- Page 1 XD LIGHT (Portable LED HeadLight System) User Manual Optical Device Medical Device System Engineering XENOSYS CO., LTD. 2, Venture-ro, 100 beon-gil, Yeonsu-gu, 22013 Republic Korea TEL. 82-32-875-9811~2 FAX. 82-32-875-9813 www.xenosys.co.kr / sales@xenosys.co.kr...
-
Page 2: Table Of Contents
COMPONENTS ..........................8 FUNCTIONS ............................ 9 OPERATING INSTRUCTION ......................11 BASIC TROUBLESHOOTING ......................16 SPECIFICATIONS.......................... 17 ELECTROMAGNETIC COMPATIBILITY ..................19 TRANSPORTATION ........................19 STORAGE ............................20 CLEANING INSTRUCTION ......................21 SERVICE & WARRANTY ......................21 Portable LED HeadLight System (XD Light) www.xenosys.co.kr... -
Page 3: Introduction
INTRODUCTION Portable LED Headlight System: XD Light is the medical device with lithium-ion battery and LED light source which is suitable for flashing on to watch the wound or surgery spot. As a portable device, it does not need supplementary holder and fiber optic cable. By the help of co-axial &... -
Page 4: Safety & Precautions
4. Do not use in the presence of a flammable anesthetic mixture with air, oxygen, or nitrous oxide. WARNING for Power Unit: 1. Do not use any undesignated charger by Xenosys. If any damage or unexpected hazard happens by the usage of undesignated charger, the manufacturer is free from the responsibility. - Page 5 4. LED optic outside emits heat, so be careful on touching. 5. Do not look directly into LED lens module or some one’s eyes to avoid the risk of permanent eye damage WARNING for Battery: Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
- Page 6 1. Do not connect any metallic objects between the cradle connector and battery. This may cause the defective on the charger and charger cradle. 2. Use only the charger which is provided by Xenosys on the phone jack. This may cause the defective on the charger and charger cradle.
-
Page 7: Features
FEATURES 1. Operating Principle XD Light adopts the way to deliver DC voltage from the battery to LED device through STEP-Down circuit and generate light speed through the lens. Even though battery voltage is reduced, XD Light allows LED to provide consistent brightness. -
Page 8: Components
① Control Unit (DCU) ② LED Lens Module (DLM82) (BPM010S05) ⑤ Gown Clip (GOC) ⑥ Screw driver, Universal Clip ④ Power Cord (LPC) 2. Optional ⑦ Dental Anti-curing Filter ⑧ LED Lens Module (DLM150) (For DLM82) Portable LED HeadLight System (XD Light) www.xenosys.co.kr... -
Page 9: Functions
⑧ FUNCTIONS 1. Control Unit (DCU) ① ⑤ ② ③ ④ ① Battery Remaining Signal: Show how much battery remains. Example) Green->Orange->Blinking Orange. Brightness Step Signal: Indicate from 1 step to 4 step Portable LED HeadLight System (XD Light) www.xenosys.co.kr... - Page 10 Warning – Do not use any other device randomly which may cause the defective reason. In case of using non-Xenosys-supplied charger with higher voltage (over 5V), it will cause the severe damage to main body. Please check if its Xenosys supplied charger and the serial Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
-
Page 11: Operating Instruction
If it’s Xenosys supplied one, then stop using and contact the distributor (dealer) or the manufacturer. If not, make sure to use Xenosys DC5V power supply. OPERATING INSTRUCTION A. Preparation before usage 1. Check components Components are shown on page 8~9. They can differ from the picture and replace or delete with new parts for better performance. - Page 12 Lithium-ion battery is expendables, thus if the operating time is shortened after full charge, we recommend exchanging new battery. ② Battery remaining signal LED D. Turn on light & Intensity change & Brightness step signal LED Intensity Change button ③ ① Power ON/OFF button Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
- Page 13 3. Adjust LED lens module up-down or left-right to locate the desired position. Caution – External LED lens module’s temperature will go up to max. 46℃ during usage, so be careful. 4. After finishing the usage, press the power ON/OFF button to turn off. Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
- Page 14 E. LED Lens Module circular connector 1. How to connect: To connect LED lens module circular connector to control unit, make XENOSYS logo facing in front and connect to the phone jack of control unit. ① Prepare to connect ②...
- Page 15 LED Lens Module attachment examples ① Rigid Headband ③ TTL Loupe of Xenosys ③ Flip-up Loupe of Xenosys ④ Normal glasses ④ Protective goggle of Xenosys Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
-
Page 16: Basic Troubleshooting
(Check the battery charged, we recommend remaining LED) exchanging with new battery as it is expendables. LED lens is intermittently Contact to local distributor or Check the wire near LED lens on & off Xenosys Portable LED HeadLight System (XD Light) www.xenosys.co.kr... -
Page 17: Specifications
A. Control Unit (DCU) ① Size: Refer to below photo ② Weight: 105 g B. LED Lens Module (DLM82) ① Size: Refer to below photo ② Weight: 57 g 1 500 1 8,5 Portable LED HeadLight System (XD Light) www.xenosys.co.kr... - Page 18 About 4 hours Charging Time (Full charge) Input: AC100~240V, 50-60Hz, 0.3A Medical Power Supply Output: DC5V High Power LED (White Color) Light Source DC3.62V Imbedded Battery 2950mA Li-ion Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
-
Page 19: Electromagnetic Compatibility
Recommend to choose one and more ways to solve the trouble in the following ways. Relocate the equipments receiving the interruptive wavelength. Put the each equipment in longer distance. Connect the equipment to the different outlets from the ones connected to other Portable LED HeadLight System (XD Light) www.xenosys.co.kr... -
Page 20: Transportation
2. Load XD Light boxes up and down evenly by handcart and any vehicle trunk to transport. 3. When you carry XD Light by hand, hold it with two hands firmly and disconnect charger, and power cord from the main-body for safe transportation. -
Page 21: Cleaning Instruction
1. This service & warranty statement applies to all countries to the extent that there is no special warranty rule. 2. All services & warranty should be provided by Xenosys Co., Ltd. or authorized personnel by Xenosys Co., Ltd. 3. Warranty becomes effective from the sales date for material, production defective, or defect Portable LED HeadLight System (XD Light) www.xenosys.co.kr... - Page 22 11. There are no user serviceable parts in this product. Please send the product to the distributor (dealer) for servicing. Technical description or manual is available upon request. 12. Warranty period of XD Light: 1 year (Only exception is for battery matter: 6 months) EU Representative (EU Repräsentant) 1.
- Page 23 ※ Revision List Version No. Release Date Revision Version 1.0 August 31, 2015 draft Version 2.0 November 19, 2015 draft (주)제노시스 인천광역시 연수구 벤처로 100길2 (송도동11-16) TEL. 032-875-9811~2 FAX. 032-875-9813 sales@xenosys.co.kr www.xenosys.co.kr / Portable LED HeadLight System (XD Light) www.xenosys.co.kr...
