Please read this manual first for correct installation and operation. This manual should be retained
for future reference. The information in this manual was current when published. The
manufacturer reserves the right to revise and improve its products. All specifications are therefore
subject to change without notice.
PRECAUTIONS
1.
Do not install the camera near electric or magnetic fields.
Install the camera away from TV, radio transmitter, magnet, electric motor, transformer,
audio speakers since the magnetic fields generate from above devices will distort the video
images.
2.
Never disassemble the camera nor put impurities in it.
Disassembly or impurities may result in trouble or fire.
3.
Never face the camera toward the sun.
Direct sunlight or severe ray may cause fatal damage to sensor and internal circuit.
4.
Keep the power cord away from water and liquid.
Touching the wet power cord may result in electric shock.
5.
Never install the camera in areas exposed to water, oil or gas.
Water, oil or gas may result in failure, electric shock or fire.
EVERFOCUS
Indoor Pendent Dome Camera
Operation Instructions
Model No.
EPD200
Advertisement
Table of Contents
Related Manuals for EverFocus EPD200A
Summary of Contents for EverFocus EPD200A
-
Page 1: Operation Instructions
Touching the wet power cord may result in electric shock. Never install the camera in areas exposed to water, oil or gas. Water, oil or gas may result in failure, electric shock or fire. EVERFOCUS Indoor Pendent Dome Camera Operation Instructions EPD200 Model No. -
Page 2: Optional Accessory
Cleaning Do not touch the surface of sensor by hand directly. Use a soft cloth to remove the dirt from the camera body. Use lens tissue or a cotton swab and ethanol to clean the sensor and the camera lens. Do not operate the camera beyond the specified temperature, humidity or power source ratings. -
Page 3: Specification
SPECIFICATION Pickup Device Video Format Scanning System Picture Elements Horizontal Resolution Sensitivity S/N Ratio Electronic Shutter Lens Video Output Back Light Comp.. Auto Gain Control Flickerless Auto White Balance Auto IRIS Gamma Correction Sync. Mode Power Source Power Consumption Video Output Connector AC 24V Power Connector + Video DC 12V Power Connector + Video Weight... -
Page 4: Dimension Diagram
DIMENSION DIAGRAM a. Conduit Size 26mm/1.06” 80mm/3.15”” 125mm/4.92” 90mm/3.54” 110mm/4.33”... -
Page 5: Hardware Overview
HARDWARE OVERVIEW a. Front panel design (For Vari-Focal Lens Model) BLC – Back Light Compensation AGC (Automatic Gain Control) FL(Flickerless) b. Front panel design (For Fixed Lens Model) BLC – Back Light Compensation AGC (Automatic Gain Control) ES(Electronic Shutter) IRIS LEVEL CONTROL BNC Pigtail Slot for Focusing and... -
Page 6: Installation
INSTALLATION This section covers simple steps and detail installation. Please follow instruction for preventing any unnecessary damage. Simple Steps: 1. Connect to 26mm/1.06” EMT Conduit Pipe and lock it with Hex Wrench 2. Open camera bubble cover 3. Connect to testing monitor(optional accessories) 4. - Page 7 White (+) Black (-) 2. Open Camera Bubble Cover Turn the camera bubble until you see the arrow face to here. 3. Connecting to testing monitor EN220 Connect the BNC Pigtail accessory to the front of the module for help with focusing or video testing.
-
Page 8: Camera Setting
4. Adjust Camera Position and Lens Adjust camera position (Tilt angle up to 90 degree): Adjust camera to the position you like. The turning angel is up to 90 degree. Use ‘tool-less’ screws on the side of the module to secure position. 90 Degree b. - Page 9 The default setting is ON. FL (Flickerless) When picture flicker fiercely, turn FL on, then the camera will stabilize the speed of electronic shutter at 1/100(S)(NTSC) or 1/120(S)(PAL) automatically, and reduce the flicker immediately. The default setting is OFF. IRIS Level Control (For Vari-Focal Lens Model) Brightness Level can be adjusted from the IRIS level VR while using the direct drive lens.
- Page 10 415 Oser Avenue Unit S Hauppauge, NY 11788 TEL: 631-436-5070 FAX: 631-436-5027 www.everfocus.com Your EverFocus product is designed and manufactured with high quality materials and components which can be recycled and reused. This symbol means that electrical and electronic equipment, at their end-of-life, should be disposed of separately from your household waste.
