- Page 1 C-24 Center Walkaround Owner’s Manual...
-
Page 2: Table Of Contents
Battery Configuration ......................16 Fuse Location & Values ...................... 17 12V Helm Control Operation .................... 18 Cutwater C-24 Wiring Schematic (Acc. 1) ..............19 Cutwater C-24 Wiring Schematic (Acc. 2) ............... 20 Cutwater C-24 Wiring Schematic (Acc. 3) ............... 21 Cutwater C-24 Wiring Schematic (P.D.P.) .............. -
Page 3: Congratulations
SAFETY Safety is always a concern at Cutwater. Please read all manuals to ensure that equipment is used in a safe manner. We highly recommend atten- dance in a Coast Guard approved boating safety course. Such courses are available from the Coast Guard directly or from boating organiza- tions. -
Page 4: Garbage Disposal & Oil Overboard Placards
HEADLINE GARBAGE DISPOSAL & OIL OVERBOARD PLACARDS Required by the USCG in a language all passengers understand. These are installed at the factory. If damaged or missing after use they should be replaced. Text should cover approximately the following: GARBAGE DISPOSAL DISPOSAL OF ALL GARBAGE PROHIBITED EXCEPT OTHERWISE SPECIFIED THE AC T TO PREVENT POLLUTION FROM SHIPS (MARPOL ANNEX V) PLACES... -
Page 5: Symbol Glossary
SYMBOL GLOSSARY HEADLINE Attention! – Important Operating or Maintenance Instructions Attention! – Electrical Shock Hazard Fresh Water Waste Tank Fuel Standard Equipment Optional Equipment Hints... -
Page 6: Specifications (Subject To Change Without Notice)
HEADLINE SPECIFICATIONS C-24 Center Walkaround Length rigged LOA (motor down) ..........29’ 2” 8.9 m Length rigged LOA (motor up) ............31’ 9.5 m Beam ......................8’ 6” 2.6 m Draft (motor down) ................32” .8 m Draft (motor up) ..................19”... -
Page 7: Equipment Location
EQUIPMENT LOCATION HEADLINE STARBOARD FIT TINGS 1 2 3 4 5 6 7 8 10 11 13 14 15 16 17 18 19 20 21 22 9 12 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. -
Page 8: Port Fittings
HEADLINE PORT FIT TINGS 1 2 3 4 5 6 8 9 10 11 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. ➓ ➑ ➐ ➋ ➊ ➒ ➎ ➏ ➌... -
Page 9: Stern Components
STERN COMPONENTS 1 2 3 4 5 6 7 8 9 10 11 12 13 15 16 ➑ ➐ ➐ ➋ ➏ ➏ ➊ ➊ ➌ ➌ ➓ ➓ ➒ ➒ ➍ ➍ ➎ Shower ➊ ➏ Swim Platform Courtesy Lights Trailer Turn/Brake Lights Ski Pole ➋... -
Page 10: Main Cabin And Cockpit Lights
MAIN CABIN AND COCKPIT LIGHTS Switch on fixture Courtesy / LED lights Underwater lights (opt.) -
Page 11: Fuel System, Engine, Generator
FUEL SYSTEM, ENGINE Yamaha 250 Yamaha 300, Kicker (9.9 Yamaha) Fuel Tank Sender Vent Fuel fill Fuel filter / separator Kicker primer bulb Main primer bulb... -
Page 12: Raw Water / Sea Strainer System
RAW WATER / SEA STRAINER SYSTEM • Sea strainer for head and raw water wash down pump. Marine Toilet Head Raw Water Sea Strainer Thru-hull/Valve Raw Water Washdown Pump (optional) Live Well Valve (optional) Live Well (optional) -
Page 13: Fresh Water Plumbing System
FRESH WATER PLUMBING SYSTEM 26 Gallon Fresh Water Tank, 3.5 GPM Fresh Water Pump. Water vent Water fill Head sink Water Pump with removable strainer Transom sink Transom shower H-23 7/14 Disinfecting The Fresh Water System APPENDIX - POTABLE WATER SYSTEMS The information contained in this appendix provides supplementary data about disinfecting a potable water system. -
Page 14: Bilge Pump System
BILGE PUMP SYSTEM 12V 1100 GPH 12v 900 GPH The bilge pumps operate automatically by checking for water every 2.5 minutes even with battery switches and breakers in the OFF position. However, the bilge pumps will run continuously once their switches are placed in the on position. -
Page 15: Waste System With Macerator Pump
WASTE SYSTEM WITH MACERATOR PUMP 13 Gallon Tank with standard pump out, and vent Macerator pump out Waste tank pump out stations are widely available. Please follow the directions carefully for the pump out equipment you are using to avoid damage to the waste system. -
Page 16: Battery Configuration
BAT TERY CONFIGURATION 2 House Batteries, 1 Engine Battery House, start, & battery parallel switches and breakers are located in the access hatch beneath the stern sink. 1 Thruster Battery. Thruster battery, switch and ANL fuse are located in the forward VOLTAGE SENSOR RELAY sink cabinet. -
Page 17: Fuse Location & Values
FUSE LOCATION & VALUES FUSE LOCATION & VALUES Dash fuse blocks are located behind a hinged access panel in the head. Fuses are automotive blade type and all values shown below are in Amps. FUSE BLOCK #1 FUSE BLOCK #2 SALTWATER PUMP RFR POWER STEREO MEM... -
Page 18: 12V Helm Control Operation
12V HELM CONTROL OPERATION The bilge pumps operate automatically with electronic float switches regardless of battery switch position. This should be tested weekly. However, the aft, mid and forward pumps will run continuously once their switches are placed in the on position. Monitor the outflow accordingly. Do not run when dry. At Helm PORT CHRT... -
Page 19: Cutwater C-24 Wiring Schematic (Acc. 1)
C-24 CW WIRING SCHEMATIC (ACC. 1) C-24-CW/DC Accessories 1 ELECTRICAL SCHEMATIC +12V -12V Helm Fuse Block #1 WashDown Wash RED 10 YEL 16 GRN/BRN 16 Down RED 16 Stereo YEL 16 Stereo Deck - see MFR Schematic Stereo To 24/7 Fuse... -
Page 20: Cutwater C-24 Wiring Schematic (Acc. 2)
C-24 CW WIRING SCHEMATIC (ACC. 2) C-24-CW/DC Accessories 2 ELECTRICAL SCHEMATIC +12V -12V Helm Fuse Block #2 YEL 10 ORG/PUR 10 Refrigerator Refrigerator - see MFR Schematic 12V Outlet RED 14 YEL 14 HELM USB Outlet RED/BLK 16 YEL 14... -
Page 21: Cutwater C-24 Wiring Schematic (Acc. 3)
C-24 CW WIRING SCHEMATIC (ACC. 3) C-24-CW/DC Accessories 3 ELECTRICAL SCHEMATIC +12V -12V 24/7 Fuse Block #3 7.5A Bilge YEL 16 BRN/BLK16 Pump Fwd YEL 16 To Acc. 1 Schematic 7.5A Bilge BRN/BLU 16 Pump Mid YEL 16 To Acc. 1 Schematic 7.5A... -
Page 22: Cutwater C-24 Wiring Schematic (P.d.p.)
C-24 CW WIRING SCHEMATIC (P.D.P.) C-24-CW/DC Power Distribution ELECTRICAL SCHEMATIC 6 red Fuse Block A. 175A HOUSE 2 red 2 red 2 red 6 red Fuse Block B. SWITCH Helm PARALLEL SWITCH INVERTER ENGINE See Inverter schematics for wire SWITCH sizes and fuse size. -
Page 23: Cutwater C-24 Working Deck
C-24 CW WORKING DECK... -
Page 24: Care And Maintenance
CARE AND MAINTENANCE The following checklists are examples and are not all inclusive and are provided only as a guide. Please customize to your personal needs. Consult your engine and trailer user manuals for additional information. EXAMPLE OF A PREPARATION FOR THE ROAD CHECKLIST TOW VEHICLE –... -
Page 25: Example Of A Spring Pre-Launch Checklist
EXAMPLE OF A SPRING PRE-LAUNCH CHECKLIST CLEANING Remove debris from scuppers and scupper drains. £ Clean hull using a mild biodegradable detergent and then wax. £ Clean topsides and decks using a mild biodegradable detergent and then wax. £ Clean and polish all bright work. £... -
Page 26: Example Of Winter Storage Checklist
EXAMPLE OF WINTER STORAGE CHECKLIST GENERAL MAINTENANCE Fill Fuel Tank and add a fuel stabilizer. £ Empty and clean black water tank. £ Empty fresh water tank use a non-toxic antifreeze per manufacturer’s directions, £ or remove all water from the system. Winterize black and fresh water tanks as necessary based on weather. -
Page 27: Warning Label Locations
WARNING LABEL LOCATIONS IN ENCLOSED HEAD IN ENCLOSED HEAD... -
Page 28: Contacts
HEADLINE CONTAC TS Customer Service Kenny Marrs, Customer Service Manager Phone: 253-839-5213 kennymarrs@rangertugs.com Web Site www.CutwaterBoats.com... - Page 29 All rights reserved. Reproduction or translation by any means in whole or in part is not permitted without written authorization from Cutwater. The information contained herein is correct to the best of Cutwater’s knowledge and the contents may change without notice and without incur- ring obligation.
