Instant Upright Snappy 300 Assembly Manual

Snappy
300
LOW LEVEL ACCESS TOWER SYSTEM
ASSEM BLY PROCESS
1. Preparation
Install the castors into the uprights if not already done.
Sort the braces into horizontal and diagonal braces - the diagonals are slightly longer.
Unlock the brace locks.
2. Base
Follow the erection procedures as shown (Section 4). It is important to follow the
bracing pattern precisely. If extension frames are being used, ensure they are "locked"
using the interlock clips.
3. Locking down the platform
A windlock clip is installed on the platform at the hook. This is locked as shown here.
4. BUILD PROCESS - 1 metre
1
2
Clip 2 horizontal braces
Insert castors into the
th
to the 7 rung either
folding frames. Lock 2
side of the frame. Clip 1
castors in one frame and
horizontal brace to the
roll the other frame
th
5 rung opposite the
outwards until the
diagonal braces.
folding diagonal braces
lock. Lock the other 2
castors.
BUILD PROCESS - 2 metre
1 2
Insert castors into the Clip horizontal brace
folding frames. Lock 2 onto the vertical member
just above the 1
castors in one frame and
with the claw facing
roll the other frame
outwards until the outwards.
folding diagonal braces
lock. Lock the other 2
castors.
BUILD PROCESS - 4 metre
1 2
Insert castors into the Clip 2 horizontal braces
th
to the 7 rung either
folding frames. Lock 2
side of the frame. Clip a
castors in one frame and
horizontal brace onto the
roll the other frame
th
outwards until the 5 rung opposite the
folding diagonal braces diagonal braces.
lock. Lock the other 2
castors.
6 7
Remove the 2 horizontal
Remove the horizontal
th
brace from the 5 rung braces from the 7th rung
and clip this onto the and using the 3T
vertical member just method, clip them to the
st th
12 rung both sides of
above the 1 rung, with
the platform. Add 2 more
the claw facing
horizontal braces to the
outwards.
th
13 rung.
This Assembly guide is designed to provide you with step by step instructions to ensure your system is
erected easily and safely using the 3T (Through the Trap) Safety Standard. Before assembly please read
the safety notes carefully.
Snappy 300 is a mobile access tower system complying with EN 1004 and WAHR, anti slip frame access, designed for Class 3 loading.
3
Fit trapdoor platform to
rd
the 3 rung.
3
Insert two guardrail
frames and lock.
st
rung,
3
rd
Fit trapdoor to the 3
rung.
8
Fit guardrail frames and
lock.
Unlocked
Locked
Unlocked
Locked
Locked
Unlocked
Warning:
The Snappy 300
is designed to be extended
with Snappy Components
only. DO NOT USE parts
from the other Span range
of products .
4 5
Fit the trapdoor platform
Using the 3T method
th
to the 7 rung. add bracing frames. if
risk assessment requires,
toeboards could be
fitted at this stage.
4 5
Fit stabilisers to the base Clip 2 diagonal braces in
unit - see separate a zig-zag pattern from
section on stabilisers. the 7th to the 10th rung
on either side. Fit a
Insert 2 standard frames
to the lower frames and trapdoor platform to the
engage locking pins. 10th rung.
9
10
Using the 3T method, fit
Remove the trapdoor
rd
platform from the 3 bracing frames on either
th
rung and fit to the 14 side. Fit toeboards to
rung to form a working complete the build.
platform.
Assembly Guide
ASSEMBLY COMPONENTS
4m Platform Height
2m Platform Height
1. Guardrail Frame
1. Guardrail Frame
2. Bracing Frame
2. Bracing Frame
3. Toeboard Set
3. Trapdoor Platform
4. Horizontal Brace
4. 7 Rung Frame
5. Trapdoor Platform
5. Folding Diagonal Brace
6. Diagonal Brace
6. Horizontal Brace
7. 7 Rung Frame
7. Castors
8. Stabiliser
9. Folding Diagonal Brace
10. Castors
Safe Working Loads and Working Heights
(WAHR)
The total loading on the tower structure should not
exceed 360kg. Maximum platform height for indoor
and outdoor use is 4m.
3T Safety Standard - THROUGH THE TRAP
This is an approved method of tower construction
which, if carried out by a competent person,
complies with all current safety legislation.
Construction - basic principles
• Always install the trapdoor platform over the
ladder (if one is fitted).
• Ensure the trapdoor hinges to the
the tower (not the centre).
• Once the platform has been installed, climb, using
the approved method and SIT IN THE
TRAPDOOR OPENING.
• While seated, attach horizontal braces to the
frames to form guardrails on
BOTH SIDES OF
THE PLATFORM.
• See assembly instructions for specific placement
of guardrails.
• 2 braces are normally required each side -
although bracing frames can be used on the
outside if desired or specified in the instructions.
• Only when the platform is fully guarded is it safe
to stand up.
Dismantling
• Unlock the brace ends furthest away from the
trapdoor.
• DO NOT REMOVE BRACES UNTIL SITTING IN
THE TRAPDOOR.
REMEMBER - NEVER STAND ON AN
UNGUARDED PLATFORM
OUTSIDE of
