WDS104HW
WIFI ONU User Manual
WDS104HW WIFI ONU User
Manual
www.wodaplug.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WDS104HW WIFI ONU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wodaplug WDS104HW WIFI ONU

Summary of Contents for Wodaplug WDS104HW WIFI ONU

  • Page 1 WDS104HW WIFI ONU User Manual WDS104HW WIFI ONU User Manual www.wodaplug.com...

  • Page 2: Table Of Contents

    7.1 Basic setting ......................20 7.2 URL Filter ......................20 7.3 IP Filter ......................... 20 8 System ..........................21 8.1 Management ......................21 8.2 System Upgrade ....................22 8.3 Device Reboot ...................... 24 8.4 Restore Factory ....................24 8.5 System Log ......................24 www.wodaplug.com...

  • Page 3: Hardware Setup

    Open the box and remove the ONU and installation guide. Cable Power adapter If any parts are incorrect, missing, or damaged, contact your On Networks dealer. Keep the carton and original packing materials in case you need to return the product for repair. www.wodaplug.com...

  • Page 4: Hardware Features

    On: Ethernet connection is normal; LAN1-2 Blinking: Data is being transmitted through the Ethernet port; Off: Ethernet connection is not set up; WIFI Blinking：Data is being transmitted Off：The WLAN function is disabled System On：CATV optical normal（>-9dBm） *CATV Off：The CATV signals are not received（<-9dBm） www.wodaplug.com...

  • Page 5: Position Your Onu

    2.4 GHz cordless phone. •Away from any large metal surfaces, such as a solid metal door or aluminum studs. Large expanses of other materials such as glass, insulated walls, fish tanks, mirrors, brick, and concrete can also affect your wireless signal. www.wodaplug.com...

  • Page 6: Connect Your Onu

    3. Please use the delivery-attached power adapter to the ONU, and plug the power adapter into an outlet. Wait for the Power LED on the front panel to light. If no LEDs are lit, press the Power On/Off button on the rear panel of the ONU. www.wodaplug.com...

  • Page 7: Getting Start

    (general subscribers default user name and password are both admin for login, administrator user name and password are “adminisp” and “adminisp”), and select your preferred language. Click Enter button and enter the WEB management interface. www.wodaplug.com...
  • Page 8 WDS104HW WIFI ONU User Manual Login to the WEB management interface Note: You can modify the password after entering WEB management interface. Please refer to system maintenance “Management” for related operation. www.wodaplug.com...

  • Page 9: Know Web Management Interface

    Basic Setting. URL Filter. MAC Filter. IP Filter. . Application ALG Setting. Dynamic DNS. UPnP. DMZ Setting. Port Forward. IGMP Setting. System System Log. Kernel Log. Log server. Device Reboot. System Upgrade. Restore Factory. Management. TR069 Management. Diagnosis Ping Test. Tracert Test www.wodaplug.com...

  • Page 10: Running

    Product Information shows Product Model, Product Function, Hardware Version, Software Version and Compile Time. 4.2 Network Status Click Network Status to display the following screen: The page will show WAN connection status and LAN status. WAN Status shows current system WAN Connection Name, Connect Type, Connect www.wodaplug.com...

  • Page 11: Wireless Status

    Wireless Status shows current Wi-Fi SSID, MAC, Signal, Transmission and so on. 4.4 Configuration Wizard Click Configuration Wizard to display the following screen: The Configuration Wizard screen provide rapid configuration, you can choose in DHCP Mode, Static Mode and PPPoE Mode based on your network. www.wodaplug.com...

  • Page 12: Network

    For Example： 1_INTERNET_R_VID_2 (The WAN Connection is used for INTERNET, working mode is Router, VLAN ID is 2) 2_INTERNET_B_VID_ (The WAN Connection is used for INTERNET, working mode is Bridge, VLAN ID is Null) www.wodaplug.com...

  • Page 13: Default Wan Connection And Router Mode

    2) In static mode, the IP address is set statically. You need to enter the IP address, subnet mask, IP addresses of the active and standby DNS servers, and default gateway. 3) In PPPoE mode, you need to enter the user name and password. www.wodaplug.com...
  • Page 14 Bridge Mode: If you use bridge mode, L2 frame produced by WAN port and port binding to WAN is transparent transmission. Under this application condition, PC or other terminal after connecting will get IP address from up-layer device. www.wodaplug.com...

  • Page 15: Add An Bridge Mode Wan Connection

    As the following figure configured, WAN 1 is the default WAN in Router Mode, and we set up WAN2 to Bridge Mode. Port1 is bound to the WAN2 Click SAVE-->Apply button , then we get the ‘2_INTERNET_B_VID_’ Connection. You can set up serval WAN Connection to carry out different service to subscriber. www.wodaplug.com...

  • Page 16: Lan Setting

    LAN Setup screen ★ Tips: DHCP is the abbreviation of Dynamic Host Configuration Protocol which can assign IP address, Subnet Mask, Default Gateway of LAN Client on TCP/IP automatically. www.wodaplug.com...

  • Page 17: Wireless

    The Wireless Settings screen lets you view or configure the wireless network setup. There are Wireless Status, Basic Setting and MAC Filter su-menu. 6.1 Base Setting In Basic Setting, you can enable or disable WIFI, and set wireless channel and work model etc. www.wodaplug.com...
  • Page 18 Select this check box to enable the WMM protocol support Encryption method Select the authentication from None, WEP, WPA-PSK, WPA2 –PSK and Mixed WPA2/WPA –PSK. If you choose one encryption method, you need configure the authentication method and KEY. www.wodaplug.com...

  • Page 19: Mac Filter

    In this screen, you can choose the SSID Select and enable/disenable MAC Filter. If you enable the MAC Filter, Can choose two rules, MAC White list and MAC Black list. In MAC address table, you can add the corresponding MAC address. www.wodaplug.com...

  • Page 20: Security

    In URL Filter screen, Provide URL Filter table, Click add button to add corresponding rules. 7.3 IP Filter In IP Filter screen, Provide enable/disable IP Filter, you can choose whitelist or blacklist, Click Apply button to add corresponding rules. www.wodaplug.com...

  • Page 21: System

    Administrator. The second user name is admin, user level is Guest. Click corresponding Modify button, these two user names and passwords can be made relevant changes. Click the following add button, you can add relevant users, and set added user level, user name, corresponding passwords. As displayed below. www.wodaplug.com...

  • Page 22: System Upgrade

    WDS104HW WIFI ONU User Manual 8.2 System Upgrade Device Software Upgrading can update device software version. Click ‘Choose File’ button, and choose corresponding upgrading file. Click upload button, and then system will pop-up a windows to confirm uploading file. www.wodaplug.com...
  • Page 23 WDS104HW WIFI ONU User Manual After that ,you can click to upgrade. In upgrade. www.wodaplug.com...

  • Page 24: Device Reboot

    Log basic setting can be chosen to enable or disable log. Log pri includes Emergency, Alert, Critical, Error, Warning, Notice, Information, Debugging, a total of eight categories. It can be chosen into different log pri according to different operation situation. Click submit www.wodaplug.com...
  • Page 25 WDS104HW WIFI ONU User Manual button to finish relevant setting. Log events record relevant log events information that happened, it can clean relevant log information and export log information. As displayed below. www.wodaplug.com...
