- Page 1 C-24 Coupe & Sport Coupe Owner’s Manual https://www.boat-manuals.com/...
-
Page 2: Table Of Contents
Fuse Location & Values ..................19 AC Distribution Panel & Rotary Switch ..............20 12V Helm Control Operation ................. 21 Cutwater C-24 Wiring Schematic (Acc. 1) .............. 22 Cutwater C-24 Wiring Schematic (Acc. 2) .............. 23 Cutwater C-24 Wiring Schematic (Acc. 3) .............. 24 Cutwater C-24 Wiring Schematic (Lighting) ............ -
Page 3: Congratulations
SAFETY Safety is always a concern at Cutwater. Please read all manuals to ensure that equip- ment is used in a safe manner. We highly recommend attendance in a Coast Guard approved boating safety course. Such courses are available from the Coast Guard directly or from boating organizations. -
Page 4: Symbol Glossary
SYMBOL GLOSSARY Attention! – Important Operating or Maintenance Instructions Attention! – Electrical Shock Hazard Fresh Water Black Water Fuel Standard Equipment Optional Equipment Hints https://www.boat-manuals.com/... -
Page 5: Specifications (Subject To Change Without Notice)
SPECIFICATIONS C-24 Coupe LOH (transom - bow) ..............23’ 7” 7.2 m LOA (motor down) ................31’ 4” 9.55 m LOA (motor up) ................33’ 8” 10.26 m Beam ....................8’ 6” 2.6 m Draft (motor down) ..............30” .76 m Draft (motor up) ................19”... -
Page 6: Equipment Location
EQUIPMENT LOCATION STARBOARD FIT TINGS 1 2 3 4 6 7 8 9 11 12 15 16 17 18 19 20 21 22 5 10 13 14 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. ➓... -
Page 7: Port Fittings
PORT FIT TINGS 1 4 5 6 8 9 12 16 17 18 2 3 7 10 11 13 14 15 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. ➊ ➋ ➍... -
Page 8: Stern Components
STERN COMPONENTS 1 2 3 5 6 7 8 9 10 11 12 13 ➐ ➐ ➋ ➑ ➊ ➊ ➏ ➏ ➌ ➌ ➓ ➓ ➒ ➒ ➌ ➍ ➍ ➎ ➊ ➏ Shower Swim Platform Courtesy Lights Trailer Turn/Brake Lights Ski Pole ➋... -
Page 9: Main Cabin And Cockpit Lights
MAIN CABIN AND COCKPIT LIGHTS Switch on Switch on fixture fixture Indirect LED Lighting Red cabin night lights switch on dash V-Berth Lighting Push On/Off LED Lights Push On/Off LED Lights Indirect LED Lighting (below seat in midberth) Switch on fixture Cabin lighting Optional Underwater Lights... -
Page 10: Fuel System, Engine, Generator
FUEL SYSTEM, ENGINE, GENERATOR Yamaha 250 Generator / Yamaha 300 / Kicker (9.9 Yamaha) Fuel Tank Generator Supply Sender Vent Fuel fill Generator Fuel filter / seperator Fuel filter / seperator Generator Kicker primer bulb Main primer bulb https://www.boat-manuals.com/... -
Page 11: Raw Water / Sea Strainer System
RAW WATER / SEA STRAINER SYSTEM • Multi port sea strainer for head and raw water wash down pump. • Generator raw water thru-hull strainer Raw Water System Marine Toilet Head Raw Water Sea Strainer Sea Strainer Thru-hull/Valve Raw Water Washdown (optional) Live Well (optional) -
Page 12: Fresh Water Plumbing System
FRESH WATER PLUMBING SYSTEM 22 Gallon Fresh Water Tank, 4 Gallon Hot Water Heater, 3.5 GPM Fresh Water Pump. Water vent Water fill Head sink Cabin sink Water Pump with removable Sender strainer Water heater Water heater drain Transom sink Transom shower H-23... -
Page 13: Shower Sump
SHOWER SUMP 12V, 1000 GPH (This should be inspected for debris on a regular basis if shower is used frequently.) The shower sump box is located underneath the v-berth step positioned just outside the head door. Depth Transducer Shower drain Sump pump Thru-hull https://www.boat-manuals.com/... -
Page 14: Bilge Pump System
BILGE PUMP SYSTEM 12V 1100 GPH 12v 900 GPH The bilge pumps operate automatically by checking for water every 2.5 minutes even with battery switches and breakers in the OFF position. However, the bilge pumps will run continuously once their switches are placed in the on position. Monitor the outfl ow accordingly. -
Page 15: Waste System With Macerator Pump
WASTE SYSTEM WITH MACERATOR PUMP 11 Gallon Tank with standard pump out, and vent Macerator pump out Waste tank pump out stations are widely available. Please follow the directions carefully for the pump out equipment you are using to avoid damage to the waste system. -
Page 16: Air Conditioning
AIR CONDITIONING A/C / Sink Drain A/C Vent A/C Vent Main Cabin A/C Unit (Under Seat) Main Cabin A/C Control Panel (in Mid-Berth) AC Water Pump (optional) Sea Strainer Thru-hull/Valves https://www.boat-manuals.com/... -
Page 17: Webasto Furnace
WEBASTO FURNACE Webasto furnace is located under the foward passenger seat. The control panel is located at the quarter berth power management center. The fuel pump and fi lter are beneath the passenger seat, inside of the black box. To access the heater/pump the seat must be removed. The fuel fi lter should be changed during the annual maintenance. -
Page 18: Battery Configuration
BAT TERY CONFIGURATION 2 House Batteries, 1 Engine Battery House, engine, & battery parallel switches are located in the midberth. 1 Thruster Battery (optional). Thruster battery switch is located in the starboard side lazarette Inverter battery switch and ANL fuse located in the port side lazarette Once the EMERGENCY PARALLEL switch is placed in the on position the power from the HOUSE batteries will be transferred to the ENGINE battery. -
Page 19: Fuse Location & Values
FUSE LOCATION & VALUES FUSE LOCATION & VALUES CW-24 CW-24 CW-24 Dash fuse blocks are located behind a hinged access panel in the head. The 24/7 fuse block is located in the mid cabin behind a removable panel secured with Velcro in the aft inboard corner. Fuse Block Layouts Fuse Block Layouts Fuse Block Layouts... -
Page 20: Ac Distribution Panel & Rotary Switch
AC DISTRIBUTION PANEL & ROTARY SWITCH AC Distribution Panel AC Rotary Selector Switch (Available with Generator) AC Main Line 2 (with AC) Inverter. While using, you must power manage the devices you choose to use. Do not exceed 1000 watt maximum. Never have charger breaker on while using the inverter. A/C Main 1 and battery charger breaker must on in order for batteries to charge. -
Page 21: 12V Helm Control Operation
12V HELM CONTROL OPERATION High Water Alarm: Triggered = Red light/audible alarm Armed = Normal operation Off = center position. The switch should remain in the down “armed position” while cruising. Middle position mutes the alarm and all the way up is a momentary “alarm test”. The bilge pumps operate automatically with electronic float switches regardless of battery switch position. -
Page 22: Cutwater C-24 Wiring Schematic (Acc. 1)
C-24 WIRING SCHEMATIC (ACC. 1) C-24 Accessories 1 ELECTRICAL SCHEMATIC +12V -12V B.P. Helm Fuse Block #1 Bilge BRN 16 YEL 16 Pump Bow YEL 16 Defrost PUR/WHT 16 Fans Macerator BRN 10 YEL 10 Pump 30A RED 10 Spare Sub Panel 8 Switch Macerator... -
Page 23: Cutwater C-24 Wiring Schematic (Acc. 2)
C-24 WIRING SCHEMATIC (ACC. 2) C-24 Accessories 2 ELECTRICAL SCHEMATIC -12V +12V Fuse Block #2 12V Outlet RED 16 YEL 16 Port 12V Outlet RED 16 YEL 16 Passenger 12V Outlet RED 16 YEL 16 STBD Cabin To Lighting Schematic Lights V-berth To Lighting Schematic... -
Page 24: Cutwater C-24 Wiring Schematic (Acc. 3)
C-24 WIRING SCHEMATIC (ACC. 3) C-24 Accessories 3 -12V +12V ELECTRICAL SCHEMATIC 24/7 Fuse Block #3 Auto Pilot BRN/BLK 10 YEL 10 Auto Pilot - see MFR Schematic Pump B.P. YEL 16 To Acc. 1 Schematic 7.5A #1 Bilge BRN/RED 16 Pump Aft B.P. -
Page 25: Cutwater C-24 Wiring Schematic (Lighting)
C-24 WIRING SCHEMATIC (LIGHTING) C-24 Lighting ELECTRICAL SCHEMATIC -12V +12V Dash Fuse Block #1 Bilge Pump (Bow) RED 10 To Acc. #1 Schematic Subpanel RED 10 Macerator 8 Switch To Acc. #1 Schematic (Helm) RED 10 Defrost Fans To Acc. #1 Schematic Subpanel Bilge Pump (Aft) RED 10... -
Page 26: Cutwater C-24 Wiring Schematic (P.d.p.)
C-24 WIRING SCHEMATIC (P.D.P.) C-24 Power Distribution ELECTRICAL SCHEMATIC To generator control panel. 6 red Fuse Block A. 175A HOUSE 2 red To A.C. panel. 2 red 2 red 6 red Fuse Block B. SWITCH Helm GENERATOR To A.C. panel. PARALLEL 6 red SWITCH... -
Page 27: Cutwater C-24 Working Deck
C-24 WORKING DECK https://www.boat-manuals.com/... -
Page 28: Care And Maintenance
CARE AND MAINTENANCE The following checklists are examples and are not all inclusive and are provided only as a guide. Please customize to your personal needs. Consult your engine and trailer user manuals for ad- ditional information. EXAMPLE OF A PREPARATION FOR THE ROAD CHECKLIST TOW VEHICLE –... -
Page 29: Example Of A Spring Pre-Launch Checklist
EXAMPLE OF A SPRING PRE-LAUNCH CHECKLIST CLEANING Remove debris from scuppers and scupper drains. £ Clean hull using a mild biodegradable detergent and then wax. £ Clean topsides and decks using a mild biodegradable detergent and then wax. £ Clean and polish all bright work. £... -
Page 30: Example Of Winter Storage Checklist
EXAMPLE OF WINTER STORAGE CHECKLIST GENERAL MAINTENANCE Fill Fuel Tank and add a fuel stabilizer. £ Empty and clean black water tank. £ Empty fresh water tank use a non-toxic antifreeze per manufacturer’s directions, £ or remove all water from the system. Winterize black and fresh water tanks as necessary based on weather. -
Page 31: Warning Label Locations
WARNING LABEL LOCATIONS PROPELLER WARNING EPA & COAST GUARD COMPLIANCE MAXIMUM CAPACITIES CARBON MONOXIDE HIGH VOLTAGE DO NOT STORE FUEL SHOCK & FIRE HAZARD INSPECT FOR LEAKS CARBON MONOXIDE TRANSOM DOOR MUST BE CLOSED PROPELLER WARNING CONTENTS UNDER PRESSURE https://www.boat-manuals.com/... - Page 32 All rights reserved. Reproduction or translation by any means in whole or in part is not permitted without written authorization from Cutwater. The information contained herein is correct to the best of Cutwater’s knowledge and the contents may change without notice and without incurring obligation.
