2m START FRAME
DESIGNATION
SPAN300 Double Width
EN1004 - 3 - 8/12 - XXCD
SPAN 300 Single Width
EN 1004 - 3 - 8/8 - XXCD
Span 300 Series
Instruction Manual
OPTION 2:
1m START FRAME
OPTION 3:
VX START FRAME
CEN designation of this instruction manual
EN 1298 — IM — en

Advertisement

loading

Related Manuals for Instant Upright Span 300 Series

Summary of Contents for Instant Upright Span 300 Series

  • Page 1 Span 300 Series Instruction Manual OPTION 1: OPTION 3: 2m START FRAME VX START FRAME OPTION 2: 1m START FRAME DESIGNATION SPAN300 Double Width CEN designation of this instruction manual EN1004 - 3 - 8/12 - XXCD EN 1298 — IM — en...

  • Page 2: Assembly Process

    WARNING NEVER STAND ON AN UNGUARDED PLATFORM SAFE WORKING LOADS AND WORKING HEIGHTS The safe working load at each level of platform is 360kg evenly distributed, regardless of whether one or two platforms are installed. Therefore, even if two platforms are installed side by side, total cumulative load shall not exceed 360kg distributed.

  • Page 3: Care And Maintenance Care And Maintenance

    USAGE ADVICE USAGE ADVICE • We recommend a minimum of two people to assemble, dismantle and move the platform tower. • We recommend a minimum of two people to assemble, dismantle and move the platform tower. • Check that all components are on site and in good working order. •...
  • Page 4 DISMANTLING / MOVING TOWERS To dismantle, follow the build process but in reverse order noting the following. • To remove the guardrail frames or braces, first unlock the hook at the end away from the trapdoor. • Sitting through the trapdoor, unlock the near end hook and remove the brace. To Move the tower to a new position, first prepare the tower.
  • Page 5 STABILISERS Stabilisers are to be used, when specified, to guarantee the structural stability of the tower. In addition, the ballast table is to be observed. Fig 2 Fig 3 Fig 4 2m single pla a tform 2.5m single platform 3m single platform Telescopic Stabiliser x = 3730mm x = 3929mm...
  • Page 6 ALTERNATIVE CONFIGURATIONS This manual details the sequence for the building of towers with ladder frames and a single platforms up to the working level. Alternative builds may be adopted as follows: 2 platforms at every level A second platform can be added (trapdoor not required) to each intermediate access platform level.
  • Page 7 OPTION 1 - SPAN 300 DW SPECIFIC PRODUCT INFORMATION 2m STARTING FRAME Table of parts and quantities Span 300 Double Width Towers - 2m, 2.5m and 3m lengths to EN1004 Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m in length) (SPAN300)* Tower Weight in kg (2.5m in length)(SPAN300)* Tower Weight in kg (3m in length) (SPAN300)* * Weight reduction (kg) for 300W Towers...
  • Page 8 DOUBLE-WIDTH TOWER 6m - BUILD SEQUENCESSHOWN USING THE SPAN300 (300W IS SAME)
  • Page 9 DOUBLE-WIDTH TOWER 6m...
  • Page 10 DOUBLE-WIDTH TOWER 6m WARNING NEVER STAND ON AN UNGUARDED PLATFORM...
  • Page 11 DOUBLE-WIDTH TOWER 6m...
  • Page 12 DOUBLE-WIDTH TOWER 5m...
  • Page 13 DOUBLE-WIDTH TOWER 5m...
  • Page 14 DOUBLE-WIDTH TOWER 5m...
  • Page 15 OPTION 1 - SPAN 300 SW SPECIFIC PRODUCT INFORMATION 2m STARTING FRAME Table of parts and quantities Span 300 Single Width Towers - 2m, 2.5m and 3m lengths to EN1004 Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m in length) (SPAN300, 300W) Tower Weight in kg (2.5m in length) (SPAN300, 300W) Tower Weight in kg (3m in length) (SPAN300, 300W) Weight reduction (kg) for 300W Towers...
  • Page 16 SINGLE-WIDTH TOWER 6m BUILD SEQUENCES SHOWN USING THE SPAN300 (300W IS SAME)
  • Page 17 SINGLE-WIDTH TOWER 6m...
  • Page 18 SINGLE-WIDTH TOWER 6m WARNING NEVER STAND ON AN UNGUARDED PLATFORM...
  • Page 19 SINGLE-WIDTH TOWER 6m...
  • Page 20 SINGLE-WIDTH TOWER 6m...
  • Page 21 SINGLE WIDTH TOWER - 5m...
  • Page 22 SINGLE WIDTH TOWER - 5m...
  • Page 23 SINGLE WIDTH TOWER - 5m...
  • Page 24 OPTION 2 - SPAN 300DW SPECIFIC PRODUCT INFORMATION 1m STARTING FRAME Table of parts and quantities Span 300 Double Width Towers - 2m, 2.5m and 3m lengths to EN1004 Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m in length) (SPAN300)* Tower Weight in kg (2.5m in length)(SPAN300)* Tower Weight in kg (3m in length) (SPAN300)* * Weight reduction (kg) for 300W Towers...
  • Page 25 DOUBLE-WIDTH TOWER 6m - BUILD SEQUENCESSHOWN USING THE SPAN300 (300W IS SAME)
  • Page 26 DOUBLE-WIDTH TOWER 6m...
  • Page 27 DOUBLE-WIDTH TOWER 6m...
  • Page 28 DOUBLE-WIDTH TOWER 6m...
  • Page 29 DOUBLE-WIDTH TOWER 5m...
  • Page 30 DOUBLE-WIDTH TOWER 5m...
  • Page 31 DOUBLE-WIDTH TOWER 5m...
  • Page 32 OPTION 2 - SPAN 300SW SPECIFIC PRODUCT INFORMATION 1m STARTING FRAME Table of parts and quantities Span 300 Single Width Towers - 2m, 2.5m and 3m lengths to EN1004 Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m in length) (SPAN300, 300W) Tower Weight in kg (2.5m in length) (SPAN300, 300W) Tower Weight in kg (3m in length) (SPAN300, 300W) Weight reduction (kg) for 300W Towers...
  • Page 33 SINGLE-WIDTH TOWER 6m BUILD SEQUENCES SHOWN USING THE SPAN300 (300W IS SAME)
  • Page 34 SINGLE-WIDTH TOWER 6m...
  • Page 35 SINGLE-WIDTH TOWER 6m...
  • Page 36 SINGLE WIDTH TOWER - 5m...
  • Page 37 SINGLE WIDTH TOWER - 5m...
  • Page 38 SINGLE WIDTH TOWER - 5m...
  • Page 39 SPECIFIC PRODUCT INFORMATION OPTION 3 - SPAN 300DW VX BRACE STARTING FRAME Table of parts and quantities Span 300 Double Width Towers - 2m, 2.5m and 3m lengths to EN1004 and WAHR Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m length) Tower Weight in kg (2.5m length) Tower Weight in kg (3m length)
  • Page 40 DOUBLE-WIDTH TOWER 6m...
  • Page 41 DOUBLE-WIDTH TOWER 6m...
  • Page 42 DOUBLE-WIDTH TOWER 6m...
  • Page 43 SPECIFIC PRODUCT INFORMATION OPTION 3 - SPAN 300SW VX BRACE STARTING FRAME Table of parts and quantities Span 300 Single Width Towers - 2m, 2.5m and 3m lengths to EN1004 and WAHR Platform Height (m) Work Height (m) Tower Height (m) Tower Weight in kg (2m length) Tower Weight in kg (2.5m length) Tower Weight in kg (3m length)
  • Page 44 SINGLE-WIDTH TOWER 6m SINGLE-WIDTH TOWER 6m...
  • Page 45 SINGLE-WIDTH TOWER 6m...
  • Page 46 SINGLE-WIDTH TOWER 6m...
  • Page 47 Instant Upright Ltd, Unit S1, Freil Avenue, Park West Industrial Park, Dublin 12, Ireland www.instantupright.com...
