Installation instructions

REMOVE ALL THE SHIPPING PARTS BEFORE INSTALLATION
LOCATION
Select a location that can support the weight of the air conditioner and one that will not
cause increased operation noise and vibration.
Direct sunlight is unfavorable for efficient cooling.
Select a place where there is no obstacles near the air inlet and outlet.
wall thickness is less than 210
Make rear side lower so that waterwill drain out smoothy.
Less than 210
More than 55
- 6 -
Scrape
lf the wall thickness is more than 210 scrape the wall as
shown above.
more
than 400
45
less
than 210
more
than 400
more
than 500
