- Page 1 Midea Life can be lovelier. Fully Automatic Double Pump Dishwasher Service Manual Shunde Midea Dishwasher Manufacturing Co., Ltd.
-
Page 2: Commonly Used Tools
Loose or defect inlet valve connector. Damaged pump. Pump gasket failure. Caked dishwater powder. Dishes block the water flow to the dishwasher powder. No brightness liquid in dispenser. Electromagnetic valve does not work. Sealing cap failure. Broken dispenser case. Service Instructions Check socket. - Page 3 WP5E. The actual configuration may be different. III. Check of Performance: Loading of Dishes Many of the performance failures of the dishwasher are not the result of mechanical troubles. And the unsatisfactory washing result can usually be corrected without any service.
-
Page 4: Power Cord
C of the inner container (see fig. 1 below), and pull out the control panel. g. Remove the timer knob (see 1 in the appending diagram). h. Turn the dishwasher upside down, remove all the screws in the bottom pan, open the cord clamp and remove the bottom pan. -
Page 5: Door Lock Assembly
The output cords of the timer are in different colors. With a copy of the circuit diagram in hand, you can track the circuit from the timer to any element. The timer is a very reliable unit. In case of dishwasher troubles, check other causes first before focusing on and replacing the timer. -
Page 6: Inlet Valve
Steps for the check: Check and replace the inlet valve. a. Turn the power of the dishwasher to OFF, and pull out the power cord plug (guard against sharp edge from hurting the power cord). b. Check with an ohmmeter as instructed. - Page 7 The heating element has a nichrome filament inside. You can measure the resistance with a universal meter to check its condition. The protective thermostat is a temperature limitation switch and a safety device. In case the dishwasher fails and the temperature inside the inner container rises above a specific limitation, the thermostat will cut the heating element circuit to avoid any damage to the machine.
-
Page 8: Overheat Thermostat
XV. Overheat Thermostat This thermostat is designed to prevent overheating of the heating element. The temperature limitation is set at 115 . Below this limitation, the circuit is closed. Once the temperature rises above this limitation, the circuit is cut, protecting the heating element from being burnt. Steps for the check: Remove the outer casing. - Page 9 XIX. Water Softener container of the dishwasher. It slows the growth of sediment in the inner container and improves the efficiency of the dishwasher powder. The water softener may have such troubles as a.
-
Page 10: Specifications
WP5E Parts List Parts Outer casing Insulation piece Micro switch Door lock screw Door lock base Door lock spring #2 Spring w asher Linkage Door lock spring #1 Slider Door lock holder Top rubber plate Inner container assem bly Rear left bracing bar Condenser Condenser gasket Condenser nut... - Page 11 Heating elem ent mounting p late Heating elem ent gasket Heating elem ent Sump gasket Thermostat Thermostat gasket Sump Front cover Foot Bottom pan Turn knob Switch button Door button Control panel Pilot cover Control panel bracing bar Power switch bracing bar Tim er Power switch Option switch...
- Page 12 Rear right bracing b ar Inlet gasket Inlet connector #1 Power cord clamp Insulation porcelain Inlet tube Absorption proofed connecting hose Inlet valve Inlet valve mounting plate Rear panel Drain hose connector Power cord p ad Power cord Name plate Drain hose assem bly Inlet hose assembly Wire basket assem bly...
- Page 13 XXII. Consumables List Consumables for WP5 Series Double Pump Models Parts Specifications (Ref. O nly) Capacitor Heating element Thermostat #1 Thermostat Thermostat gas ket Spray arm base tube Micro switch (working) Micro switch (protection) Micro switch Circulation pump Circulation pump inlet hos e Drain pump Drain pump inlet hose Outer door...
- Page 14 µ ç Â · Í ¼ Power switch door switch Note: This circuit diagram applies to WP5 series double pump dishwashers (120V, 60Hz) embedded with electric filter and without water softener and equipped with timer 165 The working thermostat may choose among 55 in accordance with the user preference and the region.
- Page 15 power switch door switch Power switch Note: ± ¸ × ¢ : This circuit diagram applies to WP5 series double pump dishwashers (120V, 60Hz) embedded without water softener and equipped with timer 163. The working thermostat may choose among 55 and 62 in accordance with the user preference and the region.
