- Page 1 ” MODEL: ATV50UHD-1120 User Manual AFTER SALES SUPPORT info@tempo.org 1300 886 649 MODEL: ATV50UHD-1120 PRODUCT CODE: 703650 11/2020...
-
Page 2: Welcome
Welcome Congratulations on your purchase! This manual tells you all you need to know about using your new BAUHN product. ® Please take special note of any important safety and usage information presented with the symbol. All products brought to you by BAUHN are manufactured to the highest standards of performance and safety and, ®... -
Page 3: Table Of Contents
Contents Welcome On-Screen Set Up Troubleshooting Unpack and Prepare TV Setting Menus Specifications What's in the Box Channel Compliance and Picture Responsible Disposal Important Tips Sound Attaching the Stand Warranty Information Time Wall-Mounting the TV Lock Repair and Refurbished Connect to Power Option Goods or Parts Notice Connect your Antenna... -
Page 4: Unpack And Prepare
Unpack and Prepare What's in the Box Before installing your new TV, check you have everything needed. See the top flap of the box for how to handle the TV without damaging it! In the box you will find: A. 50" 4K Ultra HD TV with HDR B. -
Page 5: Important Tips
Important Tips • Place the TV on a level surface. • Place the TV away from any source that may generate heat or vibrations. • Make sure there is enough space around vents for airflow. • The remote control works up to 5 metres away from the TV. •... -
Page 6: Attaching The Stand
Attaching the stand • This TV is heavy! We recommend asking someone to help you lift it. • Unplug the TV from the power outlet before installing or removing the stand. • Only touch the frame, not the screen. • It is highly recommended to use safety straps for securing the TV. -
Page 7: Wall-Mounting The Tv
Wall-mounting the TV • Unplug the TV from the power outlet before wall-mounting. • Contact a professional for assistance with wall-mounting the TV. Required 200mm • VESA Mounting Bracket • 4 x M6*10mm screws (or longer as required) The TV comes with holes on the back panel for use with wall-mounting brackets (bracket not included). -
Page 8: Connect To Power
Connect to power Don't forget to plug in the TV to the power outlet. Leave the power switched off until installation is finished. Make sure the TV is switched off at the power outlet until you have finished connecting your cables. Connect your antenna Free-to-air TV in HD (High Definition) High Definition (HD) channels... -
Page 9: Controls And Connections
Controls and Connections Get to know your TV On/Standby light and Remote sensor Buttons on the TV • When the TV is on standby, press this button to turn the TV on. • When the TV is on, press to turn the TV off. Bottom view See next page for more info on the connections. -
Page 10: Ports On The Tv
Ports on the TV DIGITAL AUDIO (CVBS) ANTENNA IN OUT (OPTICAL) VIDEO IN ANTENNA IN Connect your antenna for live TV. (Antenna cable not included.) DIGITAL Connect an external digital audio device. Use an Optical cable AUDIO OUT (not included) to connect the unit with an amplifier, soundbar or other audio decoding device for digital audio signal output. - Page 11 AUDIO HDMI 3 HDMI 1 HDMI 2 (ARC) PC IN Headphone Connect to your headphones, amplifier or audio device, using an Jack AUX cable (not included). HDMI All-digital connection between the TV and any HDMI device. Use a high-speed Supports Ultra HD. Requires a High Speed HDMI cable (not HDMI cable for best picture and included).
-
Page 12: Remote Control
Remote Control Setup Insert two AAA size batteries according to the polarity markings (+/-) inside the compartment. Make sure the batteries are correctly aligned and properly pushed into AAA size place. batteries included Precautions When Using Batteries • Do not use old and new batteries together. •... -
Page 13: Using The Remote Control
Using the Remote Control To use the remote, point it towards the remote sensor at the front of the TV. The remote will not operate if its path is blocked. The remote has a range of up to about 5 metres from Remote Hints and Tips the TV at an angle of up to 30 degrees to either side of the sensor, as illustrated below. -
Page 14: Standard Remote
Standard Remote POWER: Switch the TV to On or Standby. GOTO: Jump to a different chapter of the DVD.* TV/RADIO / EJECT: Switch between TV or radio in DTV mode / Eject a disc (DVD). ANGLE: View DVD playback from different A-B: Repeat selected DVD scenes.* angles, if the DVD has this feature.* REPEAT: Repeat playback of a selected... - Page 15 SOURCE: Switch the input source. MUTE: Mute the sound. Press again or press V+ to restore the sound. D.MENU/GUIDE: Launch the TV Guide (DTV). VOL +/-: Turn the volume up/down. CH +/-: Change to the next or previous channel. DISPLAY: Display information of the current program.
-
Page 16: Easy Remote
Easy Remote (SOURCE): Switch the input source OK: Confirm your selection. : Switch the TV to On or Standby Display the channels list (DTV) : Press the UP/ (EXIT): Exit from the main TV MENU DOWN/LEFT/RIGHT buttons to menu displayed on the screen navigate INFO : Go to the next or... -
Page 17: On-Screen Set Up
On-Screen Set Up Make sure equipment is properly connected (as shown on pages 10-11) before connecting the TV to power. Make sure the TV is plugged in at the power socket and switched on. Press the (ON) button to turn on the TV. On/Standby light is WHITE in standby mode. -
Page 18: Tv Setting Menus
TV Setting Menus Menu Navigation Buttons Press the MENU button to display the TV settings menu. See the guide below for all the other buttons you'll need Once you have programmed any to use to adjust and change your settings. settings, the unit will retain them in its memory until you change them, even after turning the TV off. - Page 19 Picture Time Option • Picture Mode • Clock • System Language • Personal Mode Settings: • Time Zone • Audio Language • Contrast, Brightness, Saturation, • Off Time • Subtitle Language Tint, Sharpness • On Time • Hearing Impaired • Picture Settings: Colour Temp, •...
-
Page 20: Channel
Channel Option Description Automatically tune all available free-to-air TV channels. Adjust settings (default settings are set for Auto Tuning Australia). Press OK to start scanning. Manually select and tune analog TV channels. (Analog TV is no longer supported in Australia). Current channel: Press the buttons to select the channel number to save the tuned signal. - Page 21 Channel Edit Use the buttons to highlight a channel. Option Description Delete Press GOTO to delete the highlighted channel. Skip A-B to skip the highlighted channel. Press Favourite Press to add the channel to the Favourites list. TV SETTING MENUS | 21...
-
Page 22: Picture
Picture Picture Mode Original (default): Basic picture suitable for home use, with reduced power consumption. Home Images are for reference only. : Enhanced brightness, contrast, colour depth and edges for standing out in Dynamic very bright places such as storefronts. : Picture with enhanced brightness for bright home environments. - Page 23 Picture Settings Option Description Colour Temp Adjust the on-screen colour temperature. Noise Reduces picture noise to improve picture quality. Reduction HDMI Mode Adjusts HDMI input mode to best suit your device. Select the screen size. Depending on the input signal, the available Aspect Ratio screen sizes may be different.
-
Page 24: Sound
Sound Option Description Sound Mode Select preset sound modes. Treble Adjust the levels of higher pitched sounds (adjustable when in personal mode). Bass Adjust the levels of lower pitched sounds (adjustable when in personal mode). Balance Adjust the audio output between the left and right speakers. Auto Volume Turn On to keep the volume level consistent. -
Page 25: Time
Time Option Description Clock Displays time values from the TV broadcast signal. (Not user adjustable). Time Zone Select your timezone. Off Time Set the time and frequency for the TV to go into standby mode. Set the time, frequency, channel and volume level for the TV to turn on. On Time Note: The TV must be in standby mode to turn on. -
Page 26: Lock
Lock 0000 Factory Password: Enter the factory password '0000' using the number buttons 4711 Master Password: on the remote and select 'OK' on-screen. If you changed your password but forgot it, you can still use the master password. Option Description Lock System Enable/disable the lock on the system. - Page 27 Hotel Mode Option Description Hotel Mode Turn On/Off Hotel Mode. Source Lock Turn On/Off the lock on available sources. Default Source Set a default input source. Default Prog Set the default program. Default Volume Set the default volume level. Max Volume Set a limit to the maximum volume level.
- Page 28 Option Option Description System Language Select your preferred On Screen Display language. Audio Language Select your preferred audio language. (Available for digital channels, depending on the program). Subtitle Language Select the language for subtitles (available for digital channels, depending on the program). Turn On or Off.
- Page 29 PVR File System To make changes to PVR (Personal Video Recording), ensure your USB drive is inserted into the TV. Check the troubleshooting section if you're having problems setting up your USB device. Option Description Select Disk Select the USB drive. Check PVR File System Check the health of the USB drive file system.
- Page 30 HDMI CEC Setup This feature allows for your TV and your connected HDMI device to be controlled by one remote. Press the SOURCE button on the TV or remote control to select the HDMI input source. Option Description HDMI CEC (Consumer Electronics Turn HDMI CEC On/Off.
-
Page 31: High Dynamic Range (Hdr)
High Dynamic Range (HDR) About the HDR feature High Dynamic Range (HDR) is a picture feature on your TV that attempts to mimic the way visuals are perceived in real life by the human eye. By using this feature, the TV can reproduce greater dynamic range of luminosity by capturing and then combining several different exposures. -
Page 32: Tv Guide
TV Guide (Free to air TV) TV Guide Functions To access the TV Function Remote Button guide, press the GUIDE button on the Move between columns. remote. To activate the TV Select a channel or programme. Channels use the buttons to select View TV Guide for the next day. -
Page 33: Recording
Recording Important Tips: • Back-up your personal data before plugging in your USB to the TV. We do not assume liability for any loss of data due to misuse or malfunction. • You cannot change channels while in recording mode. •... -
Page 34: Recording Live Tv
Recording, scheduled recording and pause Before you can record with this TV (including time-shift recording), you must live TV functions only work in DTV mode insert your USB storage device into the (free-to-air). USB port. Recording Live TV SOURCE Instant Recording Press once - start recording. -
Page 35: Pause Live Tv (Time-Shift)
Pause Live TV (Time-shift) Recording, scheduled recording and pause live TV functions only work in DTV mode Temporarily pause the live TV signal, then resume (free-to-air). playback at your convenience. SOURCE Before you can record with this TV (including time-shift recording), you must insert your USB storage device into the USB port. -
Page 36: Usb Mode
USB Mode You can only play Photos in the Photo category, Music in the Music category and so on. Make sure you select the correct category for the file you wish to play. Set up Insert your USB into a USB port on the TV. Press the SOURCE button to select 'USB' mode or press the MEDIA button on the remote. - Page 37 Playback Functions Music Function Remote Button Playback of different media types have different controls. Navigate to a folder or file Photo Play a track Function Remote Button Navigate to a folder or file Fast forward or rewind the track Skip or restart the current track Display a photo Hide or display the on-screen Return to the file list...
- Page 38 Video Text Function Remote Button Function Remote Button Navigate to a folder or file Navigate to a folder or file Play a video Open the text file Pause the video Navigate to the next/previous page Resume playback Return to the file list Stop playback Fast forward or rewind the track Skip or restart the current track...
-
Page 39: Troubleshooting
Troubleshooting If you experience problems with your TV, check below for advice. If you don't find a solution here, contact After Sales Support on 1300 886 649. Problem Solution • Check the power outlet is turned on. • If using a multi-outlet, check if it is working properly. To check whether a power strip is working properly, No power plug the TV’s power plug directly to a wall outlet and make sure the white indicator light on the TV is lit. - Page 40 Problem Solution • Ensure that all equipment is connected properly. If you are using an external device, turn it off, then turn it on again. If it says there is no signal on the screen, choose the correct source input. •...
- Page 41 Problems relating to your USB media storage device Problem Solution • First, refer to the instructions describing how to use USB devices with this TV. • If the problem still occurs, your USB device may not be compatible. My TV does not •...
-
Page 42: Specifications
Specifications Active screen size With stand: 1160.2 x 125.7cm (diagonal) 226.3 x 708.9 mm Dimensions (W x D x H) Resolution 3840 x 2160 Without stand: 1123.5 x 77.6 x 649.1 mm Aspect ratio 16:9 8.7kg Refresh rate 60Hz Weight Gross 11.6kg HDMI version... -
Page 43: Compliance And Responsible Disposal
Compliance and Responsible Disposal Packaging The packaging of your product has been selected from environmentally friendly materials and can usually be recycled. Please ensure these are disposed of correctly. Plastic wrapping can National Television and Computer Recycling be a suffocation hazard for babies and young children, please ensure all packaging materials are out of Scheme reach and are safely disposed of. -
Page 44: Warranty Information
Warranty Information The product is guaranteed to be free from defects in workmanship and parts for a period of 12 months from the date of purchase. Defects that occur within this warranty period, under normal use and care, will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and labour. -
Page 45: Repair And Refurbished Goods Or Parts Notice
Repair and Refurbished Goods or Parts Notice Unfortunately, sometimes faulty products are manufactured, which need to be returned to the supplier for repair. Please be aware that if your product is capable of retaining user-generated data (such as files stored on a computer hard drive, telephone numbers stored on a mobile telephone, songs stored on a portable media player, games saved on a games console or files stored on a USB memory stick) during the process of repair, some or all of your stored data may be lost. - Page 46 Notes...
- Page 47 Notes...
- Page 48 Online support Visit www.bauhn.com.au for software updates to keep your TV up-to-date, as well as the latest User Manual for information on the updated features. Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product.
