2 Functional Overview
2.1 Board topology
Top:
Ref.
Description
U1
NINA-B306 Module BLE 5.0 Module
U2
LSM9DS1TR Sensor IMU
DL1
Led L
Bottom:
5 / 15
Board topology Top
Ref.
U6
PB1
DL2
Board topology bot
Arduino® Nano 33 BLE / Rev. 01 - 26/11/2021
Arduino® Nano 33 BLE
Description
MP2322GQH Step Down Converter
IT-1185AP1C-160G-GTR Push button
Led Power
