Sunbeam Contempo Fire Table Owner's Manual page 11

Natural Gas
Conversion
11. Align and connect the knob with gas valve tightly.
12. Connect the thermocouple with gas valve by screwing
the thermocouple nut clockwise by hand until the nut
cannot screw any more, then continue screwing the nut
3/4 circle clockwise using the wrench carefully
and gently.
NOTE: The thermocouple is made of copper,
DO NOT over bend to prevent dysfunctionality
during the assembly.
Hardware Used
Wrench
13. Stick and place the conversion label onto the
propane rating plate.
14. REMINDER: Perform leak test (refer to page 7).
11
gas valve
12
gas valve
13
Type of gas: propane CAUTION: This appliance has been converted to use natural gas. Propane orifice dia 2.21 mm,
natural gas orifice dia 4.18 mm.
Normal hourly input: 50,000BTU/hr (14.65 kW)
Jay Trends Sales
Rated Heat Input: 50,000BTU/hr (14.65 kW).
1901 Aut. Transcanadienne, Manifold pressure: 11 inch w.c. (2.74 kPa)
Type Gas: Natural gas
Dorval, QC., H9P 1J1, Canada Maximum inlet supply pressure: 13 inch w.c. (3.24 kPa) Manifold Pressure: 7 inches water column (1.74 kPa).
Minimum inlet supply pressure: 8 inch w.c. (1.99 kPa) This appliance was converted on (day-month-year) to
(insert gas type; e.g. Natural or Propane) gas with Kit. No. CAUTION: The gas pressure regulator provided with this appliance must be used.
(name and address of organization making this conversion), which accepts the responsibility that this
This regulator is set for an outlet pressure of 11 inches water column.
conversion has been properly made.
Item Number: Minimum Clearance From Unit To Combustible Construction: 72" (182.9cm) from the top,
Model No: 24" (61cm) from all sides and back.
Serial No: For Outdoor Use Only. If Stored Indoors, Detach and Leave Cylinder Outdoors.
Date Code: The gas supply must be turned off at the LP-gas supply cylinder when this appliance is not in use.
WARNING:
Do not store or use gasoline, or other flammable vapors and liquids, in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.
Complies with ANS Z21.97-2017 CSA 2.41-2017, Outdoor Decorative Gas Appliance Standards.
Cover must be removed when burner is in operation.
Removal of this marking will void compliance with standard ANS Z21.97-2017 CSA 2.41-2017.
Do not connect to a remote gas supply.
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
WARNING: Placing the cylinder too close to the appliance might cause the fire hazard or property loss or
even life hazard.
The instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using the appliance.
Follow all warnings and instructions when using the appliance.
If instructions or parts are missing. contact with 1-877-387-3639 or email to custserv@jaytrends.com.
propane rating plate
knob
thermocouple nut
conversion label
DANGER
by
CARBON MONOXIDE
HAZARD
This appliance can
WARNING: Improper
installation, adjustment,
alteration, service or produce carbon
maintenance can cause
property damage, personal monoxide which has no
injury or loss life. Refer to
the owner's information
odor. Using it in an
manual provided with this
appliance. Installation and
enclosed space can kill
service must be performed
by a qulified installer,
you. Never use this
service agency, or the gas
supplier.
appliance in an enclosed
space such as a camper,
tent, car or home.
1-877-387-3639 | Page 11
