CHARGE/RECHARGE INSTRUCTIONS

Charging the pump by AC adapter using household 220-240 AC voltage:
1. The pump must be charged for 10 hours or overnight with AC adapter powered by
household 220-240 AC voltage.
2. Plug the AC adapter power cord into the air pump power receptacle (FIG. 1).
3. Plug the other end of the AC adapter power cord into a household 220-240 Volt AC
electrical outlet (FIG. 2).
4. Slide the switch to " " position to charge/recharge the batteries (FIG. 3).
5. Initial Charge: Charge the pump for ten (10) hours or overnight with household AC
voltage.
6. When the pump is fully charged, remove the power cord (FIG. 4).
FIG (1)
Charging the pump using a standard automobile 12 Volt
DC power source:
1. The pump must be charged for 1 hour with 12 Volt DC
power source.
2. Plug the 12 Volt DC power cord into the air pump power receptacle (FIG. 5).
3. Attach the DC power cord plug into a standard 12 Volt DC automobile cigarette lighter
or 12V DC accessory outlet (FIG. 5).
4. Slide the switch to " " position to charge/recharge the batteries (FIG. 3).
5. Charge: Charge the pump for 1 hour with 12 Volt DC power source.
6. When the pump is charged, immediately remove the power cord.
NOTE: The LED light turns red during charging/recharging mode. If the LED light does
not light up, make sure the switch is in the " " position.
SAVE THESE INSTRUCTIONS
220~240V
110~120V
√
FIG (2)
Page 3
(166IO) AP642 ELECTRIC PUMP ENGLISH 4.875" X 7.25" 05/23/2019
FIG (3)
166
IO
FIG (4)
FIG (5)
