Installation Diagram

Installation Diagram
4
Safety Precautions
CAUTION
To prevent wall damage, use a stud nder to
•
locate studs.
A minimum pipe run of 3 metres is required
•
to minimise vibration & excessive noise.
Two of the A, B, and C air circulation pathways
•
must be free from obstructions at all times.
This illustration is for demonstration
•
purposes only.
The actual shape of your air condtioner may
•
be slightly di erent.
Copper lines must be independently insulated.
•
NOTE: The installation must be performed in
accordance with the requirement of local and
national standards. The installation may be
slightly di erent in di erent areas.
3
Remote
controller
holder
5
SENA/18HF/MOZ
SENA/30HF/MOZ
SENA/36HF/MOZ
SENA/48HF/MOZ
2
Mounting screw
Installation plate
(1)
Mounting screw
ST3.9×25-C-H
Remote
controller
holder
1
Clip anchor
1
2
Drainage
Pipe
Signal
cable
5 4 3
Outdoor Unit
Power Cable
The maximum
amount of the
connection cables is 5.
This section is for
reference only.
Installation
plate
Clip anchor
Refrigerant
pipe
(2)
 
