Epson PowerLite Cinema 200 Product Information

Epson powerlite cinema 200: product information
Hide thumbs Also See for PowerLite Cinema 200:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

Projector Parts

Vertical lens shift knob
Control panel
Lamp cover
Ventilation slots
Adjustable foot
Input B (computer VGA)
Input A
(component video)
D4 port (used
mainly in Japan)
AC power inlet
Trigger out
port
Menu button
(displays on-screen menu)
Menu navigation
buttons
Focus button
Indicator
lights
Zoom button
Power
button
(correct shape of non-rectangular image)
Horizontal lens
shift knob
Lens cover
Infrared
receiver
S-Video port
Control (RS-232C) port
USB port
Infrared
receiver
®
Kensington lock port
Video port (composite video)
Source button
(switches input source)
Aspect button
(switches aspect ratio)
Esc button
(exits current menu item)
Keystone correction buttons
Epson PowerLite Cinema 200 Projector

Projector Specifications

General
Type of display
Size of LCD panels
Lens
Zoom ratio
Resolution
Color
reproduction
Brightness
Contrast ratio
Image size
Projection distance
Optical aspect ratio 16:9
Keystone correction
angle
Lens shift range
Noise level
Lamp
Type
Power consumption 200 W
Lamp life
(approximate)
Part number
Remote Control
Range
Battery
Dimensions
Height
Width
Depth
Weight
1/04
Epson PowerLite Cinema 200 Projector - 1
Poly-silicon Thin Film Transistor (TFT)
active matrix with Micro Lens Array
0.7 inches (18 mm) wide
F=2.1 to 2.8 mm, f=21.4 to 31.7 mm
1:1.5
1280 × 720 pixels (720p)
24 bit, 16.8 million colors
1300 ANSI lumens max. (Dynamic or
Living Room color mode)
1000:1
30 to 300 inches (0.76 to 7.6 m)
2.9 to 37 feet (0.9 to 11.3 m)
±
15° vertical
Vertical: 100% upward, 50% downward
Horizontal: 50% left and right
37 dB (Dynamic or Living Room color
mode)
28 dB (all other color modes)
UHE (Ultra High Efficiency)
1700 hours (Dynamic or Living
Room color mode)
3000 hours (all other color modes)
V13H010L28
30 feet (10 meters)
AA × 2
4.5 inches (114 mm)
17.3 inches (440 mm)
12.6 inches (320 mm)
11.8 lb (5.3 kg)
