THE EASTMAN

Cradle Spreading Machine

E-Series

WARNING

This machine is equipped with drive belts and

roller tubes moving at high rates of speed.

Keep hands, arms, and loose objects away

from drive belts and rollers at all times.

Misuse of this machine or failure to follow all

safety instructions on this machine and in the

instruction manual may result in serious per-

sonal injuries.

779 Washington St., Buffalo, N.Y. 14203-1396 U.S.A. • (716)856-2200 • Fax (716)856-1140 or (716)856-2068

Form CR-50-0528

Quick Start Guide

Manufacturers of Eastman Cloth Cutting and Cloth Spreading Machines

Website: www.EastmanCuts.com

Technical Support:

1-800-872-5595

Eastman

Over a Century of Cutting Expertise

Need help?

Do you have a question about the E Series and is the answer not in the manual?

Page 1 Eastman ® sonal injuries. Over a Century of Cutting Expertise 779 Washington St., Buffalo, N.Y. 14203-1396 U.S.A. • (716)856-2200 • Fax (716)856-1140 or (716)856-2068 Manufacturers of Eastman Cloth Cutting and Cloth Spreading Machines Website: www.EastmanCuts.com Form CR-50-0528...
Page 2 In the "Table Length Menu" set "Load End" by pressing the "Find Load End" or "Teach Load End" buttons. Turn Main Power "ON" Note: "Find Load End", the machine travels until the limit switch is triggered. Note: Switching the main Set "Table End"...
Page 3 Note: "Find Table End", the machine travels until the limit switch is triggered. To "Teach Press "Spread Length" Table End", the operator manually drives the (Along the bottom) spreader to its end point, and "Enter Length" requires typing in the length. Press "Settings"...
Page 4 Eastman ® Familiarization 1. Spread/Rewind: Sets cradle direction. 2. Overfeed: Additional cradle control for automatic feeding. Less decreases material, more increases material. 3. Cradle Jog: Controls manual cradle feeding. Press to manually feed material. 4. Bidirectional Throttle: For manual spreading, controls direction and speed of machine. Also may be used to stop automatic spreading by twisting and releasing.
