5 Network

Network screen includes Network status, Static Routing, WAN Setting, LAN Setting, Qos.
Network status is same as in the Running-->Network Status

5.1 WAN Setting

You can setup WAN connection here. No
The WAN connection can work under the router or bridging mode. You can bind the LAN
port or WIFI to the WAN connection.

5.1.1 WAN Connection Named Rule

The WAN Connection ( Network Name) named rule as below:
Numerical order_Keywords_Bridege or Router mode_PVC/VLAN information
Content
Numerical order
Keywords
Bridge or Router
VLAN
For Example：
1_INTERNET_R_VID_2 (The WAN Connection is used for INTERNET, working mode is
Router, VLAN ID is 2)
2_INTERNET_B_VID_ (The WAN Connection is used for INTERNET, working mode is
Bridge, VLAN ID is Null)
Definition
Sequence number
TR069
INTERNET
TR069_INTERNET
B
R
VID_Z
www.wodaplug.com
WDS104HW
WIFI ONU User Manual
Description
To identify the WAN Connection,
following the next rule: based the
sequence of the WAN Connection
created, number in sequence
increasing, no reuse the number have
been used
The connection is used for TR069
The connection is used for INTERNET,
not support the TR069
The connection is used for INTERNET
and the TR069
Bridge Mode
Router Mode
Z of VID_Z is the VLAN_ID value (for
untag
WAN Connection, value of Z is Null
and do not appear in the connection's
name）
