- Page 1 L2S15 (Portable LED Headlight System) User Manual Optical Device Medical Device System Engineering XENOSYS CO., LTD. 2, Venture-ro, 100 beon-gil, Yeonsu-gu, Incheon 406-840, Korea TEL. 82-32-875-9811~2 FAX. 82-32-875-9813 www.xenosys.co.kr / sales@xenosys.co.kr...
-
Page 2: Table Of Contents
COMPONENTS ..........................8 FUCNTIONS ..........................9 OPERATING INSTRUCTION ...................... 14 BASIC TROUBLESHOTTING ..................... 19 SPECIFICATIONS ........................20 ELECTROMAGNETIC COMPATIBILITY ..................24 TRANSPORATION ........................24 STORAGE..........................25 CLEANING INSTRUCTION ......................26 SERVICE & WARRANTY ......................26 Portable LED HeadLight System (L2S15) www.xenosys.co.kr... -
Page 3: Introduction
The external figure of product is like below pictures. Please refer to components on page 8 ~ 9. Front View Rear View Isometric View Table A describes features of L2S15 and detail specifications are described from page 19 to 21. Model Power Spectrum... -
Page 4: Safety & Precautions
4. Do not touch the power cord with wet hand which may cause electric shock or equipment damage. 5. Do not use L2S15 with connecting directly to the battery pack during the operation or medical practice. Portable LED HeadLight System (L2S15) - Page 5 4. LED optic outside emits heat, so be careful on touching. 5. Do not look directly into LED lens module or some one’s eyes to avoid the risk of permanent eye damage WARNING for Battery: Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 6 1. Do not connect any metallic objects between the cradle connector and battery. This may cause the defective on the charger and charger cradle. 2. Use only the charger which is provided by Xenosys on the phone jack. This may cause the defective on the charger and charger cradle.
-
Page 7: Features
FEATURES 1. Operating Principle L2S15 adopts the way to deliver DC voltage from the battery to LED device through STEP- Down circuit and generate light speed through the lens. Even though battery voltage is reduced, L2S15 allows LED to provide consistent brightness. -
Page 8: Components
④ LED Lens Module (LLM1582) ⑥ Power Cord (LPC) ⑦ Power Supply (BPM010S05) ⑧ Battery for RC15 (AAA) 2. Optional ⑨ Dental anti-curing filter ⑩ LED Lens Module (LLM1574) ⑪ LED Lens Module (LLM1566) (Only for LLM1574, LLM1582) Portable LED HeadLight System (L2S15) www.xenosys.co.kr... -
Page 9: Fucntions
⑪ Optional LED Lens Module (LLM1566) Field of View: Ø66 mm @WD400mm FUCNTIONS 1. Main Body (LED Control Unit, LCU15) ④ ⑤ ⑦ Top View ② ③ ⑥ ① ⑧ Isometric View Front View Portable LED HeadLight System (L2S15) www.xenosys.co.kr... - Page 10 ⑧ Charging terminals 2. Battery Pack (BTP15) Top View ① Charging terminal Isometric View Front View ① Battery: 3.7V / 5200mAh Li-ion Warning – Read the warning for battery from page 5 to 6 before usage. Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 11 2. Push & hold the pairing switch more than 5 seconds -> Blue controlled other light blinking remote controllers. 3. Push & release On/Off button of remote controller -> Blue light will linger and off 4. Release pairing complete. Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 12 ② 3 types of LED Lens Module available (Choose one) Class Type Feature (Field of View) Reference Standard LLM1482 Ø82mm@WD400mm Basic Option 1 LLM1474 Ø74mm@WD400mm Option 2 LLM1466 Ø66mm@WD400mm 5. Charger (LCH15) ② ① Top View Front View ③ Isometric View Bottom View Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 13 Warning – Do not use any other device randomly which may cause the defective reason. In case of using non-Xenosys-supplied charger with higher voltage (over 5V), it will cause the severe damage to main body. Please check if its Xenosys supplied charger and the serial number.
-
Page 14: Operating Instruction
1. If the usage is done, press the power ON/OFF button to turn off. Then store it to the case after cleaning dirt or bloods for further use. Caution – When no-use for long time, make sure to remove the battery from the battery pack. Portable LED HeadLight System (L2S15) www.xenosys.co.kr... - Page 15 2. Store LED light in the place free from the air with pressure, temperature, humidity, wind, ray of light, dirt, salinity, and ion. 3. Store L2S15 in the place free from the declination, shack, and shock. 4. Store L2S15 in the place free from gas, smoke, and chemical fluid.
- Page 16 Below table will indicate LED lens module brightness (lx@WD400mm) & operating time. Illumination Brightness(lx) @WD400mm Operating STEP LLM0982 LLM0974 LLM0966 Time (hr) 12,000 13,000 17,000 22,000 24,000 32,000 30,000 32,000 44,000 39,000 43,000 59,000 Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 17 2. One hand of index finger will be on the battery release button, and another hand to hold sides of battery pack. Then press the battery release button and pull out the battery pack to downward at the same time to disassemble the battery. ① Battery Release Button Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 18 LED Lens Module attachment examples ① Headband ② TTL Loupe ③ Flip-up Loupe ④ Usual Glasses ⑤ Protective Goggle Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
-
Page 19: Basic Troubleshotting
Discharging time is too fast charged. (Check the battery charged, we recommend remaining LED) exchanging with new battery as it is expendables. Check the wire connection Contact distributor Light flickers intermittently part – loose contact or not. manufacturer Portable LED HeadLight System (L2S15) www.xenosys.co.kr... -
Page 20: Specifications
1. Measurement & Weight A. LED Control Unit (LCU15) ① Size: Refer to below photo ② Weight: 45 g 24,5 30,846 64,5 B. Battery Pack (BTP15) ① Size: Refer to below photo ② Weight: 130 g 64,5 Portable LED HeadLight System (L2S15) www.xenosys.co.kr... - Page 21 C. Charger (LCH15) ① Size: Refer to below photo ② Weight: 20 g 26,977 65,1 79 D. Remote Controller (RC15) ① Size: Refer to below photo ② Weight: 56 g (including AAA battery) 26,924 34,993 Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 22 1 8,5 F. Power Supply (BPM010S05) ① Size: 95(L)x53(W)x33(H) [mm] ② Weight: 176 g G. Power Cord (LPC) ① Size: 1.8 m ② Weight: 90 g (EU cord example and can differ from other cord) Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
- Page 23 Uniformity 2.4 W (max.) LED Operating Power 50,000 hours LED Life Span (Guaranteed Time) Replacement Components Battery Pack DC3.7V 5200mA Li-ion Input: AC100~240V, 50-60Hz, 0.3A Power Supply Output: DC5V Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
-
Page 24: Electromagnetic Compatibility
2. Load L2S15 boxes up and down evenly by handcart and any vehicle trunk to transport. 3. 3. When you carry L2S15 by hand, hold it with two hands firmly and disconnect charger, and power cord from the main-body for safe transportation.. -
Page 25: Storage
② Store the battery with separated from the main body in case of long-time no use. ③ Recommend to keep it in the dry condition with ambient temperature range of +15℃ ~ +25℃. Keep away from too hot or extremely cold places. Portable LED HeadLight System (L2S15) www.xenosys.co.kr... -
Page 26: Cleaning Instruction
1. This service & warranty statement applies to all countries to the extent that there is no special warranty rule. 2. All services & warranty should be provided by Xenosys Co., Ltd. or authorized personnel by Xenosys Co., Ltd. 3. Warranty becomes effective from the sales date for material, production defective, or defect under the normal use. - Page 27 9. If there is any defect happens which cannot be handled by troubleshooting in this manual, return it to the manufacturer. Then Xenosys will take care of it. If the qualified engineer determines that the defect comes from the abuse or improper use, warranty will not be applied.
- Page 28 ※ Revision List Version No. Release Date Revision Version 1.0 May, 2015 draft Xenosys Co., Ltd. 2, Venture-ro, 100 beon-gil, Yeonsu-gu, Incheon 406-840, Korea TEL. 032-875-9811~2 FAX. 032-875-9813 sales@xenosys.co.kr www.xenosys.co.kr / Portable LED HeadLight System (L2S15) www.xenosys.co.kr...
