Epson PowerLite 735c Product Information

Epson powerlite 735c: product information
Hide thumbs Also See for PowerLite 735c:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual, User Manual
Card slot
Card reader
access light
Focus ring
Zoom ring
Lens cover
Video
Computer/
S-Video
port
Component
port
Video port
Power inlet
Remote control
holder

Projector Specifications

General
Type of display
Poly-silicon Thin Film Transistor
(TFT), active matrix
Size of LCD panels Diagonal: 0.9 inch (22.9 mm)
Lens
F=1.9 to 2.1, f=31 to 36 mm
Resolution
1024
Color reproduction 24 bit, 16.8 million colors
Brightness
2000 lumens (ANSI)
Control panel
Security lock
Air filter
Foot release
lever
RC receiver
Adjustable foot
Audio-In
USB
port
port
Remote control
Speaker
receiver
×
768 pixels (native format)
EPSON PowerLite 735c Projector
Contrast ratio
Image size
Projection distance 3.2 to 38.5 feet (0.96 to 11.7 meters)
Projection methods Front, rear, upside-down front
Internal sound
system
Optical aspect ratio 4:3 (horizontal:vertical)
Zoom ratio
Noise level
Keystone correction
angle
Projection Lamp
Type
Power consumption 150 W
Lamp life
Part number
Remote Control
Range
Battery
Mouse Compatibility
Supports USB
Dimensions
Height
Width
Depth
Weight
Electrical
Rated frequency
Power supply
Power
consumption
Environmental
Temperature
Humidity
2/03
400:1
30 to 300 inches
(ceiling mount), and upside-down rear
1 W monaural
1:1.16
39 dB
±15° vertical (maximum)
UHE (Ultra High Efficiency)
About 1500 hours
V13H010L18
20 feet (6 meters)
CR2025 lithium
2.8 to 3.1 inches (70 to 78.5 mm)
10.9 inches (276 mm)
7.5 inches (190 mm)
4.4 lb (1.9 kg)
50 to 60 Hz
100 to 120 VAC, 3.1 A
200 to 240 VAC, 1.5 A
Operating: 225 W
Standby: 5.5 W
Network standby: 35 W
Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Operating: 20 to 80% RH,
non-condensing
Storage: 10 to 90% RH,
non-condensing
EPSON PowerLite 735c Projector
1
-

Advertisement

Table of Contents
loading

Related Manuals for Epson PowerLite 735c

Summary of Contents for Epson PowerLite 735c

  • Page 1: Projector Specifications

    Standby: 5.5 W Network standby: 35 W Operating: 41 to 95 °F (5 to 35 °C) Storage: 14 to 140 °F (–10 to 60 °C) Operating: 20 to 80% RH, non-condensing Storage: 10 to 90% RH, non-condensing EPSON PowerLite 735c Projector...

  • Page 2: Computer Connector Pin Assignments

    PAL—60 SECAM HDTV (480i) HDTV (480p) HDTV (720p) HDTV (1080i) HDTV (1080i) The image is resized using EPSON’s SizeWise Computer Connector Pin Assignments Computer1/Component Video RGB, 15-pin micro-D-style connector. Here are the pin Resolution assignments: 640 x 350 640 x 480...

  • Page 3: Turning On The Projector

    6.5 to 7.5 ft 3 to 4 ft If you place the projector below the level of the screen, you’ll have to tilt it up by extending the feet as shown on page 5. This causes the projector to lose its square shape, but the projector automatically compensates.

  • Page 4: Starting Easymp

    Comp/EasyMP remote control. 2. Insert either the EPSON 802.11b card (for wireless presentations) or a memory card (for computer-free presentations) into the projector’s card slot. (If you do not insert a card, you see a screen prompting you to do so.) For detailed instructions on running your EasyMP presentation, see “Projecting Wirelessly in Ad Hoc Mode”...

  • Page 5: Adjusting The Height Of Your Image

    If the projected image isn’t square or has a “keystone” shape, do the following: ❏ If your image looks like projector off to one side of the screen, at an angle. Move it directly in front of the center of the screen, facing the screen squarely.

  • Page 6: Correcting Computer Images

    Caution: To avoid damaging the projector or lamp, never unplug the power cord when the power light is green or flashing orange. 6. Store the projector in the case that came with it or in a similar protective case. Using the Remote Control The remote control lets you access most of your projector’s...

  • Page 7: Using The Control Panel

    EasyMP button on the remote control or the EasyMP button on the projector (see page 7). 3. If you haven’t already done so, insert the EPSON 802.11b card with the blue label facing up. while Insert card into card slot Note: Only the EPSON 802.11b card is guaranteed to work.

  • Page 8: Presenting From A Memory Card

    To use EMP Slidemaker, you’ll need a memory card and a card reader on your computer. Depending on the type of card, you may also need an adapter to use it with the projector. The following standard Type II memory cards are supported: ❏...

  • Page 9: Creating A Scenario From Scratch

    5. If you need to rearrange cells, you can drag and drop them as necessary within the scenario window. 2/03 Click icon to see preview Thumbnail preview EPSON PowerLite 735c Projector...

  • Page 10: Projector Status Lights

    (with the memory card in the projector), click Cancel card from your computer and insert it in the projector. ❏ To run the scenario automatically when the projector is turned on, click . On the Edit Autorun window,...

  • Page 11: Cleaning And Replacing The Air Filter

    (such as an artist’s camel-hair brush). If the dirt is difficult to remove or if the filter is torn, replace it. Contact your dealer or EPSON to obtain a new one. 3. If you need to replace the filter, lift the tab and pull it upward to remove the filter.

  • Page 12: Replacing The Lamp

    Contact your dealer or call EPSON at (800) 873-7766 in the United States for a replacement lamp. Request part number . In Canada, please call (800) 463-7766 to locate V13H010L18 a dealer.

  • Page 13: Optional Accessories

    ® Kensington security lock You can purchase these accessories from your dealer, by calling EPSON at (800) 873-7766, or by visiting the EPSON Store at www.epsonstore.com (U.S. sales only). In Canada, please call (800) 463-7766 for dealer referral. Related Documentation...
