- Page 1 Assembly Instructions CORNER WRITING DESK (LB-DUR-CD44) Questions, problems, missing parts? Before returning to the store call Customer Service Time available: 8:00 am - 5:00 pm PST 1-888-552-0592 Hotline: Thank you for choosing E-Ready Furniture. 1 of 10...
-
Page 2: Getting To Know Your Product
Assembly Instructions Getting to know your product Part List: Description Quantity Description Quantity Part Part Wooden top Wooden shelf Keyboard drawer Top front stretcher Left side frame Top left stretcher Right side frame Top right stretcher Left post Bottom side stretcher Right post Crossed stretcher Hardware List:... - Page 3 Assembly Instructions Two persons are recommended for assembly. Unpack the inventory parts on a soft and smooth surface. Do not use power tools. Do not overtighten any connectors. A Philips head screwdriver is required (not included) for the assembly. To remove the drawer from the case: Press up or down on the back levers in the metal drawer glides located on each side of the drawer.
- Page 4 Assembly Instructions Step 1 CONNECT TOP LEFE STRETCHER (9),BOTTOM SIDE STRETCHER(11) AND LEFT POST(5) TO THE LEFT SIDE FRAME(3) WITH ALLAN HEAD BOLT(H3),FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6). DO NOT TIGHTEN CONNECTIONS UNTIL AFTER STEP 4 Step 2 CONNECT TOP RIGHT STRETCHER (10),BOTTOM SIDE STRETCHER(11) AND RIGHT POST(6) TO THE RIGHT SIDE FRAME(4) WITH ALLAN HEAD BOLT(H3),FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6).
- Page 5 Assembly Instructions Step 3 CONNECT WOODEN SHELF(7) TO THE ASSEMBLED LEFT SIDE PART( STEP 1) WITH ALLAN HEAD BOLT(H2),FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6). 5 of 10...
- Page 6 Assembly Instructions Step 4 CONNECT TOP FRONT STRETCHER (8) TO THE ASSEMBLED LEFT & RIGHT PARTS( STEP 1&2) WITH ALLAN HEAD BOLT(H3),FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6), AFTER THAT CONNECT THE SHELF(7) TO RIGHT ASSEMBLED PART WITH ALLAN HEAD BOLT(H2),FLAT WASHER(H4), BY TURNING ALLEN WRENCH(H6).TIGHTEN ALL BOLTS.
- Page 7 Assembly Instructions Step 5 CONNECT KEYBOARD DRAWER(2) TO THE BOTTOM OF THE WOODEN TOP(1) WITHALLAN HEAD BOLT(H1),FLAT WASHER(H4),SPRING WASHER(H5),BY TURNING ALLEN WRENCH(H6). THEN TIGHTEN 7 of 10...
- Page 8 Assembly Instructions Top front stretcher Step 6 CONNECT THE TABLE TOP TO THE ASSEMBLED FRAME WITH ALLAN HEAD BOLT(H2), FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6). THEN TIGHTEN 8 of 10...
- Page 9 Assembly Instructions Step 7 CONNECT CROSSED STRETCHER(12) TO THE FIXED TABLE WITH ALLAN HEAD BOLT(H2), FLAT WASHER(H4),BY TURNING ALLEN WRENCH(H6) AND TIGHTEN 9 of 10...
- Page 10 Assembly Instructions Corner writing desk hutch Corner writing desk ADJUSTABLE LEVER 10 of 10...
