Epson PowerLite 737c Product Information

Epson powerlite 737c: product information
Hide thumbs


Projector Parts

Focus ring
Card slot
Exhaust air vent
Foot adjust lever
Lens cap
Audio port
Video port
S-Video port
USB port
(Type B)
Rear adjustable
Power inlet


Type of display
Poly-silicon TFT active matrix
(native format)
24-bit, 16.8 million colors
2000 lumens (High Brightness mode)
1500 lumens (Low Brightness mode)
Contrast ratio
Image size
30 to 300 inches (0.8 to 7.6 meters)
3.2 to 39.7 feet (1.0 to 12.1 meters)
Zoom ring
Control panel
Security lock
I/R receiver
Video port
USB port
(Type A)
768 pixels (XGA)
Epson PowerLite 737c Projector
Front, rear, upside-down (ceiling mount)
1 W monaural
sound system
Optical aspect
4:3 (horizontal:vertical)
Zoom ratio
Noise level
36 dB (Low Brightness mode)
Supports USB (type B)
Projection Lamp
UHE (Ultra High Efficiency)
170 W
Lamp life
High Brightness mode: about 2000 hours
Low Brightness Mode: about 3000 hours
Part number
Remote Control
20 feet (6 meters)
Batteries (2)
Alkaline AAA
2.7 inches (70 mm), feet retracted
10.9 inches (276 mm)
7.6 inches (193 mm)
3.9 lb (1.8 kg)
Rated frequency
50/60 Hz AC
Power supply
100 to 120 VAC, 2.7 A
200 to 240 VAC, 1.1 A
Operating: 240 W
Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Operating: 20 to 80% RH,
(non-condensing) Storage: 10 to 90% RH
Epson PowerLite 737c Projector
