THP700-IP/TS3100
INDUSTRIAL ROBOT SPECIFICATIONS
1.
Make sure that this instruction manual is delivered to the final
user of Toshiba Machine's industrial robot.
2.
Before operating the industrial robot, read through and
completely understand this manual.
3.
After reading through this manual, keep it nearby for future
reference.
INSTRUCTION MANUAL
DUST- & DRIP-PROOF TYPE
Notice
April 2011
TOSHIBA MACHINE CO., LTD.
STE85336-0
