4.1 USB
Pin Function Type
1
VUSB
Power
2
D-
Differential USB differential data -
3
D+
Differential USB differential data +
4
ID
Analog
5
GND
Power
4.2 Headers
The board exposes two 15 pin connectors which can either be assembled with pin headers or soldered through
castellated vias.
9 / 15
Description
Power Supply Input. If board is powered via VUSB from header this is an Output
(1)
Selects Host/Device functionality
Power Ground
Arduino® Nano 33 BLE / Rev. 01 - 26/11/2021
Arduino® Nano 33 BLE
