- Page 1 Wodaplug® WDS111HZ 1*GE EPON ONU, PPPoE support, ZTE WDS111HZ-EPON User Manual Version： V1.1...
-
Page 2: Table Of Contents
EPON WDS111HZ User Manual Contents Attention ........................... 2 Install Caution ....................... 2 Precautions For Use ...................... 2 Introduce ........................... 3 Feature ........................... 4 Environmental Parameter ....................4 Interface ........................5 Application ........................5 Login ONU web ........................6 Internet service configuration ....................7 PPPoE Dial-up access Internet .................. -
Page 3: Attention
EPON WDS111HZ User Manual Attention Install Caution Do not near flammable or conductive items, high temperature, direct sunlight or moist environment, or on PC chassis, and check whether other home equipment placed around stability. Check the cable line.Test and confirm the ac or dc input voltage in the range of allowable, and direct current (dc) correct polarity. -
Page 4: Introduce
EPON WDS111HZ User Manual Avoid eyes optical interface, in order to avoid interface laser radiation injury of eyes. Please wear safety glasses, in order to effectively protect your eyes from damage. Optical interface. when not in use the best sheath with optical fiber interface. -
Page 5: Feature
EPON WDS111HZ User Manual high-performance forwarding capabilities to ensure excellent experience with Internet and HD video services. Therefore, the FD111HZ provides a perfect terminal solution and future-oriented service supporting capabilities for FTTH deployment. It has good third-party compatibility work with... -
Page 6: Interface
EPON WDS111HZ User Manual Interface Indicator light Introduction On: Ethernet connection is normal; Blinking: Data is being transmitted through the LAN port status Ethernet port; Off: Ethernet connection is not set up; EPON optical On: Optical power lower than receiver signals On: Success to register to OLT;... -
Page 7: Login Onu Web
EPON WDS111HZ User Manual Login ONU web Set computer local IP address manually to 192.168.101.100, using network cable, connect the computer with EPON ONU Ethernet ports, open a browser, copy and paste the URL: http://192.168.101.1 Page as shown below: Input Username:... -
Page 8: Internet Service Configuration
EPON WDS111HZ User Manual Internet service configuration PPPoE Dial-up access Internet ①Click Network ->WAN->WAN Connection, Login to the web interface as shown below: ② Connection Name choose “Create WAN Connection”, give the WAN name(ex:internet), check “Enable VLAN”, set correct VLAN ID and 802.1P, Type is “Route”, Service List to “INTERNET”, Link Type set to “PPP”. - Page 9 EPON WDS111HZ User Manual ③Click Network -> LAN->DHCP Server, Check ”Enable DHCP Server”, Click “Submit” button to enable the DHCP function. ④Click Status->Network Interface->WAN Connection, can check the PPPoE WAN is connected or not. If the WAN get an ip address, DNS address and the Ipv4 Connection Status is Connected, mean the PPPoE dial-up is successfully.
-
Page 10: Static Ip Access Internet
EPON WDS111HZ User Manual ONU on the premise that registed and online, but IP and DNS without address, the IPv4 Connectioin Status show Disconnected.and Disconnect Reason “AUTHENTICATION FAILURE”, Please check the PPPoE username and password. If IPv4 Connection Status is “connecting” all the time, Please check the OLT configuration. - Page 11 EPON WDS111HZ User Manual ③Click Network -> LAN->DHCP Server, Check ”Enable DHCPServer”, Click “Submit” button to enable the DHCP function.
-
Page 12: Dhcp Access Internet
EPON WDS111HZ User Manual ④ Click Status->Network Interface->WAN Connection, can check the IP WAN is connected or not. If the WAN get an ip address, DNS address and the Ipv4 Connection Status is Connected, mean the IP WAN is connected. PC connect to ONU LAN port and obtain an IP address automatically can surf the Internet. - Page 13 EPON WDS111HZ User Manual ② Connection Name choose “Create WAN Connection”, give the WAN name(ex:internet3), check “Enable VLAN”, set correct VLAN ID and 802.1P, Type is “Route”, Service List to “INTERNET”, Link Type set to “IP”. IP type set to “DHCP”. Other configuration keep in default.
-
Page 14: Onu Bridge Mode Access Internet
EPON WDS111HZ User Manual ④ Click Status->Network Interface->WAN Connection, can check the IP WAN is connected or not. If the WAN get an ip address, DNS address and the Ipv4 Connection Status is Connected, mean the IP WAN is connected. PC connect to ONU LAN port and obtain an IP address automatically can surf the Internet. -
Page 15: Reboot Onu
EPON WDS111HZ User Manual Reboot ONU Click Administration->System Management->System Management, Click “Reboot” button can reboot the device. Restore Default Click Administration->System Management->System Management, Click “Restore... -
Page 16: Software Upgrade
EPON WDS111HZ User Manual Default” button to set ONU to factory default. Software upgrade Click Administration->System Management->Software Upgrade to upgrade the ONU firmware version. Backup/Restore ONU Configuration Click Administration->System Management->User Configuration Management, Click... -
Page 17: Other
EPON WDS111HZ User Manual “Backup Configuration” to export configuration, Click “Restore Configuration” to import configuration. Other LOID modify LOID use to register. In default LOID the same as ONU MAC address. Click Network->PON->LOID can view and modify LOID. -
Page 18: Web Remote Management
EPON WDS111HZ User Manual web remote management On the premise that OLT have configured ONU management ip. Click Security->Service Control->Service Control, check “Enable”, Ingress select “OAM_WAN_MNGIP”, set “Start Source IP Address” and “End Source IP Address”, Mode set to “Permit”, check “HTTP”. Click “Add” button finally. -
Page 19: Conclusion
EPON WDS111HZ User Manual Conclusion Thanks for using Wodaplug Products ! EU worldwide distribution: Contact： Tomorrow systems s.r.o. Karlstejnska 323 252 25 Orech – Prague west Czech Republic GSM: +420 608 262 004 , +420 775 262 900 Tel. : +420 257 211 010 (store, service) Email: info@wodaplug.com...
