- Page 1 TOOLS REQUIRED Phillips Screwdriver (Not Included) Hammer (Not Included) 2 - Persons Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product. 1 / 16...
- Page 2 2 / 16...
- Page 3 3 / 16...
-
Page 4: Care Advice
ASSEMBLY CARE ADVICE FAILURE TO FOLLOW THE GUIDELINES BELOW MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. Position each part correctly Turn clockwise to tighten and and insert screws or bolts into only tighten when step is their respective holes. completed or when instructed to do so. - Page 5 5 / 16...
- Page 6 CONSOLE TABLE PARTS 2PCS 2PCS HARDWARE ACCESSORIES 2PCS 4PCS 17PCS 17PCS 11PCS 16PCS 2PCS 4PCS 5PCS 0.87" 1.97" 0.67" 2PCS 2PCS 4PCS 4PCS 24PCS 2PCS 8PCS 0.39" 0.47" 0.47" 4PCS 4PCS 4PCS 4PCS 4.01" 0.75" 6 / 16...
-
Page 7: Get Ready
GET READY Please group boards as below. 2PCS 2PCS Body 7 / 16... - Page 8 Hardware x16PCS Hardware x2PCS Hardware x2PCS Hardware x4PCS OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 8 / 16...
- Page 9 Hardware x1PC Hardware x9PCS Hardware x2PCS Hardware x2PCS Accessory x2PCS Accessory x4PCS OPTIONAL Apply a dab of glue into dowel holes of panels before inserting dowels (#3). 9 / 16...
- Page 10 Front Part x2PCS Part x1PC Part x1PC Hardware x8PCS Accessory x1PC Front Part x1PC Part x2PCS Front OPTIONAL 10 / 16...
- Page 11 Front Part x1PC Hardware x2PCS Hardware x4PCS Accessory x1PC Please refer to page 5 for detailed instructions on how to fasten cam locks (#2) to cam bolts (#1). Part x1PC Part x1PC Front Hardware x7PCS Hardware x2PCS Accessory x5PCS Accessory x1PC 11 / 16...
- Page 12 Hardware x4PCS Hardware x12PCS Front Front Part x1PC Part x1PC Hardware x2PCS Accessory x1PC 12 / 16...
- Page 13 Part x1PC Hardware x6PCS Front Accessory x4PCS Use the provided stickers (#A5) to cover exposed locks. 13 / 16...
- Page 14 Part x1PC Part x1PC Hardware x12PCS Hardware x2PCS Hardware x8PCS Front 14 / 16...
- Page 15 Part x1PC Hardware x2PCS Hardware x4PCS Hardware x4PCS Accessory x1PC Front Hardware x4PCS Hardware x4PCS Front Insert fixative plates (#15) through the thin lined gaps between back and side panels, then secure by using screws (#16). [ No pre-drilled holes ] 15 / 16...
- Page 16 ASSEMBLY COMPLETED Please ensure the furniture rests on an even and flat surface. If the produst wobbles or feels loose,double-check all bolts and/or screws are properly tightened and secured. Keep this handy! Please retain this instruction manual and any order-related information for future reference.
