- Page 1 Assembly Instructions EMERY TV STAND61”(ER-EME-ETV61) Questions, problems, missing parts? Before returning to the store call Customer Service Time available: 8:00 am - 5:00 pm PST 1-888-552-0592 Hotline: Thank you for choosing E-Ready Furniture. 1 of 12...
-
Page 2: Getting To Know Your Product
Assembly Instructions Getting to know your product Part List: Description Quantity Description Quantity Description Quantity Part Part Part Side Panel Assembly Side Frame Wooden Top Middle Frame Wooden Shelf Door Dack Panel Metal Stretcher Wooden Shelf Movable Shelf Crossed Stretcher Bottom Shelf Hardware Kit (Part 13): NOTE: Hardware not shown to actual size. - Page 3 Assembly Instructions Step 1 CONNECT BOTTOM SHELF (4) TO SIDE & MIDDLE METAL FRAME (9) & (10). Step 2 SLIDE THE METAL STRETCHER (11) INTO THE MIDDLE FRAME (10) ON ASSEMBLY POSITION. 3 of 12...
- Page 4 Assembly Instructions Step 3 CONNECT SIDE FRAME TO BOTTOM SHELF (4) WITH (H3) & (H1),CONNECT METAL STRETCHER (11) TO MIDDLE FRAME WITH (H3) & (H2),THE FIXED WITH SHELF (4) WITH (H1) (H3),BY TURNING ALLEN WRENCH (H12) UNTIL TIGHT. 4 of 12...
- Page 5 Assembly Instructions Step 3 CONNECT SIDE PANEL (5) TO BOTTOM SHELF (4) WITH CAM & LOCK (H5) (H6) BY SCREWDRIVER. 5 of 12...
- Page 6 Assembly Instructions Step 5 CONNECT BACK PANEL (7) BETWEEN SIDE PANEL (5) THEN FIXED TO MIDDLE FRAME (10) WITH (H12) BY ALLEN WRENCH (H12). Step 6 PUT THE WOODEN SHELF (3) INTO THE FIXED METAL FRAME. 6 of 12...
- Page 7 Assembly Instructions Step 7 INSTALL (H5) ON WOODEN SHELF (2), THEN PUT IT INTO THE FIXED FRAME. 7 of 12...
- Page 8 Assembly Instructions Step 8 USE THE CAM (H6) CONNECT THE SHELF (H6) & SIDE PANEL (H5) AND TIGHTEN BY SCREWDRIVER, CONNECT THE WOODEN SHELF (2) TO THE FIXED METAL FRAME WITH (H3) (H1) BY ALLEN WRENCH (H12). 8 of 12...
- Page 9 Assembly Instructions Step 9 CONNECT (11) ON MIDDLE METAL FRAME (10) WITH (H3) (H2) BY ALLEN WRENCH (H12) TO TIGHTEN, PUT THE WOODEN TOP (1) INTO THE FIXED PARTS. 9 of 12...
- Page 10 Assembly Instructions Step 10 INSTALL THE SHELF SUPPORTS (H7) BY HAND, PUT THE MIDDLE WOODEN SHELF (8) ONTO THE SUPPORTS. 10 of 12...
- Page 11 Assembly Instructions Step 11 INSTALL THE HANDLE (H9) ON WOODEN DOOR (6) WITH (H8) BY SCREWDRIVER. CONNECT DOORS TO THE FIXED PARTS WITH (H11) & (H4) BY SCREWDRIVER. 11 of 12...
- Page 12 Assembly Instructions Step 12 CONNECT (12) TO THE FIXED PARTS FROM BACK WITH (H3) (H2) BY ALLEN WRENCH (H12) TO TIGHTEN. 12 of 12...
