) X15.75" (D) X19.29" (H) 2PCS 2PCS...
- Page 7 ASSEMBLY INSTRUCTIONS STEP1 Hardware #1=10pcs Hardware #3=8pcs Hardware #5=2pcs Page 7...
- Page 8 ASSEMBLY INSTRUCTIONS STEP2 Hardware #1=2pcs Hardware #3=4pcs Hardware #6=4pcs Hardware #7=8pcs Hardware #8=2pcs Hardware #9=4pcs These screws are a little bit bigger 這幾個螺絲比例有點大， then the other small screws. 可以縮小一點 hole usage The darkened holes are the holes for the screws. Page 8...
- Page 9 ASSEMBLY INSTRUCTIONS STEP3 Hardware #2=2pcs Hardware #10=12pcs Connect "C" and "M" to "B" by 請補上木栓 using the wood dowels. Insert wood dowels on the bottom hole of "B". Page 9...
- Page 10 ASSEMBLY INSTRUCTIONS STEP4 Hardware #2=4pcs Hardware #4=6pcs Page 10...
- Page 11 ASSEMBLY INSTRUCTIONS STEP5 Hardware #2=6pcs Insert wood dowels on the red circle in the picture. Page 11...
- Page 12 ASSEMBLY INSTRUCTIONS STEP6 Hardware #3=5pcs Hardware #4=17pcs Hardware #13=5pcs Page 12...
- Page 13 ASSEMBLY INSTRUCTIONS STEP7 Hardware #7=8pcs Hardware #11=12pcs Hardware #12=12pcs hole usage The darkened holes are the holes for the screws. Make sure the product is rested on a flat surface and does not feel loose or wobbly. If it does, double check that the bolts/screws are secured and properly tightened.
