MICROWAVE OVEN
INSTRUCTION MANUAL
Model: FMO09AHTBKD
Read these instructions carefully before using your
microwave oven, and keep it carefully. If you follow
the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMO09AHTBKD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Farberware FMO09AHTBKD

Summary of Contents for Farberware FMO09AHTBKD

  • Page 1 MICROWAVE OVEN INSTRUCTION MANUAL Model: FMO09AHTBKD Read these instructions carefully before using your microwave oven, and keep it carefully. If you follow the instructions, your oven will provide you with many years of good service. SAVE THESE INSTRUCTIONS CAREFULLY...
  • Page 2 Farberware is a registered trademark of Farberware Licensing Company, LLC Manufactured and sold pursuant to a license from Farberware Licensing Company, LLC © 2018 Farberware Licensing Company, LLC. All rights reserved.

  • Page 3: Table Of Contents

    Tables of Contents PRECAUTIONS....………………………………………….……….. 4 SPECIFICATIONS……………………………………………………..…..… 4 SAFETY………………………………………………………………………..…. GROUNDING………………………………………………………….……..6 UTENSILS………………………..............8 SETTING UP YOUR OVEN……………............10 CONTROL PANEL………………………………......... 12 OPERATION………………………………..........13 MAINTENANCE……………………………………………………………….. 19 WARRANTY INFORMATION.……………………………………………….. 20...

  • Page 4: Precautions

    (1) DOOR (bent) (2) HINGES AND LATCHES (broken or loosened) (3) DOOR SEALS AND SEALING SURFACES (d) The oven should not be adjusted or repaired by anyone except properly qualified service personnel SPECIFICATIONS Model: FMO09AHTBKD Rated Voltage: 120V~60Hz Rated Input Power(Microwave): 1350W Rated Output Power(Microwave): 900W Oven Capacity:...
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS When using electrical appliances basic safety precautions should be followed, including the following: WARNING – To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1. Read all instructions before using the appliance. 2. Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found on page 4. 3. This appliance must be grounded. Connect only to properly grounded outlet. See “GROUNDING INSTRUCTIONS” found on page .

  • Page 6: Grounding

    17. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.

  • Page 7: Safety

    1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord. 2. Longer cord sets or extension cords are available and may be used if care is exercised in their use. 3.

  • Page 8: Utensils

    7. Do not cook bacon directly on the turntable. Excessive local heating of the turntable may cause the turntable to break. 8. Do not heat baby bottles or baby food in the microwave oven. Uneven heating may occur and could cause physical injury. 9.
  • Page 9 MATERIALS YOU CAN USE IN MICROWAVE OVEN Utensils Remarks Browning dish Follow manufacturer* instructions. The bottom of browning dish must be at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause the turntable to break. Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped dishes.

  • Page 10: Setting Up Your Oven

    MATERIALS TO BE AVOIDED IN MICROWAVE OVEN Utensils Remarks Aluminum tray May cause arcing. Transfer food into microwave-safe dish. Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish. Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
  • Page 11 Turntable Installation a. Never place the glass tray upside down. Hub (underside) The glass tray should never be restricted. b. Both glass tray and turntable ring assembly Glass tray must always be used during cooking. c. All food and containers of food are always placed on the glass tray for cooking. d.

  • Page 12: Control Panel

    CONTROL PANEL Time Cook Time Defrost Weight Defrost Power (10 power levels available) Clock Kitchen Timer Auto Cook Menu (Popcorn, Potato, Pizza, Frozen Vegetable, Beverage, Dinner Plate) Number Pad (0-9) Express Cook (Number Pad 1-6) (10) START/ 30 SEC. (Begin cooking time or add time to cooking) (11) Stop/CANCEL (Before cooking starts, press to clear all previous settings;...

  • Page 13: Operation

    OPERATION 1. POWER LEVEL 10 power levels are available. Level Power 100% Display PL10 2. CLOCK SETTING (1) Press “Clock“ , “00:00” will display. (2) Press the number keys and enter the current time. For example, time is 10:12 now, please press “1,0,1,2” in turn. (3) Press “Clock“ to finish clock setting. “:” will flash and the clock will be lighted. (4) If the numbers input are not within the range of 1:00--12:59, the setting will be invalid until valid numbers are input.
  • Page 14 Note: 1. In the process of setting, if the “STOP/CANCEL“ button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically. 2. You can skip the step of “c” and cook at 100% microwave power. 4. KITCHEN TIMER (1) Press “Kitchen Timer “ once, the screen will display 00:00. (2) Press the number keys and enter the timer time. (The maximum cooking time is 99 minutes and 99 seconds.) START/ 30sec.
  • Page 15 (2) If not ready cooking, press number pads 1-6 to quickly cook from 1-6 minutes at 100% power. “ “ Press " " " " START/ 30sec. to increase the cooking time; the maximum cooking time is 99 minutes and 99 seconds. Note: During microwave cooking, time defrost , time can be added by pressing START/ 30sec.
  • Page 16 10. BEVERAGE (1) Press “BEVERAGE“ repeatedly until the number you wish appears in the display, “1”,”2”,”3” cup will display in order. One cup is about 120ml. For example, press “BEVERAGE” once, “1” appears. (2) Press “START/ 30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five times and then turns back to waiting state. 11. PIZZA REHEAT (1) Press “PIZZA“ repeatedly until the number you wish appears in the display, “4.0”,”8.0”,”14.0”Oz will display in order. For example, press “PIZZA“ once, “4.0” appears. (2) Press “START/ 30SEC.“ to cook, buzzer sounds once. When cooking finish, buzzer sounds five times and then turns back to waiting state. 12.
  • Page 17 15. MEMORY FUNCTION (1) Press “0/MEMORY” to choose memory 1-3 procedure. The screen will display 1,2,3. (2) If the procedure has been set, press to use it. If not, continue to set “START/ 30SEC.“ the procedure. Only one or two stages can be set. once save (3) If the procedure has not been set, after finishing the setting, press “START/ 30SEC.“ procedure and turn back to the waiting states. If press it will start “START/ 30SEC.“ cooking at once and save the procedure too. Example: To set the following procedure as the second memory, that is memory 2. To cook the food with 80% microwave power for 3minutes and 20 seconds.
  • Page 18 17. INQUIRING FUNCTION In the microwave cooking state, press “POWER“ to inquire microwave power level, and the current microwave power will be displayed. After three seconds, the oven will turn back to the previous state. In multi-stage state, the inquiring way can be done by the same way as above. “ In the microwave cooking state, press CLOCK“...

  • Page 19: Maintenance

    MAINTENANCE Troubleshooting Check your problem by using the chart below and try the solutions for each problem. If the microwave oven still does not work properly, contact the nearest authorized service center. Trouble Possible Cause Possible Remedy Oven will not a.

  • Page 20: Warranty Information

    ONE YEAR LIMITED WARRANTY This warranty applies to products purchased and used in the U.S. and Canada. This is the only expressed warranty for this product and is in lieu of any other warranty or condition. This product is warranted to be free from defects in material and workmanship for a period of one (1) year from the date of original purchase.
