- Page 1 Grapple MG20 - MG80, SG40-60 & SOG80 Translation of the Original Instructions 2200179_7225 2018 04 23 |...
- Page 2 Overview The products described in the document are original tools for Rototilt . The overviews show standard ® equipment and options. See illustrations and lists below. Grapple, components 1. Hitch 2. Frame / Bolted joint 3. Chassis 4. Cover plate 5.
-
Page 3: Operation
Stone grapple The grapple arms work tip-to-tip, at a flat angle (2). The stone grapple models are suitable for use on the Rototilt R series. Sorting grapple The grapple arms work tip-to-tip, at a sharper angle (3). The sorting grapple is suitable for use on the Rototilt R series. - Page 4 Undo the connections carefully. prevents unintentional grapple opening. The pressurized gas in the accumulator is compressed further by hydraulic pressure at the start of work. This automatically adjusts the grapple if the load shifts. © Rototilt Group AB Instructions_Grapple 2200179_ _ 7225 2018-04-23...
-
Page 5: Using The Product
Remain constantly on the lookout for signs of degraded functions. Contact an authorized service workshop Use the grapple in the intended manner and within its capacity limits; see Limitations and Technical data. © Rototilt Group AB 2200179_ _ 7225 2018-04-23 Instructions_Grapple... -
Page 6: Maintenance
Inspection & service manufacturing number on the information Warning decals plate. Information plate. Only use original spare parts from Rototilt Shank locks Group AB. Rototilt Group AB assumes no Hoses liability for the product if other spare parts Quick coupler are used. -
Page 7: Daily Checks
250 operating hours. Grease the tapered expanders and pins on reinstallation. The MG20 grapple is fitted with a bearing that is secured with a locking nut. Tightening torque when checking and re-tightening is 17 Nm. © Rototilt Group AB 2200179_ _ 7225 2018-04-23 Instructions_Grapple...
