  • Page 1 Wi-Fi EOC Slave Quick Start Guide...

  • Page 2: Table Of Contents

    Catalog 1. Hardware Setup ......................... 3  1.1 Unpack Your EOC slave ..................... 3  1.2 Hardware Features ......................3  1.3 Position Your EOC Slave ....................5  1.4 Cable Your EOC Slave ......................5  2 Getting Start ..........................6  2.1 Prepare for login the EOC slave web management ............. 6  2.2 Login the Web Management Interface ................

  • Page 3: Hardware Setup

    1. Hardware Setup Getting to know your EOC slave The Wi-Fi EOC slave provides you with an easy and secure way to set up a wireless home network with fast access to the Internet over a coaxial cable network. The EOC slave has a built-in EOC slave to work with the EOC master of the Internet service providers.
  • Page 4 The back panel has the connections and button shown in the following figure. Interface Qty. Description Cable Connect to uplink CATV network Connect to STB or TV by Cable Ethernet LANn ports for connecting to PC，can work on Router Mode. WAN connection can get the IP address from upper-layer device.

  • Page 5: Position Your Eoc Slave

    •Off. No link is detected on this port. Blinking green. Data is being transmitted or received over the WIFI wireless link. OFF. No wireless PC connected. 1.3 Position Your EOC Slave The slave lets you access your network from virtually anywhere within the operating range of your wireless network.

  • Page 6: Getting Start

    2 Getting Start 2.1 Prepare for login the EOC slave web management Before you login the EOC slave, you should confirm the connect between the CPE and your PC is normal. Configuring the IP address of your PC to 192.168.1.X（2~254）, subnet mask Step 1 is 255.255.255.0，gateway is 192.168.1.1.

  • Page 7: Login The Web Management Interface

    2.2 Login the Web Management Interface Open the WEB browser (recommend IE), enter http://192.168.1.1 in the address bar, and then press enter to display the login interface, as shown in figure. Please input user name and password (general subscribers default user name and password are both admin for login, administrator user name and password are “adminisp”...

  • Page 8: Know Web Management Interface

    3 Know WEB Management Interface WEB management interface can rapidly complete required function configurations. This chapter will lead you to understand and become familiar with WEB management interface. 3.1 WEB Management Interface Introduction WEB management interface introduction 1) The sub-menu area 2) The main menu area 3) Display the content 3.2 Main Menu Introduction...

  • Page 9: Running

    4 Running Running screen includes Device information, Network Status, Wireless Status and Configuration Wizard. 4.1 Device information Click Device information to display the following screen: Product Information shows Product Model, Product Function, Hardware Version, Software Version and Compile Time. 4.2 Network Status Click Network Status to display the following screen: The page will show WAN connection status and LAN status.

  • Page 10: Wireless Status

    LAN Status will show client ID, IP address, MAC Address and Hostname. Note: Refresh button is for refresh the information of explore 4.3 Wireless Status Click Wireless Status to display the following screen: Wireless Status shows current Wi-Fi SSID, MAC, Signal, Transmission and so on. 4.4 Configuration Wizard Click Configuration Wizard to display the following screen: The Configuration Wizard screen provide rapid configuration, you can choose in DHCP...

  • Page 11: Network

    5 Network Network screen includes Network status, Static Routing, WAN Setting, LAN Setting, Qos. Network status is same as in the Running-->Network Status 5.1 WAN Setting You can setup WAN connection here. No The WAN connection can work under the router or bridging mode. You can bind the LAN port or WIFI to the WAN connection.

  • Page 12: Default Wan Connection And Router Mode

    Bridge, VLAN ID is Null) 5.1.2 Default WAN Connection and Router Mode There is a default WAN connection, 1_INTERNET_R_VID_ as below. It works on Router Mode, DHCP, VLAN Disable. LABEL DESCRIPTION Network Name Name of the WAN connection, you can add a new WAN connection or edit a exist WAN connection Mode Bridge or Route mode.
  • Page 13 gateway. 3) In PPPoE mode, you need to enter the user name and password. Note: All the ports are bound with the default Router Mode WAN Connection. If you setup another Bridge Mode WAN connection, the port which you choose to bind with the bridge WAN connection will de-bind with the WAN connection.

  • Page 14: Add An Bridge Mode Wan Connection

    Click the Save button to save the configuration. And then click the Apply button to let the configuration come into operation. 5.1.3 Add An Bridge Mode WAN Connection As the following figure configured, WAN 1 is the default WAN in Router Mode, and we set up WAN2 to Bridge Mode.

  • Page 15: Lan Setting

    5.2 LAN Setting The LAN Setup screen allows configuration of LAN IP services such as Dynamic Host Configuration Protocol (DHCP). The device is shipped preconfigured in a router mode and to use private IP addresses on the LAN side and to act as a DHCP server. The router’s default LAN IP configuration is: •LAN IP address.

  • Page 16: Wireless

    1. DHCP Server: The DHCP function will go into effect if you select “Enable” as the figure beside. 2. IP Pool Starting Address: The starting IP address which DHCP Server automatically starts. 3. IP Pool Ending Address: The ending IP address which DHCP Server automatically ends.
  • Page 17 Basic Set Area LABEL DESCRIPTION WIFI Enable or disable WLAN Channel Set the operating channel manually by selecting a channel from the Selection Channel Selection list or use Auto Channel Select to have it automatically configured. Model The default 11NGHT40PLUS in Mode setting, and you can also manually change it into other modes.

  • Page 18: Mac Filter

    6.2 MAC Filter In this screen, you can choose the SSID Select and enable/disenable MAC Filter. If you enable the MAC Filter, Can choose two rules, MAC White list and MAC Black list. In MAC address table, you can add the corresponding MAC address.

  • Page 19: Security

    7 Security 7.1 Basic setting In Basic Setting screen, you can set relevant parameters, such as SYN-flood recovery, Invalid packets, Forward, Web Remote Management. Click save button to add them. As displayed below. 7.2 URL Filter In URL Filter screen, Provide URL Filter table, Click add button to add corresponding rules.

  • Page 20: System

    8 System System Maintenance includes User Manager, System Update, Reboot, Reset Default, System Log; 8.1 Management User Manager Setting has two default user name. The first user name is administrator, user level is Administrator. The second user name is admin, user level is Guest. Click corresponding Modify button, these two user names and passwords can be made relevant changes.

  • Page 21: System Upgrade

    8.2 System Upgrade Device Software Upgrading can update device software version. Click ‘Choose File’ button, and choose corresponding upgrading file. Click upload button, and then system will pop-up a windows to confirm uploading file.
  • Page 22 After that ,you can click to upgrade. In upgrade.

  • Page 23: Device Reboot

    8.3 Device Reboot Click Reboot button to reboot the current home gateway devices, as displayed below. 8.4 Restore Factory Reset Default Setting, click submit button to restore the factory setting of the home gateway into default status. All parameters configurations made in system which includes WAN port parameter settings, wifi settings and other parameters will be cleared.

  • Page 24: Specification

    button to finish relevant setting. Log events record relevant log events information that happened, it can clean relevant log information and export log information. As displayed below. 9. Specification Item Description Power Consumer <8W Power Supply 12V/1A Dimension 160×120×32 mm Working Temperature 0℃～50℃...
