- Page 1 C-32 Owner’s Manual...
-
Page 2: Table Of Contents
Bilge Pump System ....................30 Waste System with Macerator Pump ..............31 Mast Set Up And Take Down ................. 32 Cutwater 32 Wiring Schematic (Acc. 1) ..............33 Cutwater 32 Wiring Schematic (Acc. 2) ..............34 Cutwater 32 Wiring Schematic (Acc. 3) ..............35 Cutwater 32 Wiring Schematic (Lighting) .............. -
Page 3: Congratulations
SAFETY Safety is always a concern at Cutwater. Please read all manuals to ensure that equip- ment is used in a safe manner. We highly recommend attendance in a Coast Guard approved boating safety course. Such courses are available from the Coast Guard directly or from boating organizations. -
Page 4: Safety Sticker Location
SAFETY STICKER LOCATION... -
Page 5: Garbage Disposal & Oil Overboard Placards
GARBAGE DISPOSAL & OIL OVERBOARD PLACARDS Required by the USCG in a language all passengers understand. These are installed at the factory. If damaged or missing after use they should be replaced. Text should cover approximately the following: GARBAGE DISPOSAL DISPOSAL OF ALL GARBAGE PROHIBITED EXCEPT OTHERWISE SPECIFIED THE AC T TO PREVENT POLLUTION FROM SHIPS (MARPOL ANNEX V) PLACES... -
Page 6: Symbol Glossary
SYMBOL GLOSSARY Attention! – Important Operating or Maintenance Instructions Attention! – Electrical Shock Hazard Fresh Water Black Water Fuel Standard Equipment Optional Equipment Northwest Edition Luxury Edition Hints... -
Page 7: Specifications (Subject To Change Without Notice)
SPECIFICATIONS C-32 SEDAN LOA (motors down) ............... 37’ 8” 11.5 m LOA (motors up) ................39’ 10” 12.1 m Beam ..................... 10’ 3.05 m Draft (motors up) ................26” .66 m Draft (motors down) ..............33” .84 m Weight (dry) ................... 10,000 lbs 4,536 kg Bridge clearance (mast/down) ............ -
Page 8: Sanitation Of Potable Water System
SANITATION OF POTABLE WATER SYSTEM SUGGESTED METHOD OF DISINFEC TION Perform the following steps in the order indicated at least once a year: a. Flush entire system thoroughly by allowing potable water to flow through it. b. Drain system completely. Fill entire system with a chlorine solution having a strength of at least 100 parts per million, and allow to stand for one (1) hour. -
Page 9: Equipment Location
EQUIPMENT LOCATION STARBOARD FIT TINGS 1 2 4 5 6 7 9 10 11 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. ➏ ➊ ➊ ➐ ➌ ➍ ➑ ➒ ➋ ➓... -
Page 10: Port Fittings
PORT FIT TINGS 1 2 3 4 5 6 7 8 12 14 16 9 10 13 15 Keep all vents, drains and exhausts clear of any obstructions to ensure proper performance of each system. ➓ ➊ ➒ ➑ ➐ ➋... -
Page 11: Main Cabin Top Deck Components
MAIN CABIN TOP DECK COMPONENTS 1 2 3 6 7 ➏ 4 5 8 ➎ ➌ ➍ ➊ ➑ ➋ ➐ Sedan ➏ ➍ ➎ ➊ ➌ ➑ ➐ ➋ Command Bridge ➊ Searchlight ➎ XM-Weather Antennae ➋ Horn ➏ Anchor Light ➌... -
Page 12: Stern Components
STERN COMPONENTS 1 2 3 4 5 6 7 ➊ ➊ ➍ ➍ ➏ ➋ ➐ ➐ ➌ ➌ ➎ ➑ ➊ ➎ Courtesy Lights Stern Thruster ➋ ➏ Cockpit Drains Swim Platform Retractable Ladder ➌ ➐ Underwater Lights Trim Tabs ➍... -
Page 13: Fuse Location & Values
FUSE LOCATION & VALUES The dash fuse blocks are located behind the hinged mirror located inside of the bathroom. Fuses are automotive blade type and all values are shown in amps. CW-30/32 CW-30/32 Fuse Block Layouts Fuse Block Layouts W-30/32 Dash #1 Dash #1 Dash Fuse Block #1... - Page 14 Fuse Block Layouts Dash #1 TV Antenna Light Switch (V-berth) 12V Outlet (Dinette) CW-30/3 CW-30/32 Webasto Heater Fuse Block L Fuse Block Layouts FUSE LOCATIONS AND VALUES CONTINUED Dash #1 Dash #1 TV Antenna Light Switch (V-berth) 12V Outlet (Dinette) These four blocks and fuses are located in the Quarter Berth aft storage area and under Webasto Heater the Helm on the Bridge.
-
Page 15: Main Cabin And Cockpit Lights
MAIN CABIN AND COCKPIT LIGHTS ➎ ➎ ➎ Switch on fixture for ➍ ➍ ➍ ➐ ➏ ➍ ➏ Switch for ➍ ➍ ➐ Switch for & ➏ ➏ ➌ ➌ ➌ ➌ ➌ ➌ Switch on fixture for ➌ ➑... -
Page 16: Battery Compartment
BAT TERY COMPARTMENT House Batteries, Engine Battery, Thruster Battery, Inverter/Charger Inverter Fuse (150 AMP), Inverter/Charger Cutoff Switch. Batteries 1 = House 2 = Engine 3 = Thruster Inverter / Charger... -
Page 17: Power Distribution Center
POWER DISTRIBUTION CENTER Located in the upper cockpit hatch on the starboard side of the main cabin door. House, Engine, Thruster, and Crossover switches. The parallel switch should always remain in the off position. While in the on position, the house and engine batteries will be combined as one for emergency start only. -
Page 18: Systems Control Center
SYSTEMS CONTROL CENTER Located in midberth Inverter/Battery Charger Rear Heat Control Solar Water Pump gauge/switch MeTer Abso Inverter Charger MT-1 Charge Error Charger Inveter Status Fault DV Volts Display KiloWatts ELCI SELECT POWER 12.9 KISAE ON/STATUS SHORE NEXT POWER FAULT RESET TEST 12 VOLTS DC... -
Page 19: Ac Distribution Panel, Switch & Dc Volt Meter
AC DISTRIBUTION PANEL, SWITCH & DC VOLT METER Located in midberth AC Distribution Panel AC Selector Switch. Available with Generator The AC Switch Selector Switch will determine which source of incoming 120 Volt power to use for your AC Distribution Panel. Slide gate for shore/generator power selection. AC Distribution Panel 120 VOLT AC 60 HZ DC AMPERES... -
Page 20: Inverter
INVERTER Inverter powers microwave and 110V outlets. To power on inverter: • Turn the rotary switch to the ON postion (located in port lazarette). • Press the power button on the inverter panel in the system control center. • Switch on load at AC Panel. Inverter Rotary Switch Fuse 150 amp ANL... -
Page 21: Shore Power Layout
SHORE POWER LAYOUT Shore Power AC Panel/ELCI Breaker (pg 19) Galvanic Isolator Shore Power Inlet Inverter/Charger (pg 20) -
Page 22: Solar Panel
SOLAR PANEL Solar panel 140 watt, with control panel • The solar panel is designed to provide charging to the house & engine batteries. 90% of its charge is dedicated to the house battery and 10% is dedicated to the engine battery. •... -
Page 23: Generator
GENERATOR Generator will start off of thruster battery #3 FUEL TANK Generator Supply Generator Fuel filter / seperator Generator Silencer Exhaust Water Lock... -
Page 24: Fuel System - Engine And Generator
FUEL SYSTEM - ENGINE AND GENERATOR 2 x Yamaha 300 Generator STARBOARD ENGINE FUEL TANK Sender Fuel fill Vent Pickup PORT ENGINE FUEL TANK Sender Vent Fuel fill Pickup Generator Supply Generator Fuel filter / separator Starboard Fuel filter / separator Port Fuel filter / separator Starboard Main primer bulb Generator... -
Page 25: Webasto Furnace
WEBASTO FURNACE Webasto diesel furnace is located under access panel below range. The controller is located at the quarter berth power management center. The pump is underneath the forward passenger seat. The diesel tank capacity is 10 gal. Interior Heat Vent Fuel Tank Fuel Pump / Filter (inside black box) -
Page 26: Air Conditioning System
AIR CONDITIONING SYSTEM Air Conditioning System Air Conditioner Dislpay V-Berth Shower Sump Box Condensate Drain Raw Water Discharge Air Conditioner V-Berth 12kw Access from mid cabin Air Conditioner Salon 16kw Air Conditioner Dislpay located at Power Management Control Center Air Conditioner Pump Air Conditioner Thru-Hull Air Conditioner Sea Strainer... -
Page 27: Sea Strainer System
SEA STRAINER SYSTEM Multi Port Sea Strainer for Marine Toilet and Raw Water Washdown. Marine Toilet Head Raw Water Generator (optional) AC Pump (opt.) Sea Strainer Sea Strainer Thru-hull/Valves Sea Strainer Raw Water Washdown... -
Page 28: Fresh Water Plumbing System
FRESH WATER PLUMBING SYSTEM 80 Gallon Fresh Water Tank, 11 Gallon Water Heater, 4.0 GPM Fresh Water Pump. Head sink cold Head sink hot Shower mixer cold & hot Fresh water Galley sink hot Tank Galley sink cold Water Fresh water pump Heater Fresh water fill Tank vent... -
Page 29: Shower Sump
SHOWER SUMP 12V, 500 GPH (Sump should be inspected for debris on a regular basis if shower is used frequently.) • The shower sump box is located underneath the center removable teak and holly floor. Shower Sump... -
Page 30: Bilge Pump System
BILGE PUMP SYSTEM 12V 1000GPH Marine Toilet The bilge pumps operate automatically even when all switches and breakers are in the OFF position. They will detect for water for 1 second once every 2 and a half minutes and run if needed. However, the FORWARD BILGE PUMP and AFT BILGE PUMP will run continuously once their helm switches are placed in the on position. -
Page 31: Waste System With Macerator Pump
WASTE SYSTEM WITH MACERATOR PUMP Equipped with Raw Water Head, 40 Gallon Tank with Macerator Pump Out, Standard Dockside Pump Out, and Vent. Waste tank fill level can be monitored by checking the electronic display in the head compartment. Green = Empty, Yellow = Half, Red = Full. Pump out can be done with the macerator or standard dockside pump out. -
Page 32: Mast Set Up And Take Down
MAST SET UP AND TAKE DOWN SED A N A ND S P O RT MAST SET UP PROCEDURE 1. Remove the two black plastic wing nuts from the mast base. 2. While supporting the mast, remove the pin in the support bar. 3. -
Page 33: Cutwater 32 Wiring Schematic (Acc. 1)
C-32 WIRING SCHEMATIC (ACC. 1) CW-32 Accessories #1 ELECTRICAL SCHEMATIC -12V +12V Dash Fuse Block #1 To Subpanel 4 Switch (Bridge) ORG/WHT 16 YEL 16 RED 10 Horn Macerator YEL 10 RED 10 BRN 10 Pump Subpanel Macerator 8 Switch... -
Page 34: Cutwater 32 Wiring Schematic (Acc. 2)
C-32 WIRING SCHEMATIC (ACC. 2) CW-32 Accessories #2 ELECTRICAL SCHEMATIC -12V +12V Dash Fuse Block #2 YEL 10 ORG 10 Trim Tabs Trim Tab - see MFR Schematic Wine ORG 10 YEL 10 Wine Cooler - see MFR Schematic Cooler... -
Page 35: Cutwater 32 Wiring Schematic (Acc. 3)
C-32 WIRING SCHEMATIC (ACC. 3) CW-32 Accessories #3 -12V +12V ELECTRICAL SCHEMATIC PDP Fuse Block Washdown RED 10 YEL 10 BRN 10 Washdown 12V Outlet YEL 10 RED/PUR 10 (Quarter Berth) ORG/PUR 10 YEL 10 Refrigerator Refrigerator - see MFR Schematic... -
Page 36: Cutwater 32 Wiring Schematic (Lighting)
C-32 WIRING SCHEMATIC (LIGHTING) CW-32 Lighting +12V -12V ELECTRICAL SCHEMATIC Dash Fuse Block #1 RED 10 Wipers (Port & Stbd) To Acc. #1 Schematic Subpanel Bilge Pump (#1) RED 10 8 Switch To Acc. #1-2 Schematic (Helm) RED 10 Bilge Pump (#2) To Acc. -
Page 37: Cutwater 32 Wiring Schematic (P.d.p.)
C-32 WIRING SCHEMATIC (P.D.P.) To Generator Control Panel 8 RED 8 RED To Stereo Amplifier (SPORT ONLY) To AC Panel HOUSE 3/O RED 1 RED 6 RED To Quarter Berth Fuse Block 150A SWITCH 1 RED To AC Panel GENERATOR... -
Page 38: Working Deck
WORKING DECK... -
Page 39: Care And Maintenance
CARE AND MAINTENANCE The following checklists are examples and are not all inclusive and are provided only as a guide. Please customize to your personal needs. Consult your engine and trailer user manuals for additional information. EXAMPLE OF A PREPARATION FOR THE ROAD CHECKLIST TOW VEHICLE –... -
Page 40: Example Of A Spring Pre-Launch Checklist
EXAMPLE OF A SPRING PRE-LAUNCH CHECKLIST CLEANING Remove debris from scuppers and scupper drains. £ Clean hull using a mild biodegradable detergent and then wax. £ Clean topsides and decks using a mild biodegradable detergent and then wax. £ Clean and polish all bright work. £... -
Page 41: Example Of Winter Storage Checklist
EXAMPLE OF WINTER STORAGE CHECKLIST GENERAL MAINTENANCE Fill Fuel Tank and add a fuel stabilizer. £ Empty and clean black water tank. £ Empty fresh water tank use a non-toxic antifreeze per manufacturer’s directions. £ Winterize black and fresh water tanks as necessary based on weather. £... -
Page 42: Contacts
CONTAC TS Customer Service Kenny Marrs, Customer Service Manager Phone: 253-839-5213 kennymarrs@cutwaterboats.com Web Site www.Cutwaterboats.com... -
Page 43: Notes
NOTES... - Page 44 All rights reserved. Reproduction or translation by any means in whole or in part is not permitted without written authorization from Cutwater. The information contained herein is correct to the best of Cutwater’s knowledge and the contents may change without notice and without incurring obligation.
