Please read this manual carefully before installation and keep it for future reference.
Installation Manual
Signature Series
MCVP* & MCHP* Series Coils
Due to updates and constantly improving performance, the information and instructions within this
manual are subject to change without notice. Please visit www.mrcool.com/documentation to
ensure you have the latest version of this manual.
Version Date: 05-24-21
Advertisement
Table of Contents
Related Manuals for MrCool Signature MCVP Series
Summary of Contents for MrCool Signature MCVP Series
- Page 1 MCVP* & MCHP* Series Coils Due to updates and constantly improving performance, the information and instructions within this manual are subject to change without notice. Please visit www.mrcool.com/documentation to ensure you have the latest version of this manual. Version Date: 05-24-21...
-
Page 2: Table Of Contents
As with any mechanical equipment, contact with sharp sheet metal edges can result in personal injury. Take care while handling this equipment and make sure to wear gloves and protective clothing. Manufactured By: MRCOOL , LLC ® 48 Remington Way Hickory, KY 42051 Page 1 mrcool.com... - Page 3 M C V P 2 4 A N P A MRCOOL 2nd Gen Coil Metering Device O = Orifice T = TXV Air Flow C = Capillary M = Upflow/Horizontal P = Piston V = Upflow H = Horizontal Refrigerant...
-
Page 4: General
NOTE: The coil cabinet has six screw clearance holes which should be aligned with the furnace engagement holes. Secure the coil cabinet to the furnace or air handler " screws. Air Leakage All indoor cabinets MUST be taped after installation to seal Page 3 mrcool.com... -
Page 5: Refrigerant Line Connections
The heat shield must be in place to prevent heat NOTE: The coils are shipped with a factory-installed damage during brazing. See Figure 2. system matches with this coil require use of a check/ expansion valve. mrcool.com Page 4... -
Page 6: Leak Testing, Evacuating And Charging
Do not remove the water-saturated rags from the cabinet and piping until the piping has cooled completely. NOTE: To prevent any possibility of water damage, properly insulate all parts of the expansion valve assembly the valve and its surrounding ambient temperatures. Page 5 mrcool.com... -
Page 7: Sealing Ducts
AFTER COIL) TRAPS ARE REQUIRED ON ALL SLOPE A MINIMUM OF DRAIN LINES CONNECTED TO COIL. ONE INCH PER 10 FT. TRAPS MUST BE DEEP ENOUGH TO OFFSET MAXIMUM STATIC DIFFERENCES — GENERALLY, TWO INCHES. Figure 6. mrcool.com Page 6... -
Page 8: Blower Speed Selection
36ANPA 14.5 1200 hole plugs into test holes. 36BNPA 17.5 1200 17.5 1400 48BNPA 17.5 1600 1400 48CNPA 1600 49CNPA 1600 50/60CNPA 1600 60CNPA 2000 60DNPA 24.5 2000 Table 2. Page 7 mrcool.com... -
Page 9: Maintenance
Ensure that the distributor lines are not rubbing together or kinked. All tubes must have enough clearance from other metal parts. Use wire ties to secure tubes to prevent movement that could cause the refrigerant tubing to fail. mrcool.com Page 8... - Page 10 Please read this manual carefully before installation and keep it for future reference. Signature Series Consult with the sales agency or manufacturer for details.
