Summary of Contents for Magnavox MM451
- Page 1 BLUETOOTH 50 WATT CD SHELF SYSTEM OWNER'S MANUAL PLEASE READ BEFORE OPERATING THIS EQUIPMENT. MODEL: MM451...
-
Page 2: Limited Warranty
LIMITED WARRANTY FCC WARNING: This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. Modifications not authorized by the manufacturer may void users authority to operate this devices. INFORMATION: This equipment has been tested and found to comply with the limits for a Class B Digital Device, pursuant to Part 15 of the FCC Rules. -
Page 4: Care And Maintenance
CARE AND MAINTENANCE Depending on the quality of the disc, and the condition of the recording, some CD-R/CD-RW discs may not be playable. How to remove the disc How to hold the disc How to clean the disc 1. Always place the compact disc in the disc tray with the label facing upward. (Compact discs can be played only on one side). -
Page 5: Location Of Controls
LOCATION OF CONTROLS MAIN UNIT PHONES 7 8 9 10 11 12 13 14 15 23 24 DC 15V BASS KNOB STANDBY 1 3. CLK SET, MEM/PROG BUTTON REPEAT / M- BUTTON PHONES JACK PHONES JACK AUX IN JACK SOURCE BUTTON LCD DISPLAY BALANCE KNOB STOP BUTTON... -
Page 6: Remote Controls
REMOTE CONTROLS PROG OPEN/ REPEAT CLOSE SCAN CLK SET PAIR FM BUTTON: Set the unit to FM radio mode STANDBY BUTTON: Set the unit to ON/ STANDBY CD BUTTON: Set the unit to CD mode PROG BUTTON: CD program playback MEM BUTTON: Radio memory REPEAT BUTTON: Set playback to repeat. -
Page 7: Battery Replacement
The Remote Control Unit can operate the unit from a distance about 8M. When operating the remote control unit, point it towards the front panel of the unit. • Even if the remote control unit is operated within the effective range, remote control operation may be impossible if there are any obstacles between the unit and the remote control. - Page 8 CONNECTION AND POWER SOURCE CONNECTING THE EXTERNAL SPEAKERS The speaker input sockets are located at the back of the main unit. Speaker output sockets are located at the back of speaker box. 1. Unwrap the included speaker wire, plug one end into the left (L) speaker box and plug the other end into the left (L) speaker socket on the main unit.
-
Page 9: Operation
OPERATION FM RADIO 1. Press the SOURCE button to switch to the FM RADIO or press the FM button on the remote. The display will show a radio station. 2. Tune to a desired radio station. The frequency is indicated on the display. •... -
Page 10: Program Play
button until the display reads “CD” or press CD button on the 1. Press SOURCE remote. 2. Press the OPEN/CLOSE button to open the CD door, put a CD onto the CD tray with the printed label facing up (towards you). To close the CD door, press OPEN/CLOSE button again. -
Page 11: Getting Connected
2. Set the Bluetooth function of your external device to ON and begin searching for devices. NOTE: The effective distance between your external device and this apparatus is 10 meters (33 feet). “MM451” 3. Once appears on the paired devices list of your external device select it. “0000”. -
Page 12: Troubleshooting
TROUBLESHOOTING In case of trouble with the unit, please look through the problems below and see if you can solve them yourself before calling your dealer. PROBLEM CAUSE SOLUTION Unit does not turn • Unit is unplugged • Connect unit to AC power ON when STANDBY supply is pressed. -
Page 13: General Specifications
GENERAL SPECIFICATIONS ATIONS Power Source : DC 15V, 3A, Audio Power : 25W per Channel (Total 50W, RMS) Impedance of Speakers : 30W, 4 ohm per channel FM Band Range : 87.5 - 108MHz BT Version : 5.0 BT Operation Distance : Up to 32 Feet in open area PACKAGE INCLUDES : Remote Control (2 x AAA size batteries, not included) Speaker cords x 2... - Page 14 This product has been manufactured by and is sold under the responsibility of Craig Electronics Inc, and Craig Electronics Inc is the warrantor in relation to this product. MAGNAVOX and SMART. VERY SMART are registered trademarks of Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.
