- Page 1 SERVICE MANUAL High Wall Fixed R-410A 60Hz YH9FYC12BAH-A-X Read this manual before installation and operation Make sure that it is well kept for later reference...
-
Page 2: Table Of Contents
Contents Contents 1. Introduction ....................1 2. Specifications..................7 3. Sensors list ....................8 4. Piping diagrams ..................9 5. Operation range ..................10 6. Wiring diagrams..................7. Dimensional drawings................8. Conter of gravity ................... 9. Installations ..................10. Service Diagnosis ................11. Performance and cerves diagrams............. Domestic air conditioner... -
Page 3: Introduction
Introduction 1. Introduction 1.2 Safety Cautions Be sure to read the following safety cautions before conducting repair work. The caution items are classified into “Warning” and “Caution”. The “Warning” items are especially important since they can lead to death or serious injury if they are not followed closely. The “Caution” items can also lead to serious accidents under some conditions if they are not followed. - Page 4 Introduction Warning Do not repair the electrical components with wet hands . Working on the equipment with wet hands can cause an electrical shock Do not clean the air conditioner by splashing water. Washing the unit with water can cause an electrical shock.
- Page 5 Introduction Warning Be sure to use an exclusive power circuit for the equipment, and follow the technical standards related to the electrical equipment, the internal wiring regulations and the instruction manual for installation when conducting electrical work. Insufficient power circuit capacity and improper electrical work can cause an electrical shock or fire. Be sure to use the specified cable to connect between the indoor and outdoor units.
- Page 6 Introduction Do not install the equipment in a place where there is a possibility of combustible gas leaks. If a combustible gas leaks and remains around the unit, it can cause a fire. Be sure to install the packing and seal on the installation frame properly. If the packing and seal are not installed properly, water can enter the room and wet the furniture and floor.
- Page 7 Introduction Check the grounding, and repair it if the equipment is not properly grounded. Improper grounding can cause an electrical shock. Be sure to measure the insulation resistance after the repair, and make sure that the resistance is 1 M ohm or higher.
-
Page 8: Specifications
Specification 2 Specifications NOMINAL DISTRIBUTION SYSTEM VOLTAGE NOMINAL CAPACITY and NOMINAL INPUT n i l 3.51 Capacity rated Btu/h 12000 Power Consumption(Rated) 1.25 2.81 ³ 1.6*10 ³ TECHNICAL SPECIFICATIONS-UNIT Dimensions W*D*H 780×245×540 Packaged W*D*H 920×351×620 Dimensions 27.3 30.7 Sound level ELECTRICAL SPECIFICATIONS n i l Maximum running current... -
Page 9: Sensors List
Specification TECHNICAL SPECIFICATIONS-OTHERS Refrigerant type R410A Refrigerant charge 0.60 Refrigerant Maximum allowable distance circuit between indoor an outdoor Maximum allowable level difference Refrigerant control Capillary liquid Piping connections 12.7 (external diameter) drain Heat insulation type Both liquid and Gas pipes Max. -
Page 10: Piping Diagrams
Pinping diagrams Domestic air conditioner... -
Page 11: Operation Range
Operation range Domestic air conditioner... -
Page 12: Wiring Diagrams
Wiring diagrams 6.Wiring diagrams NOTE: 1.See above for wiring of heat pump type. 2.There are no dotted lines on cool only type.(marked with @ ),Wire is connected from 4 (marked with @ @ )on terminal block to 1. 3.Some of cool only type terminal block only have 1 2 and but no the parts... -
Page 13: Dimensional Drawings
Dimensinal drawings 7.Dimensional drawings 780mm 245mm 780mm 8.Center of gravity 780mm 245mm 338.3mm 113.7mm Domestic air conditioner... -
Page 14: Installations
Installations 9.Installations Preparation Selection of Installation Place Necessary Tools for Installation Indoor Unit Torque wrench Driver (17mm,22mm,26mm) Nipper Place, robust not causing vibration, where the body can be supported suf ciently. Hacksaw Pipe cutter Place, not affected by heat or steam generated in the vicinity, where inlet and outlet of the Hole core drill Flaring tool unit are not disturbed. - Page 15 Installations Installation of the Indoor Unit Drawing of pipe Floor fixing dimensions Floor fixing dimensions [ Rear piping ] of the outdoor unit of the outdoor unit (Unit:mm) Draw pipes and the drain hose, then fasten them with the adhesive tape (Unit:mm) [ Left ・...
- Page 16 Installations Outdoor unit Installation of Outdoor Unit Drawing for the installation of indoor and outdoor units Install according to Connection of pipes Power cable: -mod 07-12: 3G1.0mm -mod 3G2.5mm To bend a pipe, give the roundness as large as possible not to crush the pipe , -mod 07-12: 3G1.0mm and the bending radius should be 30 to 40 mm or longer.
- Page 17 Installations No gas leakage? On Drainage In case of gas leakage, tighten parts of pipe connection. If Please install the drain hose so as to be downward slope without fail. leakage stops, then proceed 6. steps Please don’t do the drainage as shown below. If it does not stop gas leakage, discharge whole refrigerants from the service port.
-
Page 18: Service Diagnosis
Service diagnosis 10.Service Diagnosis 10.1 Problem Symptoms and Measures Symptom Check Item Details of Measure Check to make sure that the rated voltage is None of the units Check the power supply. supplied. operates Check the indoor PCB Check to make sure that the indoor PCB is broken Equipment operates but does Diagnosis... - Page 19 Service diagnosis 10.3 Error Codes and Description indoor display Code indication Reference Description Page indoor Room temperature sensor failure u l i Indoor Malfunction The code indication that is listed above is the main fault 10.3.1 Thermistor or Related Abnormality Indoor Display E1: Room temperature sensor failure E2: Heat-exchange sensor failure...
- Page 20 Service diagnosis Thermistor resistance check method: Remove the connector of the thermistor on the PCB, and measure the resistance of thermistor using tester. The relationship between normal temperature and resistance is shown in the value of indoor thermistor. 10.3.2 EEPROM abnormal E4: indoor EEPROM error Indoor Display Method of...
- Page 21 Service diagnosis Pull out the terminals on the indoor Check whether terminals mainboard and reinsert them. on indoor pcb is well? Electrify the machine again and turn it on in the cooling operation, Measure voltage between the positions 1and 3 of Terminal CN5 on the indoor PCB the voltage is about 90-220vac Measure whether there is voltage pulse(0-5VDC)
-
Page 22: Performance And Cerves Diagrams
Performance and ceves diagrams performance curves cooling value-temerature table outdoor temp.(humidity 46%) indoor temp. DB/WB 18℃ 20℃ 25℃ 32℃ 35℃ 40℃ 43℃ 46℃ 2382 2357 3947 3536 3148 3070 2837 2106 18/12℃ 18/14℃ 2432 2407 4029 3618 3342 3148 2915 2166 20/15℃... - Page 23 Performance and ceves diagrams performance curves power consumption value-temp.table outdoor temp.(humidity 46%) indoor temp. DB/WB 18℃ 20℃ 25℃ 32℃ 35℃ 40℃ 43℃ 46℃ 1343 1398 1438 1534 1446 18/12℃ 1366 1422 1462 1566 1606 18/14℃ 1390 1446 1486 1590 1646 20/15℃...
- Page 24 Performance and ceves diagrams performance curves cooling discharge pressure.table outdoor temp. indoor temp. (humidity 46%) DB/WB 16℃ 19℃ 22℃ 15℃ 3090 3197 3303 25℃ 4134 4177 4262 30℃ 4134 4220 4262 35℃ 4177 4262 4390 40℃ 4220 4433 4433 45℃ 3259 3259 3385...
- Page 25 Performance and ceves diagrams performance curves cooling suction pressure.table outdoor temp. indoor temp. (humidity 46%) DB/WB 16℃ 19℃ 22℃ 15℃ 1100 1138 1176 25℃ 1472 1488 1518 30℃ 1472 1503 1518 35℃ 1488 1518 1563 40℃ 1503 1579 1579 45℃ 1161 1161 1205...
- Page 26 2015 Johnson Controls, Inc. www.johnsoncontrols.com Doc. No.: MH9FYCAH--151103 12...
